Short answer: the Revel F228Be for better sound quality, the Revel F206 for the lower price. The Revel F228Be ranks #15 of 56 floorstanding speakers at $7000. The Revel F206 ranks #17 at $2000, $5000 cheaper.
On the Revel F228Be side: CEA2034 spinorama shows an essentially flat on-axis response with very nice directivity. Set against that: Minimum impedance dips to 3.4 ohms with a secondary rise around 2kHz, calling for an amplifier comfortable with a demanding load.
What the Revel F206 offers: CEA2034 spinorama shows a pretty even on-axis response. Watch for: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz.
Buy the Revel F228Be if sound quality matters more than the price. Buy the Revel F206 if the price matters more than sound quality.
Specifications Side By Side
| Revel F228Be | Revel F206 | |
|---|---|---|
| Price | $7000 | $2000 used, Discontinued |
| Ranked | #15 of 56 in Large Size Floorstanding Speakers | #17 of 56 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 25Hz (measured, Audio Science Review) | 34Hz (measured, Audio Science Review) |
| Bass Extension (-3dB) | 61Hz (measured, Audio Science Review) | 60Hz (measured, Audio Science Review) |
| Dimensions | 50.9"H x 13.5"W x 17.6"D (1292.9 x 342.9 x 447 mm) | 40.3"H x 8.4"W x 12.2"D (1023.6 x 213.4 x 309.9 mm) |
| Impedance | 8 ohms | 4 ohms nominal (3.3 ohms minimum, measured by Audio Science Review) |
| Drivers | Dual 8" (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter | Dual 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25" (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide |
| Sensitivity | 89.3dB (300Hz-3kHz @ 2.83V/1m, measured by Audio Science Review; 90dB manufacturer specified) | 87dB (measured, Audio Science Review) |
| Weight | 112.4 lbs / 51 kg each | 57.3 lbs / 26 kg each |
| Woofer Cabinet | ported, front | ported, front |
| Discontinued | - | Yes |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- MoFi SourcePoint V10 Master Edition vs Revel Concerta2 F35
- Revel F226Be vs Revel Concerta2 F35
- Revel F226Be vs JBL Studio 698
- Revel F208 vs Revel F228Be
- Revel F206 vs Revel F226Be
The Two Speakers In Full
Revel F228Be: $7000 Crutchfield
Pros: CEA2034 spinorama shows an essentially flat on-axis response with very nice directivity. Predicted in-room response is nearly perfect, with a smooth slope down from bass to treble. Horizontal beamwidth of about ±70 degrees is wide and holds up well until narrowing above 8kHz. Vertical directivity offers more degrees of listening-height freedom than a typical bookshelf design, a benefit of this tower’s driver layout. Distortion is extremely low across the full audio range at 86dB SPL/1m and stays comfortable even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice, well-integrated crossover behavior with only low-level resonances.
Cons: Minimum impedance dips to 3.4 ohms with a secondary rise around 2kHz, calling for an amplifier comfortable with a demanding load. Very expensive and very heavy (51 kg each).
Full Revel F228Be review and specifications →
| Bass Extension (-10dB) | 25Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 61Hz (measured, Audio Science Review) |
| Dimensions | 50.9"H x 13.5"W x 17.6"D (1292.9 x 342.9 x 447 mm) |
| Drivers | Dual 8" (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms |
| Sensitivity | 89.3dB (300Hz-3kHz @ 2.83V/1m, measured by Audio Science Review; 90dB manufacturer specified) |
| Weight | 112.4 lbs / 51 kg each |
| Woofer Cabinet | ported, front |
As an eBay Partner, we may be compensated if you make a purchase.
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Revel F206: $2000 used, Discontinued
Pros: CEA2034 spinorama shows a pretty even on-axis response. Predicted in-room response is excellent, with a smooth downward slope. Horizontal beamwidth of about ±65 degrees is wide, if a bit uneven. Distortion is very nice at 86dB SPL/1m, falling below the frequency range where human hearing is most sensitive, and stays excellent even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice suppression of port and woofer resonances. Really amazing value for the performance.
Cons: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz. Vertical directivity means listening position needs to stay within the tweeter axis, though the reviewer notes there is some leeway. Minimum impedance dips to 3.3 ohms, calling for an amplifier comfortable with a demanding load. Discontinued.
Full Revel F206 review and specifications →
| Bass Extension (-10dB) | 34Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 60Hz (measured, Audio Science Review) |
| Dimensions | 40.3"H x 8.4"W x 12.2"D (1023.6 x 213.4 x 309.9 mm) |
| Discontinued | Yes |
| Drivers | Dual 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25" (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide |
| Impedance | 4 ohms nominal (3.3 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 87dB (measured, Audio Science Review) |
| Weight | 57.3 lbs / 26 kg each |
| Woofer Cabinet | ported, front |
