Short answer: the KEF R5 for better sound quality, the Revel F206 for the lower price. The KEF R5 ranks #9 of 56 floorstanding speakers at $2999. The Revel F206 ranks #17 at $2000, $999 cheaper.
On the KEF R5 side: Slim three-way tower with the acoustic advantages of KEF’s coincident Uni-Q midrange/tweeter: horizontal and vertical off-axis responses track the direct sound smoothly. Set against that: The unusual gap between 77Hz F3 and 33Hz F10 indicates a gradual bass contour rather than flat deep-bass output; a subwoofer and roughly 80Hz high-pass are recommended for high-level playback.
The case for the Revel F206: CEA2034 spinorama shows a pretty even on-axis response. The tradeoff: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz.
Buy the KEF R5 if sound quality matters more than the price. Buy the Revel F206 if the price matters more than sound quality.
Specifications Side By Side
| KEF R5 | Revel F206 | |
|---|---|---|
| Price | $2,999/pair Discontinued | $2000 used, Discontinued |
| Ranked | #9 of 56 in Large Size Floorstanding Speakers | #17 of 56 in Large Size Floorstanding Speakers |
| Bass Extension (-3dB) | 77Hz (measured, Erin’s Audio Corner) | 60Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 33Hz (measured, Erin’s Audio Corner) | 34Hz (measured, Audio Science Review) |
| Sensitivity | Approximately 86dB/2.83V/1m (measured, Erin’s Audio Corner) | 87dB (measured, Audio Science Review) |
| Impedance | Approximately 3.5 ohms minimum near 150Hz (measured, Erin’s Audio Corner) | 4 ohms nominal (3.3 ohms minimum, measured by Audio Science Review) |
| Drivers | 1" aluminum tweeter coaxial with 5" midrange; dual 5.25" woofers | Dual 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25" (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide |
| Dimensions | 40.4"H x 6.9"W x 13.5"D | 40.3"H x 8.4"W x 12.2"D (1023.6 x 213.4 x 309.9 mm) |
| Discontinued | Yes | Yes |
| Weight | 59.5 lb each | 57.3 lbs / 26 kg each |
| Woofer Cabinet | ported, rear | ported, front |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- KEF R5 Meta vs Focal Chora 816
- Revel Concerta2 F35 vs JBL HDI-3600
- KEF R5 Meta vs JBL Studio 698
- KEF R5 vs JBL Studio 590
- Revel F206 vs PSB Imagine T65
The Two Speakers In Full
KEF R5: $2,999/pair Discontinued
Pros: Slim three-way tower with the acoustic advantages of KEF’s coincident Uni-Q midrange/tweeter: horizontal and vertical off-axis responses track the direct sound smoothly, producing stable imaging and a well-behaved directivity index. Erin measured deep low-frequency reach for the cabinet width—77Hz F3 but 33Hz F10—and less than 1% harmonic distortion at 86dB. At 96dB it remains clean when high-passed, and its mild response deviations are suitable for equalization because the radiation pattern stays orderly.
Cons: The unusual gap between 77Hz F3 and 33Hz F10 indicates a gradual bass contour rather than flat deep-bass output; a subwoofer and roughly 80Hz high-pass are recommended for high-level playback. Erin measured a minimum near 3.5 ohms around 150Hz, although most of the curve remains above 4 ohms, so amplifier quality still matters. Sensitivity is approximately 86dB/2.83V/1m. At 102dB, compression reaches roughly 1dB around 150Hz, showing the limits of the twin 5.25-inch woofers. This original model lacks the Meta version’s MAT rear-wave absorption. Discontinued.
Full KEF R5 review and specifications →
| Bass Extension (-10dB) | 33Hz (measured, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 77Hz (measured, Erin's Audio Corner) |
| Dimensions | 40.4"H x 6.9"W x 13.5"D |
| Discontinued | Yes |
| Drivers | 1" aluminum tweeter coaxial with 5" midrange; dual 5.25" woofers |
| Impedance | Approximately 3.5 ohms minimum near 150Hz (measured, Erin's Audio Corner) |
| Sensitivity | Approximately 86dB/2.83V/1m (measured, Erin's Audio Corner) |
| Weight | 59.5 lb each |
| Woofer Cabinet | ported, rear |
As an eBay Partner, we may be compensated if you make a purchase.
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Revel F206: $2000 used, Discontinued
Pros: CEA2034 spinorama shows a pretty even on-axis response. Predicted in-room response is excellent, with a smooth downward slope. Horizontal beamwidth of about ±65 degrees is wide, if a bit uneven. Distortion is very nice at 86dB SPL/1m, falling below the frequency range where human hearing is most sensitive, and stays excellent even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice suppression of port and woofer resonances. Really amazing value for the performance.
Cons: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz. Vertical directivity means listening position needs to stay within the tweeter axis, though the reviewer notes there is some leeway. Minimum impedance dips to 3.3 ohms, calling for an amplifier comfortable with a demanding load. Discontinued.
Full Revel F206 review and specifications →
| Bass Extension (-10dB) | 34Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 60Hz (measured, Audio Science Review) |
| Dimensions | 40.3"H x 8.4"W x 12.2"D (1023.6 x 213.4 x 309.9 mm) |
| Discontinued | Yes |
| Drivers | Dual 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25" (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide |
| Impedance | 4 ohms nominal (3.3 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 87dB (measured, Audio Science Review) |
| Weight | 57.3 lbs / 26 kg each |
| Woofer Cabinet | ported, front |
