Short answer: both are discontinued, so this only matters if you are buying used. Used, the KEF R5 is the better pick: it ranks #40 of 188 floorstanding speakers by sound quality (rated 4.4/5), against #148 (rated 3.5/5) for the Infinity Reference 253. If you want one new, the Revel Concerta2 F35 ranks #30 at $900.
The KEF R5 is the better-sounding choice. Slim three-way tower with the acoustic advantages of KEF’s coincident Uni-Q midrange/tweeter: horizontal and vertical off-axis responses track the direct sound smoothly, producing stable imaging and a well-behaved directivity index. Watch for: The unusual gap between 77Hz F3 and 33Hz F10 indicates a gradual bass contour rather than flat deep-bass output; a subwoofer and roughly 80Hz high-pass are recommended for high-level playback.
Why pick the Infinity Reference 253: Horizontal beamwidth of about ±60 degrees is fairly smooth and well controlled. Watch for: CEA2034 spinorama and predicted in-room response both show elevated treble above 4kHz (“too hot”), a dip around 2kHz, and bass shelved down relative to the midrange.
Buy the KEF R5 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, start with the Revel Concerta2 F35 instead.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| KEF R5 | Infinity Reference 253 | |
|---|---|---|
| Price | $2,999 per pair Discontinued | $400 per pair used, Discontinued |
| Ranked | #40 of 188 in Large Size Floorstanding Speakers | #148 of 188 in Large Size Floorstanding Speakers |
| Bass Extension (-3dB) | 77Hz (measured, Erin’s Audio Corner) | 78Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 33Hz (measured, Erin’s Audio Corner) | 38Hz (measured, Audio Science Review) |
| Sensitivity | Approximately 86dB/2.83V/1m (measured, Erin’s Audio Corner) | 86.9dB (measured by Audio Science Review; 88dB manufacturer specified) |
| Impedance | Approximately 3.5 ohms minimum near 150Hz (measured, Erin’s Audio Corner) | 6 ohms |
| Drivers | 1” aluminum tweeter coaxial with 5” midrange; dual 5.25” woofers | Dual 5.25” (130mm) CMMD™ woofers, 5.25” (130mm) flat-piston CMMD™ midrange, 1” (25mm) CMMD™ tweeter |
| Dimensions | 40.4”H x 6.9”W x 13.5”D | 40.3”H x 6.8”W x 12.4”D (1023.6 x 172.7 x 315 mm) |
| Weight | 59.5 lbs (27 kg) each | 39.2 lbs (17.8 kg) each |
| Woofer Cabinet | ported, rear | ported, rear |
| Spinorama Preference Score | 5.78 | 5.43 (spinorama.org) |
| Spinorama Preference Score with Perfect Sub | 7.40 | 7.31 (spinorama.org) |
| DIY Kit | No | No |
Related Speaker Comparisons
How KEF R5 compares with other leading options:
- KEF Blade Two Meta vs KEF R5
- MoFi SourcePoint 888 vs KEF R5
- Revel F328Be vs KEF R5
- KEF R5 Meta vs KEF R5
- Revel F226Be vs KEF R5
Prices on this page were last checked October 9, 2026 at 8:01 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
KEF R5: $2,999 per pair Discontinued eBay
Same family: the KEF R3 (bookshelf, rated 4.5/5), the KEF R7 (larger floorstanding, ranked lower, estimated 4.2/5), the KEF R11 (larger floorstanding, ranked lower, estimated 4.3/5) and the KEF R2c (center, rated 4/5).
Pros: Slim three-way tower with the acoustic advantages of KEF’s coincident Uni-Q midrange/tweeter: horizontal and vertical off-axis responses track the direct sound smoothly, producing stable imaging and a well-behaved directivity index. Erin measured deep low-frequency reach for the cabinet width (77Hz F3 but 33Hz F10) and less than 1% harmonic distortion at 86dB. At 96dB it remains clean when high-passed, and its mild response deviations are suitable for equalization because the radiation pattern stays orderly. Measured bass extension of 77Hz (-3dB), with a measured sensitivity of 86dB.
Cons: The unusual gap between 77Hz F3 and 33Hz F10 indicates a gradual bass contour rather than flat deep-bass output; a subwoofer and roughly 80Hz high-pass are recommended for high-level playback. Erin measured a minimum near 3.5 ohms around 150Hz, although most of the curve remains above 4 ohms, so amplifier quality still matters. Sensitivity is approximately 86dB/2.83V/1m. At 102dB, compression reaches roughly 1dB around 150Hz, showing the limits of the twin 5.25-inch woofers. This original model lacks the Meta version’s MAT rear-wave absorption. Discontinued.
Full KEF R5 review and specifications →
| Bass Extension (-10dB) | 33Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 77Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 40.4”H x 6.9”W x 13.5”D |
| Drivers | 1” aluminum tweeter coaxial with 5” midrange; dual 5.25” woofers |
| Impedance | Approximately 3.5 ohms minimum near 150Hz (measured, Erin’s Audio Corner) |
| Sensitivity | Approximately 86dB/2.83V/1m (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 5.78 |
| Spinorama Preference Score with Perfect Sub | 7.40 |
| Weight | 59.5 lbs (27 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Infinity Reference 253: $400 per pair used Discontinued eBay
Same family: the Infinity Reference R152 (smaller bookshelf, rated 3.8/5), the Infinity Reference R162 (larger bookshelf, rated 3.8/5), the Infinity Reference R263 (larger floorstanding, ranked higher, rated 4.4/5), the Infinity Reference RC252 (smaller center, rated 4.4/5) and the Infinity Reference RC263 (larger center, rated 4.2/5).
Pros: Horizontal beamwidth of about ±60 degrees is fairly smooth and well controlled. Really amazing value for the performance. Measured bass extension of 78Hz (-3dB), with a measured sensitivity of 86.9dB.
Cons: CEA2034 spinorama and predicted in-room response both show elevated treble above 4kHz (“too hot”), a dip around 2kHz, and bass shelved down relative to the midrange. Vertical directivity requires staying at or below the tweeter axis for accurate tonal balance. Distortion at 96dB SPL/1m is broadly elevated above the reviewer’s audibility threshold across much of the midrange. Minimum impedance dips to 4.2 ohms. Discontinued.
Full Infinity Reference 253 review and specifications →
| Bass Extension (-10dB) | 38Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 40.3”H x 6.8”W x 12.4”D (1023.6 x 172.7 x 315 mm) |
| Drivers | Dual 5.25” (130mm) CMMD™ woofers, 5.25” (130mm) flat-piston CMMD™ midrange, 1” (25mm) CMMD™ tweeter |
| Impedance | 6 ohms |
| Sensitivity | 86.9dB (measured by Audio Science Review; 88dB manufacturer specified) |
| Spinorama Preference Score | 5.43 (spinorama.org) |
| Spinorama Preference Score with Perfect Sub | 7.31 (spinorama.org) |
| Weight | 39.2 lbs (17.8 kg) each |
| Woofer Cabinet | ported, rear |
