Short answer: both are discontinued, so this only matters if you are buying used. Used, the Revel M105 is the better pick: it ranks #15 of 160 bookshelf speakers by sound quality (rated 4.2/5), against #143 (rated 2.1/5) for the JBL Stage A130. If you want one new, the Revel Performa4 M145 replaces the Revel M105 and is rated 4.3/5 at $1,999.95.
What the JBL Stage A130 does well: More constant, better-behaved directivity than the smaller JBL Stage A120 once past the tweeter crossover point, giving a more consistent radiation pattern that likely explains some of its positive reception among other reviewers. The tradeoff: Still shows the same underlying “Batman”-shaped response pattern as the JBL Stage A120: a bass bump, a midrange dip, a cabinet-resonance peak around 800Hz-1.7kHz (confirmed via accelerometer testing on the cabinet panels), and roughly a 5dB treble bump around 10kHz.
The Revel M105 is the more accurate choice. CEA2034 spinorama shows an essentially flat on-axis response with only a small 5kHz peak, a smooth listening window, and clean waterfall decay. Its measured preference score, a predictor of how neutral it sounds, is 5.76 against 4.04 for the JBL Stage A130. The tradeoff: Low nominal impedance demands a capable amplifier that can handle low-impedance loads.
Buy the Revel M105 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, buy the Revel Performa4 M145, which replaces the Revel M105.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| JBL Stage A130 | Revel M105 | |
|---|---|---|
| Price | $399 per pair Discontinued | $1,500 per pair Discontinued |
| Ranked | #143 of 160 in Medium Size Bookshelf Speakers | #15 of 160 in Medium Size Bookshelf Speakers |
| Crossover Frequency | 3.2kHz | - |
| Dimensions | 12.6”H x 7.5”W x 9.1”D (321 x 190 x 230 mm) | 14”H x 7.9”W x 9.8”D (355.6 x 200.7 x 248.9 mm) |
| Impedance | 6 ohms nominal, about 4.3 ohms minimum (measured, Erin’s Audio Corner) | 8 ohms nominal, low minimum |
| Sensitivity | 85.2dB (measured, Erin’s Audio Corner) | 85dB (2.83V/1m, measured, Audio Science Review) |
| Drivers | 5.25” (133mm) polycellulose woofer, 1” (25mm) aluminum dome tweeter | 5.25” aluminum cone woofer, 1” aluminum tweeter with acoustic lens waveguide |
| Weight | 12 lbs (5.45 kg) each | 15.4 lbs (7 kg) each |
| Woofer Cabinet | ported | ported, rear |
| Bass Extension (-3dB) | 66Hz (measured, Erin’s Audio Corner) | 63Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 50Hz (measured, Erin’s Audio Corner) | 49.8Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
| Spinorama Preference Score | 4.04 | 5.76 |
| Spinorama Preference Score with Perfect Sub | 6.51 | 8.18 |
| DIY Kit | No | No |
| Frequency Response | - | 60Hz - 44kHz (+/-3dB) (Manufacturer specified) |
Related Speaker Comparisons
More worthwhile head-to-heads for Revel M105:
- Ascend Sierra 1 v2 vs Revel M105
- KEF LS50 Meta vs Revel M105
- Arendal 1961 Monitor vs Revel M105
- Monitor Audio Silver 50 7G vs Revel M105
- Revel M105 vs Klipsch RP-500M II
Prices on this page were last checked October 9, 2026 at 8:01 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
JBL Stage A130: $399 per pair Discontinued eBay
Newer model: the JBL Stage 250B, ranked higher, rated 3.2/5.
Older model: the JBL Arena 120 (ranked higher, rated 3.8/5).
Same family: the JBL Stage A120 (smaller bookshelf, ranked higher, rated 2.5/5), the JBL Stage A180 (floorstanding, rated 3.8/5), the JBL Stage A125C (smaller center, rated 3.4/5) and the JBL Stage A135C (larger center, rated 2.9/5).
Pros: More constant, better-behaved directivity than the smaller JBL Stage A120 once past the tweeter crossover point, giving a more consistent radiation pattern that likely explains some of its positive reception among other reviewers. Distortion at 96dB measures slightly better than a direct competitor (Emotiva B1+) in the low end, though slightly worse at high frequencies. The tweeter itself sounded decent to the reviewer, who considers it a reasonable value at its price point despite other reservations. Wide, well-filled horizontal radiation through the midrange. Measured bass extension of 66Hz (-3dB), with a measured sensitivity of 85.2dB.
