Short answer: the Revel F328Be for the higher ranking, the Revel F228Be for the lower price. The Revel F328Be ranks #5 of 25 floorstanding speakers at $13600. The Revel F228Be ranks #6 at $7000, $6600 cheaper.
On the Revel F228Be side: CEA2034 spinorama shows an essentially flat on-axis response with very nice directivity. The catch: Minimum impedance dips to 3.4 ohms with a secondary rise around 2kHz, calling for an amplifier comfortable with a demanding load.
The case for the Revel F328Be: CEA2034 spinorama shows a quite flat on-axis response with superb directivity and efficiency above 90dB. The catch: Vertical directivity is asymmetric - the reviewer recommends staying between -20 and +40 degrees relative to the tweeter axis.
Buy the Revel F228Be if the price matters more than the ranking. Buy the Revel F328Be if the ranking matters more than the price.
Specifications Side By Side
| Revel F228Be | Revel F328Be | |
|---|---|---|
| Price | $7000 | $13600 |
| Ranked | #6 of 25 in Large Size Floorstanding Speakers | #5 of 25 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 25Hz | 39Hz |
| Bass Extension (-3dB) | 61Hz | 74Hz |
| Dimensions | 50.9"H x 13.5"W x 17.6"D (1292.9 x 342.9 x 447 mm) | 50.9"H x 13.5"W x 17.6"D (1292.9 x 342.9 x 447 mm) |
| Impedance | 8 ohms | 8 ohms |
| Drivers | Dual 8" (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter | Three 8" (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Sensitivity | 89.5dB | 91dB |
| Weight | 112.4 lbs / 51 kg each | 112.4 lbs / 51 kg each |
| Woofer Cabinet | Front ported | Dual rear-mounted ports |
The Two Speakers In Full
Revel F228Be: $7000 Crutchfield
Pros: CEA2034 spinorama shows an essentially flat on-axis response with very nice directivity. Predicted in-room response is nearly perfect, with a smooth slope down from bass to treble. Horizontal beamwidth of about ±70 degrees is wide and holds up well until narrowing above 8kHz. Vertical directivity offers more degrees of listening-height freedom than a typical bookshelf design, a benefit of this tower’s driver layout. Distortion is extremely low across the full audio range at 86dB SPL/1m and stays comfortable even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice, well-integrated crossover behavior with only low-level resonances.
Cons: Minimum impedance dips to 3.4 ohms with a secondary rise around 2kHz, calling for an amplifier comfortable with a demanding load. Very expensive and very heavy (51 kg each).
| Bass Extension (-10dB) | 25Hz |
|---|---|
| Bass Extension (-3dB) | 61Hz |
| Dimensions | 50.9"H x 13.5"W x 17.6"D (1292.9 x 342.9 x 447 mm) |
| Drivers | Dual 8" (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms |
| Sensitivity | 89.5dB |
| Weight | 112.4 lbs / 51 kg each |
| Woofer Cabinet | Front ported |
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Links
Revel F328Be: $13600 Crutchfield
Pros: CEA2034 spinorama shows a quite flat on-axis response with superb directivity and efficiency above 90dB. Predicted in-room response is extremely accurate, with a smooth ~5dB downward slope from bass to treble that suits typical rooms without correction. Early reflections sum very nicely with the direct sound. Horizontal beamwidth of about ±70 degrees is wide and quite smooth. At 96dB SPL/1m distortion stays easily below the reviewer’s audibility threshold across nearly the whole range.
Cons: Vertical directivity is asymmetric - the reviewer recommends staying between -20 and +40 degrees relative to the tweeter axis, reflecting the driver layout of this three-way tower. Impedance dips to a minimum of 3 ohms with an additional resonance-driven phase swing, calling for an amplifier comfortable with a demanding load. Very expensive and very heavy (51 kg each).
| Bass Extension (-10dB) | 39Hz |
|---|---|
| Bass Extension (-3dB) | 74Hz |
| Dimensions | 50.9"H x 13.5"W x 17.6"D (1292.9 x 342.9 x 447 mm) |
| Drivers | Three 8" (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms |
| Sensitivity | 91dB |
| Weight | 112.4 lbs / 51 kg each |
| Woofer Cabinet | Dual rear-mounted ports |
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Links
