Short answer: the Revel F226Be for the higher ranking, the Revel F206 for the lower price. The Revel F226Be ranks #8 of 25 floorstanding speakers at $7700. The Revel F206 ranks #9 at $2000, $5700 cheaper.
The case for the Revel F206: CEA2034 spinorama shows a pretty even on-axis response. Set against that: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz.
What the Revel F226Be gets right: Three-way design with a beryllium tweeter, a dedicated 5.25” mid-range, and dual 5.25” midwoofers (not a coaxial layout). The catch: Minimum impedance of 3.7 ohms means it wants a 4-ohm-capable amplifier.
One note: the Revel F206 is discontinued, but it still ranks #9 of 25 floorstanding speakers, ahead of most of what is still sold new, so it is worth considering used.
Buy the Revel F206 if the price matters more than the ranking. Buy the Revel F226Be if the ranking matters more than the price.
Specifications Side By Side
| Revel F206 | Revel F226Be | |
|---|---|---|
| Price | $2000 used, Discontinued | $7700 |
| Ranked | #9 of 25 in Large Size Floorstanding Speakers | #8 of 25 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 34Hz | 36Hz |
| Bass Extension (-3dB) | 60Hz | 56Hz |
| Dimensions | 40.3"H x 8.4"W x 12.2"D (1023.6 x 213.4 x 309.9 mm) | 41.3"H x 9.8"W x 13.7"D (1049 x 248.9 x 348 mm) |
| Discontinued | Yes | - |
| Impedance | 4 ohms | 8 ohms |
| Drivers | Dual 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25" (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide | Two 6.5" (165mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Sensitivity | 87dB | 90dB |
| Weight | 57.3 lbs / 26 kg each | 58.2 lbs / 26.4 kg each |
| Woofer Cabinet | Front ported | Front ported |
The Two Speakers In Full
Revel F206: $2000 used, Discontinued Ebay
Pros: CEA2034 spinorama shows a pretty even on-axis response. Predicted in-room response is excellent, with a smooth downward slope. Horizontal beamwidth of about ±65 degrees is wide, if a bit uneven. Distortion is very nice at 86dB SPL/1m, falling below the frequency range where human hearing is most sensitive, and stays excellent even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice suppression of port and woofer resonances. Really amazing value for the performance.
Cons: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz. Vertical directivity means listening position needs to stay within the tweeter axis, though the reviewer notes there is some leeway. Minimum impedance dips to 3.3 ohms, calling for an amplifier comfortable with a demanding load. Discontinued.
| Bass Extension (-10dB) | 34Hz |
|---|---|
| Bass Extension (-3dB) | 60Hz |
| Dimensions | 40.3"H x 8.4"W x 12.2"D (1023.6 x 213.4 x 309.9 mm) |
| Discontinued | Yes |
| Drivers | Dual 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25" (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide |
| Impedance | 4 ohms |
| Sensitivity | 87dB |
| Weight | 57.3 lbs / 26 kg each |
| Woofer Cabinet | Front ported |
- Reviews, Comparisons and Sound Samples
- Buy Used
- Links
Revel F226Be: $7700 Crutchfield
Pros: Three-way design with a beryllium tweeter, a dedicated 5.25” mid-range, and dual 5.25” midwoofers (not a coaxial layout). On-axis frequency response holds within about ±1.5dB - excellent linearity. Average sensitivity around 90dB (2.83V/1m), notably higher than some competing three-way designs, meaning less amplifier power is needed for the same output. Wide horizontal radiation of about ±70° at the -6dB point, landing right in the reviewer’s preferred 60-70° range for an enveloping soundstage without excess diffusion. Distortion at 96dB stays under 1% THD through most of the midrange - strong output capability. Flat enough on- and off-axis response that toeing the speaker away from the listener preserves the same tonal balance rather than changing it, giving flexibility in placement.
Cons: Minimum impedance of 3.7 ohms means it wants a 4-ohm-capable amplifier; budget AVRs rated only for 6 or 8 ohms may struggle. F3 of 56Hz and F10 of 36Hz mean it doesn’t extend nearly as low as some three-way rivals with larger woofers; a dedicated subwoofer is recommended for home theater use, though it can work without one for music alone. Vertical directivity tolerance is tighter (about ±20° in the crossover region) than true coaxial designs, since the tweeter, midrange, and woofers are physically separated - a bigger consideration with multiple theater rows or if you tend to stand and move around the room. On-axis, the top end reads as a bit bright according to the reviewer’s subjective impression, generally benefiting from some toe-out. High-gloss cabinet finish can create distracting reflections if used behind a projector screen in a home theater setup.
| Bass Extension (-10dB) | 36Hz |
|---|---|
| Bass Extension (-3dB) | 56Hz |
| Dimensions | 41.3"H x 9.8"W x 13.7"D (1049 x 248.9 x 348 mm) |
| Drivers | Two 6.5" (165mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms |
| Sensitivity | 90dB |
| Weight | 58.2 lbs / 26.4 kg each |
| Woofer Cabinet | Front ported |
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Links