Cons: Still shows the same underlying “Batman”-shaped response pattern as the JBL Stage A120: a bass bump, a midrange dip, a cabinet-resonance peak around 800Hz-1.7kHz (confirmed via accelerometer testing on the cabinet panels), and roughly a 5dB treble bump around 10kHz. Does not include a port bung, so sealed-cabinet listening requires DIY stuffing rather than a proper factory solution. The reviewer’s own measurements notably diverge from another well-known publication’s results on this same model, possibly reflecting a running production change, though this couldn’t be confirmed. Overall sound quality struck the reviewer as not a good-sounding speaker despite the more favorable measurements relative to the JBL Stage A120. Output-limited at extreme volumes (102dB), similar to its smaller sibling. Loses to the similarly-priced Emotiva B1+ in overall linearity and neutrality, according to the reviewer’s direct comparison. Discontinued.
Full JBL Stage A130 review and specifications →
| Bass Extension (-10dB) | 50Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 66Hz (measured, Erin’s Audio Corner) |
| Crossover Frequency | 3.2kHz |
| DIY Kit | No |
| Dimensions | 12.6”H x 7.5”W x 9.1”D (321 x 190 x 230 mm) |
| Drivers | 5.25” (133mm) polycellulose woofer, 1” (25mm) aluminum dome tweeter |
| Impedance | 6 ohms nominal, about 4.3 ohms minimum (measured, Erin’s Audio Corner) |
| Sensitivity | 85.2dB (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 4.04 |
| Spinorama Preference Score with Perfect Sub | 6.51 |
| Weight | 12 lbs (5.45 kg) each |
| Woofer Cabinet | ported |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- JBL Stage A130 vs Fluance Signature HFS
- JBL Stage A130 vs JBL Control 1 Pro
- JBL Stage A130 vs Q Acoustics 5020
- JBL Stage A130 vs Polk T15
- JBL Stage A130 vs Micca RB42
- JBL Stage A130 vs Definitive Technology ProMonitor 1000
- JBL Stage A130 vs Pioneer Elite SP-EBS73-LR
- JBL Stage A130 vs Q Acoustics 3020i
- See all 35 comparisons
Revel M105: $1,500 per pair Discontinued eBay
Newer model: the Revel Performa4 M145, ranked higher, estimated 4.3/5.
Same family: the Revel M106 (larger bookshelf, rated 4.6/5), the Revel F206 (smaller floorstanding, rated 4.5/5), the Revel F208 (larger floorstanding, rated 4.5/5), the Revel Performa3 C205 (smaller center, rated 4.1/5) and the Revel Performa3 C208 (larger center, rated 4/5).
Pros: CEA2034 spinorama shows an essentially flat on-axis response with only a small 5kHz peak, a smooth listening window, and clean waterfall decay. Wide horizontal dispersion gives flexibility with toe-in. The reviewer called it reference-quality performance with minor EQ correction applied. Measured bass extension of 63Hz (-3dB), with a measured sensitivity of 85dB.
Cons: Low nominal impedance demands a capable amplifier that can handle low-impedance loads. Bass distortion runs high in the 80-250Hz range from woofer displacement, and maximum output is limited compared to larger designs. Discontinued.
Full Revel M105 review and specifications →
| Bass Extension (-10dB) | 49.8Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
|---|---|
| Bass Extension (-3dB) | 63Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 14”H x 7.9”W x 9.8”D (355.6 x 200.7 x 248.9 mm) |
| Drivers | 5.25” aluminum cone woofer, 1” aluminum tweeter with acoustic lens waveguide |
| Frequency Response | 60Hz - 44kHz (+/-3dB) (Manufacturer specified) |
| Impedance | 8 ohms nominal, low minimum |
| Sensitivity | 85dB (2.83V/1m, measured, Audio Science Review) |
| Spinorama Preference Score | 5.76 |
| Spinorama Preference Score with Perfect Sub | 8.18 |
| Weight | 15.4 lbs (7 kg) each |
| Woofer Cabinet | ported, rear |
