Short answer: the Revel F228Be for a flatter measured response, the KEF R5 for easier amplification. The F228Be’s CEA2034 spinorama is essentially flat on-axis with very nice directivity, but its minimum impedance dips to 3.4 ohms with a secondary rise around 2kHz, so it wants an amplifier comfortable with a demanding load. The R5’s Uni-Q gives smooth off-axis tracking, though its 77Hz F3 and 33Hz F10 call for a subwoofer and 80Hz high-pass.
Buy the Revel F228Be. It is rated higher for sound quality and still sold new, while the KEF R5 is discontinued.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| KEF R5 | Revel F228Be | |
|---|---|---|
| Price | $2,999 per pair Discontinued | $9,000 per pair |
| Ranked | #22 of 74 in Large Size Floorstanding Speakers | #17 of 74 in Large Size Floorstanding Speakers |
| Bass Extension (-3dB) | 77Hz (measured, Erin’s Audio Corner) | 61Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 33Hz (measured, Erin’s Audio Corner) | 25Hz (measured, Audio Science Review) |
| Sensitivity | Approximately 86dB/2.83V/1m (measured, Erin’s Audio Corner) | 89.3dB (300Hz-3kHz @ 2.83V/1m, measured by Audio Science Review; 90dB manufacturer specified) |
| Impedance | Approximately 3.5 ohms minimum near 150Hz (measured, Erin’s Audio Corner) | 8 ohms |
| Drivers | 1” aluminum tweeter coaxial with 5” midrange; dual 5.25” woofers | Dual 8” (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4” (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1” (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Dimensions | 40.4”H x 6.9”W x 13.5”D | 50.9”H x 13.5”W x 17.6”D (1292.9 x 342.9 x 447 mm) |
| Weight | 59.5 lbs (27 kg) each | 112.4 lbs (51 kg) each |
| Woofer Cabinet | ported, rear | ported, front |
| Spinorama Preference Score | 5.78 | 6.01 |
| Spinorama Preference Score with Perfect Sub | 7.40 | 7.51 |
| DIY Kit | No | No |
Related Speaker Comparisons
More worthwhile head-to-heads for Revel F228Be:
- KEF Blade Two Meta vs Revel F228Be
- MoFi SourcePoint V10 Master Edition vs Revel F228Be
- MoFi SourcePoint 888 vs Revel F228Be
- Revel F228Be vs Revel F328Be
- Radiant Acoustics Clarity 66 vs Revel F228Be
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
KEF R5: $2,999 per pair Discontinued eBay
Pros: Slim three-way tower with the acoustic advantages of KEF’s coincident Uni-Q midrange/tweeter: horizontal and vertical off-axis responses track the direct sound smoothly, producing stable imaging and a well-behaved directivity index. Erin measured deep low-frequency reach for the cabinet width (77Hz F3 but 33Hz F10) and less than 1% harmonic distortion at 86dB. At 96dB it remains clean when high-passed, and its mild response deviations are suitable for equalization because the radiation pattern stays orderly. Measured bass extension of 77Hz (-3dB), with a measured sensitivity of 86dB.
Cons: The unusual gap between 77Hz F3 and 33Hz F10 indicates a gradual bass contour rather than flat deep-bass output; a subwoofer and roughly 80Hz high-pass are recommended for high-level playback. Erin measured a minimum near 3.5 ohms around 150Hz, although most of the curve remains above 4 ohms, so amplifier quality still matters. Sensitivity is approximately 86dB/2.83V/1m. At 102dB, compression reaches roughly 1dB around 150Hz, showing the limits of the twin 5.25-inch woofers. This original model lacks the Meta version’s MAT rear-wave absorption. Discontinued.
Full KEF R5 review and specifications →
| Bass Extension (-10dB) | 33Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 77Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 40.4”H x 6.9”W x 13.5”D |
| Drivers | 1” aluminum tweeter coaxial with 5” midrange; dual 5.25” woofers |
| Impedance | Approximately 3.5 ohms minimum near 150Hz (measured, Erin’s Audio Corner) |
| Sensitivity | Approximately 86dB/2.83V/1m (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 5.78 |
| Spinorama Preference Score with Perfect Sub | 7.40 |
| Weight | 59.5 lbs (27 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Revel F228Be: $9,000 per pair Crutchfield eBay
Older model: the Revel F208 (ranked higher, rated 4.5/5).
Pros: CEA2034 spinorama shows an essentially flat on-axis response with very nice directivity. Predicted in-room response is nearly perfect, with a smooth slope down from bass to treble. Horizontal beamwidth of about ±70 degrees is wide and holds up well until narrowing above 8kHz. Vertical directivity offers more degrees of listening-height freedom than a typical bookshelf design, a benefit of this tower’s driver layout. Distortion is extremely low across the full audio range at 86dB SPL/1m and stays comfortable even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice, well-integrated crossover behavior with only low-level resonances. Measured bass extension of 61Hz (-3dB), with a measured sensitivity of 89.3dB.
Cons: Minimum impedance dips to 3.4 ohms with a secondary rise around 2kHz, calling for an amplifier comfortable with a demanding load. Very expensive and very heavy (51 kg each).
Full Revel F228Be review and specifications →
| Bass Extension (-10dB) | 25Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 61Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 50.9”H x 13.5”W x 17.6”D (1292.9 x 342.9 x 447 mm) |
| Drivers | Dual 8” (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofers, 5-1/4” (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1” (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms |
| Sensitivity | 89.3dB (300Hz-3kHz @ 2.83V/1m, measured by Audio Science Review; 90dB manufacturer specified) |
| Spinorama Preference Score | 6.01 |
| Spinorama Preference Score with Perfect Sub | 7.51 |
| Weight | 112.4 lbs (51 kg) each |
| Woofer Cabinet | ported, front |
