Short answer: the Infinity Reference 253 for easier amplification; the Magnepan LRS+ for a dipole panel. The Magnepan is a thin two-way planar-magnetic open baffle, about 48 inches tall and just 1 inch deep, but it is so power-hungry that a pair of 600W Macintosh monoblocks only averaged about 90dB, so a robust amplifier is mandatory. The Infinity’s ±60 degree beamwidth is smooth and controlled, though treble above 4kHz runs hot.
Buy the Magnepan LRS+ if you want one new; the Infinity Reference 253 is discontinued, so only look for it used.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| Infinity Reference 253 | Magnepan LRS+ | |
|---|---|---|
| Price | $400 per pair used, Discontinued | $1300 per pair |
| Ranked | #60 of 74 in Large Size Floorstanding Speakers | #61 of 74 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 38Hz (measured, Audio Science Review) | 67Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) | 74Hz (measured, Erin’s Audio Corner) |
| Dimensions | 40.3”H x 6.8”W x 12.4”D (1023.6 x 172.7 x 315 mm) | 48”H x 13.5”W x 1”D (1219.2 x 342.9 x 25.4 mm) |
| Impedance | 6 ohms | 4 ohms nominal, 3 ohms minimum (measured, Erin’s Audio Corner) |
| Drivers | Dual 5.25” (130mm) CMMD™ woofers, 5.25” (130mm) flat-piston CMMD™ midrange, 1” (25mm) CMMD™ tweeter | Full-range planar magnetic dipole panel (48” tall x 13.5” wide); quasi-ribbon design, two-way with separate mid/bass and tweeter ribbon sections |
| Sensitivity | 86.9dB (measured by Audio Science Review; 88dB manufacturer specified) | 85.1dB (measured, Erin’s Audio Corner) |
| Weight | 39.2 lbs (17.8 kg) each | 30 lbs (13.6 kg) |
| Woofer Cabinet | ported, rear | open baffle |
| Spinorama Preference Score | 5.43 (spinorama.org) | 1.27 |
| Spinorama Preference Score with Perfect Sub | 7.31 (spinorama.org) | 4.32 |
| DIY Kit | No | No |
Related Speaker Comparisons
More top alternatives to Infinity Reference 253:
- Revel F226Be vs Infinity Reference 253
- KEF Reference 203 vs Infinity Reference 253
- JBL HDI-3800 vs Infinity Reference 253
- Focal Chora 816 vs Infinity Reference 253
- Revel F208 vs Infinity Reference 253
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Infinity Reference 253: $400 per pair used Discontinued eBay
Pros: Horizontal beamwidth of about ±60 degrees is fairly smooth and well controlled. Really amazing value for the performance. Measured bass extension of 78Hz (-3dB), with a measured sensitivity of 86.9dB.
Cons: CEA2034 spinorama and predicted in-room response both show elevated treble above 4kHz (“too hot”), a dip around 2kHz, and bass shelved down relative to the midrange. Vertical directivity requires staying at or below the tweeter axis for accurate tonal balance. Distortion at 96dB SPL/1m is broadly elevated above the reviewer’s audibility threshold across much of the midrange. Minimum impedance dips to 4.2 ohms. Discontinued.
Full Infinity Reference 253 review and specifications →
| Bass Extension (-10dB) | 38Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 40.3”H x 6.8”W x 12.4”D (1023.6 x 172.7 x 315 mm) |
| Drivers | Dual 5.25” (130mm) CMMD™ woofers, 5.25” (130mm) flat-piston CMMD™ midrange, 1” (25mm) CMMD™ tweeter |
| Impedance | 6 ohms |
| Sensitivity | 86.9dB (measured by Audio Science Review; 88dB manufacturer specified) |
| Spinorama Preference Score | 5.43 (spinorama.org) |
| Spinorama Preference Score with Perfect Sub | 7.31 (spinorama.org) |
| Weight | 39.2 lbs (17.8 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Infinity Reference 253 vs Polk Signature Elite ES60
- Infinity Reference 253 vs JBL Stage 2 280F
- Infinity Reference 253 vs Focal Aria Evo X N°2
- Infinity Reference 253 vs Polk T50
- Infinity Reference 253 vs SVS Ultra Evolution Pinnacle
- Infinity Reference 253 vs Definitive Technology BP-9020
- Infinity Reference 253 vs Sony SS-CS3
- Infinity Reference 253 vs Klipsch RP-6000F II
- See all 34 comparisons
Magnepan LRS+: $1300 per pair Magnepan eBay
Pros: Thin, two-way planar-magnetic open-baffle/dipole panel design (about 48” tall, just 1” deep). Delivers a uniquely dramatic and enveloping soundstage with genuinely three-dimensional depth effects that work across all music genres, not just classical or orchestral material as commonly assumed. Extremely tight, locked-in center-phantom imaging when set up correctly. Open-baffle design avoids the “boxy” enclosure coloration of conventional cabinet speakers. Multitone distortion is remarkably consistent from low to high frequency, a characteristic the reviewer hasn’t observed in conventional cone-and-dome speakers. Compression at high output stays modest (about 0.5-1dB) through the midrange and treble, giving roughly 20-26dB of usable dynamic range in that region. At its price, a strong contender for a dedicated secondary listening room, even if not a main-system replacement. Measured bass extension of 74Hz (-3dB), with a measured sensitivity of 85.1dB.
Cons: Extremely current-hungry and power-hungry: even a pair of 600W Macintosh monoblock amplifiers only averaged about 90dB output. A robust, high-power amplifier is essentially mandatory, and budget amps won’t cut it. Bass rolls off very quickly (F3 74Hz, F10 67Hz, described as falling off “like a rock”), making a subwoofer an absolute requirement for any low-end content. A roughly 3dB dip in the mid-bass (100-300Hz) region thins out vocal body and fullness compared to a conventional bookshelf speaker. A resonance/bump around 400Hz adds a mild boxy quality, though it responds well to about 2dB of EQ correction. Extraordinarily fussy about exact positioning: both seating height (must align with the acoustic reference point between the panel’s lower tie-down points) and horizontal aiming are unusually critical; moving just a couple of inches can cause treble content above roughly 500-600Hz to nearly vanish. Distinct off-axis cancellation zones exist directly to the sides of the panel, where very little sound is audible at all. Fails badly under extreme dynamic-transient testing in the bass, and the reviewer blew fuses pushing the speaker during testing: not built for high-volume or highly dynamic playback. A genuinely different category from conventional hi-fi speakers, requiring more setup patience and experimentation than a typical monopole design.
Full Magnepan LRS+ review and specifications →
| Bass Extension (-10dB) | 67Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 74Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 48”H x 13.5”W x 1”D (1219.2 x 342.9 x 25.4 mm) |
| Drivers | Full-range planar magnetic dipole panel (48” tall x 13.5” wide); quasi-ribbon design, two-way with separate mid/bass and tweeter ribbon sections |
| Impedance | 4 ohms nominal, 3 ohms minimum (measured, Erin’s Audio Corner) |
| Sensitivity | 85.1dB (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 1.27 |
| Spinorama Preference Score with Perfect Sub | 4.32 |
| Weight | 30 lbs (13.6 kg) |
| Woofer Cabinet | open baffle |
