Short answer: the KEF R5 for bass, the Revel Concerta2 F35 for a simpler cabinet design. Both need a subwoofer: the R5’s 77Hz F3 and 33Hz F10 mean a gradual bass contour, while the F35 is rated F3 61Hz and F10 39Hz. The R5’s Uni-Q tracks off-axis smoothly for stable imaging, and the Revel’s two-and-a-half-way, four-driver layout uses a waveguide tweeter in a rear-ported cabinet.
Buy the Revel Concerta2 F35. It is rated higher for sound quality and still sold new, while the KEF R5 is discontinued.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| KEF R5 | Revel Concerta2 F35 | |
|---|---|---|
| Price | $2,999 per pair Discontinued | $900 per pair |
| Ranked | #22 of 74 in Large Size Floorstanding Speakers | #19 of 74 in Large Size Floorstanding Speakers |
| Bass Extension (-3dB) | 77Hz (measured, Erin’s Audio Corner) | 70Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-10dB) | 33Hz (measured, Erin’s Audio Corner) | 50Hz (measured, Erin’s Audio Corner) |
| Sensitivity | Approximately 86dB/2.83V/1m (measured, Erin’s Audio Corner) | 89.4dB (measured, Erin’s Audio Corner; 90dB manufacturer specified) |
| Impedance | Approximately 3.5 ohms minimum near 150Hz (measured, Erin’s Audio Corner) | 6 ohms nominal (3.8 ohms minimum, measured by Erin’s Audio Corner) |
| Drivers | 1” aluminum tweeter coaxial with 5” midrange; dual 5.25” woofers | 3x 5.25” deep anodized aluminum cone woofers, 1” Aluminum Tweeter |
| Dimensions | 40.4”H x 6.9”W x 13.5”D | 40.3”H x 8.4”W x 12.2”D (1023.6 x 213.4 x 309.9 mm) |
| Weight | 59.5 lbs (27 kg) each | 41 lbs (18.6 kg) each |
| Woofer Cabinet | ported, rear | ported, rear |
| Spinorama Preference Score | 5.78 | 5.35 |
| Spinorama Preference Score with Perfect Sub | 7.40 | 7.30 |
| DIY Kit | No | No |
Related Speaker Comparisons
More top alternatives to Revel Concerta2 F35:
- GR-Research NX-Treme vs Revel Concerta2 F35
- KEF Blade Two Meta vs Revel Concerta2 F35
- MoFi SourcePoint V10 Master Edition vs Revel Concerta2 F35
- MoFi SourcePoint 888 vs Revel Concerta2 F35
- Revel Concerta2 F35 vs Revel F328Be
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
KEF R5: $2,999 per pair Discontinued eBay
Pros: Slim three-way tower with the acoustic advantages of KEF’s coincident Uni-Q midrange/tweeter: horizontal and vertical off-axis responses track the direct sound smoothly, producing stable imaging and a well-behaved directivity index. Erin measured deep low-frequency reach for the cabinet width (77Hz F3 but 33Hz F10) and less than 1% harmonic distortion at 86dB. At 96dB it remains clean when high-passed, and its mild response deviations are suitable for equalization because the radiation pattern stays orderly. Measured bass extension of 77Hz (-3dB), with a measured sensitivity of 86dB.
Cons: The unusual gap between 77Hz F3 and 33Hz F10 indicates a gradual bass contour rather than flat deep-bass output; a subwoofer and roughly 80Hz high-pass are recommended for high-level playback. Erin measured a minimum near 3.5 ohms around 150Hz, although most of the curve remains above 4 ohms, so amplifier quality still matters. Sensitivity is approximately 86dB/2.83V/1m. At 102dB, compression reaches roughly 1dB around 150Hz, showing the limits of the twin 5.25-inch woofers. This original model lacks the Meta version’s MAT rear-wave absorption. Discontinued.
Full KEF R5 review and specifications →
| Bass Extension (-10dB) | 33Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 77Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 40.4”H x 6.9”W x 13.5”D |
| Drivers | 1” aluminum tweeter coaxial with 5” midrange; dual 5.25” woofers |
| Impedance | Approximately 3.5 ohms minimum near 150Hz (measured, Erin’s Audio Corner) |
| Sensitivity | Approximately 86dB/2.83V/1m (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 5.78 |
| Spinorama Preference Score with Perfect Sub | 7.40 |
| Weight | 59.5 lbs (27 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Revel Concerta2 F35: $900 per pair Crutchfield eBay
Pros: Two-and-a-half-way, four-driver design: a 1” aluminum dome tweeter on a waveguide, a 5.25” mid-range, and dual 5.25” mid-bass drivers in a rear-ported cabinet. Measured sensitivity of 89.4dB closely matches the 90dB spec, and distortion looks good at both 86dB and 96dB, holding up well even with a high-pass filter applied. At its sale price of $900/pair, down from full retail, the reviewer calls it a “no-brainer,” undercutting comparable budget floorstanders like the ELAC DF63. Frequency response and directivity mismatches are largely EQ-able, since most of what shows up in measurements traces to physical tweeter/mid-range separation rather than a fundamental flaw. Compression is fairly well controlled for the price: about 1dB of loss around 100Hz under long-term compression, described as “par for the course” at this cost. Measured bass extension of 70Hz (-3dB), with a measured sensitivity of 89.4dB.
Cons: F3 of 61Hz and F10 of 39Hz mean a subwoofer is needed for real bass extension. A dip in the lower midrange/2-3kHz region reduces attack and detail, and a peak around 5kHz adds some edge and sibilance in the lower treble. A peak in off-axis energy around 3kHz reflects off sidewalls at roughly 60-70° off-axis and arrives louder than the direct sound: this specific issue can’t be fixed with EQ (boosting the direct sound would boost the stronger reflection too) and would need acoustic absorption to properly address, though the reviewer considers it a minor, optional fix at this price. A couple of minor resonances appear in the impedance plot, including one around 300Hz that may partly explain a subtle sense of vocal warmth noticed in listening, though it’s more likely room-related. Minimum impedance around 3.8 ohms. Short-term compression testing shows some increased distortion in the tweeter and higher-frequency compression at loud output.
Full Revel Concerta2 F35 review and specifications →
| Bass Extension (-10dB) | 50Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 70Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 40.3”H x 8.4”W x 12.2”D (1023.6 x 213.4 x 309.9 mm) |
| Drivers | 3x 5.25” deep anodized aluminum cone woofers, 1” Aluminum Tweeter |
| Impedance | 6 ohms nominal (3.8 ohms minimum, measured by Erin’s Audio Corner) |
| Sensitivity | 89.4dB (measured, Erin’s Audio Corner; 90dB manufacturer specified) |
| Spinorama Preference Score | 5.35 |
| Spinorama Preference Score with Perfect Sub | 7.30 |
| Weight | 41 lbs (18.6 kg) each |
| Woofer Cabinet | ported, rear |
