The XMechanik Mechano23 DIY is rated 4.4/5 for sound quality, #6 of 179 Medium Size Bookshelf Speakers. See all Passive Home rankings for every top pick.
Prices on this page were last checked November 18, 2026 at 8:41 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#6 XMechanik Mechano23 DIY: $200 per pair DIY parts Madisound (Tweeter) $200 Madisound (Woofer) eBay
Pros: A DIY bookshelf design with exceptionally accurate sound that rivals far pricier speakers for a modest parts cost. A DIY two-way bookshelf design with a nearly perfect predicted in-room response, 0.195dB average on-axis deviation and a 5.42 preference score. The bass alignment is unusually well damped, with a measured Q of 0.336, so the -3dB point at 77.6Hz rolls off cleanly instead of building into a resonant bump the way many small ported designs do. Audio Science Review’s independent Klippel NFS review praised the predicted in room response, with directivity matching that beats some commercial designs costing many times more, all from about $200 in parts. Measured bass extension of 77.6Hz (-3dB), with a measured sensitivity of 85.1dB.
Cons: This is a true DIY project. There is no assembled unit to buy, drivers come from Madisound, the crossover kit comes separately from EZ Speaker Solutions, and the birch plywood cabinet has to be built and finished by hand. Listening window smoothness measures a moderate 0.47 and the sound power directivity index has more variation (standard deviation 4.02) than the tightest commercial designs, so off axis energy isn’t quite as evenly controlled as the excellent on axis figures suggest.
| Released | Feb 2023 (3 years ago) |
|---|---|
| Bass Extension (-10dB) | 42.4Hz (measured, Audio Science Review) |
| Bass Extension (-3dB) | 77.6Hz (measured, Audio Science Review) |
| Cabinet Material | 18mm Baltic birch plywood |
| Country | Design origin: United States (ASR forum); assembled by buyer |
| DIY Kit | Yes |
| Dimensions | 11.4”H x 6.9”W x 10.4”D (290 x 174 x 263 mm) |
| Drivers | Scan-Speak Discovery H2606/9200 1” horn loaded textile dome tweeter, SB Acoustics SB13PFCR25-4 5” fiber cone woofer |
| Enclosure | ported |
| Impedance | 4.1 ohms nominal (measured, ASR) |
| Port Tuning | Approximately 45Hz |
| Sensitivity | 85.1dB @ 2.83V/1m (measured, Audio Science Review) |
| Spinorama Preference Score | 5.42 |
| Spinorama Preference Score with Perfect Sub | 7.88 |
