Short answer: the Revel F328Be for better sound quality, the KEF R5 for the lower price. The Revel F328Be ranks #7 of 56 floorstanding speakers at $13600. The KEF R5 ranks #9 at $2999, $10601 cheaper.
What the Revel F328Be offers: CEA2034 spinorama shows a quite flat on-axis response with superb directivity and efficiency above 90dB. Watch for: Vertical directivity is asymmetric - the reviewer recommends staying between -20 and +40 degrees relative to the tweeter axis, reflecting the driver layout of this three-way tower.
What the KEF R5 gets right: Slim three-way tower with the acoustic advantages of KEF’s coincident Uni-Q midrange/tweeter: horizontal and vertical off-axis responses track the direct sound smoothly. The catch: The unusual gap between 77Hz F3 and 33Hz F10 indicates a gradual bass contour rather than flat deep-bass output; a subwoofer and roughly 80Hz high-pass are recommended for high-level playback.
Buy the Revel F328Be if sound quality matters more than the price. Buy the KEF R5 if the price matters more than sound quality.
Specifications Side By Side
| Revel F328Be | KEF R5 | |
|---|---|---|
| Price | $13600 | $2,999/pair Discontinued |
| Ranked | #7 of 56 in Large Size Floorstanding Speakers | #9 of 56 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 39Hz (measured, Audio Science Review) | 33Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 74Hz (measured, Audio Science Review) | 77Hz (measured, Erin’s Audio Corner) |
| Dimensions | 50.9"H x 13.5"W x 17.6"D (1292.9 x 342.9 x 447 mm) | 40.4"H x 6.9"W x 13.5"D |
| Impedance | 8 ohms nominal (3 ohms minimum, measured by Audio Science Review) | Approximately 3.5 ohms minimum near 150Hz (measured, Erin’s Audio Corner) |
| Drivers | Three 8" (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter | 1" aluminum tweeter coaxial with 5" midrange; dual 5.25" woofers |
| Sensitivity | 91dB (measured, Audio Science Review) | Approximately 86dB/2.83V/1m (measured, Erin’s Audio Corner) |
| Weight | 112.4 lbs / 51 kg each | 59.5 lb each |
| Woofer Cabinet | ported, rear | ported, rear |
| Discontinued | - | Yes |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- Revel F226Be vs MoFi SourcePoint V10 Master Edition
- Revel F226Be vs Dali Rubikore 6
- KEF R5 Meta vs Endow Audio Bravura 7
- KEF R11 Meta vs Revel F328Be
- Revel F208 vs Revel F328Be
The Two Speakers In Full
Revel F328Be: $13600 Crutchfield
Pros: CEA2034 spinorama shows a quite flat on-axis response with superb directivity and efficiency above 90dB. Predicted in-room response is extremely accurate, with a smooth ~5dB downward slope from bass to treble that suits typical rooms without correction. Early reflections sum very nicely with the direct sound. Horizontal beamwidth of about ±70 degrees is wide and quite smooth. At 96dB SPL/1m distortion stays easily below the reviewer’s audibility threshold across nearly the whole range.
Cons: Vertical directivity is asymmetric - the reviewer recommends staying between -20 and +40 degrees relative to the tweeter axis, reflecting the driver layout of this three-way tower. Impedance dips to a minimum of 3 ohms with an additional resonance-driven phase swing, calling for an amplifier comfortable with a demanding load. Very expensive and very heavy (51 kg each).
Full Revel F328Be review and specifications →
| Bass Extension (-10dB) | 39Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 74Hz (measured, Audio Science Review) |
| Dimensions | 50.9"H x 13.5"W x 17.6"D (1292.9 x 342.9 x 447 mm) |
| Drivers | Three 8" (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms nominal (3 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 91dB (measured, Audio Science Review) |
| Weight | 112.4 lbs / 51 kg each |
| Woofer Cabinet | ported, rear |
As an eBay Partner, we may be compensated if you make a purchase.
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
KEF R5: $2,999/pair Discontinued
Pros: Slim three-way tower with the acoustic advantages of KEF’s coincident Uni-Q midrange/tweeter: horizontal and vertical off-axis responses track the direct sound smoothly, producing stable imaging and a well-behaved directivity index. Erin measured deep low-frequency reach for the cabinet width—77Hz F3 but 33Hz F10—and less than 1% harmonic distortion at 86dB. At 96dB it remains clean when high-passed, and its mild response deviations are suitable for equalization because the radiation pattern stays orderly.
Cons: The unusual gap between 77Hz F3 and 33Hz F10 indicates a gradual bass contour rather than flat deep-bass output; a subwoofer and roughly 80Hz high-pass are recommended for high-level playback. Erin measured a minimum near 3.5 ohms around 150Hz, although most of the curve remains above 4 ohms, so amplifier quality still matters. Sensitivity is approximately 86dB/2.83V/1m. At 102dB, compression reaches roughly 1dB around 150Hz, showing the limits of the twin 5.25-inch woofers. This original model lacks the Meta version’s MAT rear-wave absorption. Discontinued.
Full KEF R5 review and specifications →
| Bass Extension (-10dB) | 33Hz (measured, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 77Hz (measured, Erin's Audio Corner) |
| Dimensions | 40.4"H x 6.9"W x 13.5"D |
| Discontinued | Yes |
| Drivers | 1" aluminum tweeter coaxial with 5" midrange; dual 5.25" woofers |
| Impedance | Approximately 3.5 ohms minimum near 150Hz (measured, Erin's Audio Corner) |
| Sensitivity | Approximately 86dB/2.83V/1m (measured, Erin's Audio Corner) |
| Weight | 59.5 lb each |
| Woofer Cabinet | ported, rear |
