Short answer: the Revel F206. It ranks #17 of 56 floorstanding speakers by sound quality at $2000; the PSB Imagine T65 ranks #26 and costs $2699, so there is not much of a tradeoff to weigh.
On the Revel F206 side: CEA2034 spinorama shows a pretty even on-axis response. Set against that: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz.
The case for the PSB Imagine T65: Three-way design with dual 6.5” woven carbon fiber woofers delivers genuinely strong, extended low end for a $2,699 tower - among the better performers Erin has measured in this price class. The tradeoff: Noticeable dip in the midrange/crossover region that Erin flagged as affecting dialogue and vocal clarity, though he notes a couple bands of EQ smooths it out.
Buy the Revel F206. It ranks higher for sound quality than the PSB Imagine T65 and costs less, so there is no real case for the other one.
Specifications Side By Side
| Revel F206 | PSB Imagine T65 | |
|---|---|---|
| Price | $2000 used, Discontinued | $2,699 |
| Ranked | #17 of 56 in Large Size Floorstanding Speakers | #26 of 56 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 34Hz (measured, Audio Science Review) | 26Hz (measured average, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 60Hz (measured, Audio Science Review) | 47Hz (measured average, Erin’s Audio Corner) |
| Dimensions | 40.3"H x 8.4"W x 12.2"D (1023.6 x 213.4 x 309.9 mm) | 38-13/16"H x 8-3/8"W x 13.5"D (986 x 213 x 343mm) |
| Discontinued | Yes | - |
| Impedance | 4 ohms nominal (3.3 ohms minimum, measured by Audio Science Review) | 8 ohms nominal (3.3 ohms minimum measured by Erin’s Audio Corner; manufacturer specifies 4 ohms minimum) |
| Drivers | Dual 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25" (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide | 1" titanium dome tweeter, 5.25" woven carbon fiber midrange, 2x 6.5" woven carbon fiber woofers |
| Sensitivity | 87dB (measured, Audio Science Review) | 85.1dB (measured average, Erin’s Audio Corner) |
| Weight | 57.3 lbs / 26 kg each | 44 lbs each |
| Woofer Cabinet | ported, front | - |
| Crossovers | - | 600Hz & 2000Hz, 4th-order Linkwitz-Riley |
| Recommended Power | - | 20-200W |
| Bass Reflex | - | Dual rear slot ports, individual woofer chambers |
| Frequency Response | - | 28Hz - 20kHz (±1.5dB, manufacturer specified) |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- KEF R5 Meta vs JBL Studio 698
- Revel Concerta2 F35 vs JBL HDI-3600
- KEF R11 Meta vs Q Acoustics 5040
- Arendal 1961 Tower vs PSB Imagine T65
- KEF R5 vs Revel F206
The Two Speakers In Full
Revel F206: $2000 used, Discontinued
Pros: CEA2034 spinorama shows a pretty even on-axis response. Predicted in-room response is excellent, with a smooth downward slope. Horizontal beamwidth of about ±65 degrees is wide, if a bit uneven. Distortion is very nice at 86dB SPL/1m, falling below the frequency range where human hearing is most sensitive, and stays excellent even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice suppression of port and woofer resonances. Really amazing value for the performance.
Cons: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz. Vertical directivity means listening position needs to stay within the tweeter axis, though the reviewer notes there is some leeway. Minimum impedance dips to 3.3 ohms, calling for an amplifier comfortable with a demanding load. Discontinued.
Full Revel F206 review and specifications →
| Bass Extension (-10dB) | 34Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 60Hz (measured, Audio Science Review) |
| Dimensions | 40.3"H x 8.4"W x 12.2"D (1023.6 x 213.4 x 309.9 mm) |
| Discontinued | Yes |
| Drivers | Dual 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25" (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide |
| Impedance | 4 ohms nominal (3.3 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 87dB (measured, Audio Science Review) |
| Weight | 57.3 lbs / 26 kg each |
| Woofer Cabinet | ported, front |
As an eBay Partner, we may be compensated if you make a purchase.
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
PSB Imagine T65: $2,699 The Audio Factory
Pros: Three-way design with dual 6.5” woven carbon fiber woofers delivers genuinely strong, extended low end for a $2,699 tower - among the better performers Erin has measured in this price class. Distortion shows a clean second-order character with clear separation from third-order all the way up to 96 dB, indicating a well-controlled motor. Compression data shows enhancement rather than compression below about 50-60 Hz, so the bass can sound louder as you turn it up rather than choking off. Wide, forgiving vertical listening window (about ±25°) thanks to the 3-way layout, giving more seating and placement flexibility than most towers. Plenty of dynamic headroom for home theater use or a two-channel system - 100W drove it comfortably in Erin’s room.
Cons: Noticeable dip in the midrange/crossover region that Erin flagged as affecting dialogue and vocal clarity, though he notes a couple bands of EQ smooths it out. Some horizontal dispersion mismatch (about 10-15° of ballooning between 1-3 kHz) between the midrange and tweeter can add extra perceived attack or detail if your room’s sidewalls are reflective. Dips to 4 ohms, so it wants an amplifier comfortable driving a 4-ohm load. Distortion climbs above 3% around 60 Hz at 96 dB, though it’s benign second-order distortion.
Full PSB Imagine T65 review and specifications →
| Bass Extension (-10dB) | 26Hz (measured average, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 47Hz (measured average, Erin's Audio Corner) |
| Bass Reflex | Dual rear slot ports, individual woofer chambers |
| Crossovers | 600Hz & 2000Hz, 4th-order Linkwitz-Riley |
| Dimensions | 38-13/16"H x 8-3/8"W x 13.5"D (986 x 213 x 343mm) |
| Drivers | 1" titanium dome tweeter, 5.25" woven carbon fiber midrange, 2x 6.5" woven carbon fiber woofers |
| Frequency Response | 28Hz - 20kHz (±1.5dB, manufacturer specified) |
| Impedance | 8 ohms nominal (3.3 ohms minimum measured by Erin's Audio Corner; manufacturer specifies 4 ohms minimum) |
| Recommended Power | 20-200W |
| Sensitivity | 85.1dB (measured average, Erin's Audio Corner) |
| Weight | 44 lbs each |
