RCF NX 945-A Review: Rated 4.1/5

The RCF NX 945-A is rated 4.1/5 for sound quality, #8 of 76 15-Inch PA Speakers. See all PA & Live Sound rankings for every top pick.

Prices on this page were last checked October 24, 2026 at 4:42 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Brand: RCF

#8 RCF NX 945-A: $2,299.00 Amazon $2,299.00 B&H Photo Video $2,299.00 Guitar Center $2,299.00 eBay

Same family: the RCF NX 910-A (smaller model, rated 3.5/5), the RCF NX 912-A (smaller model, rated 4/5), the RCF NX 932-A (smaller model, rated 4.2/5) and the RCF NX 915-A (smaller model, ranked lower, rated 3.6/5).

Pros: A loud powered 15 inch PA speaker in a plywood cabinet with wide coverage and onboard processing that keeps bass tidy. The top NX-series 15-inch box pairs a plywood cabinet with a 135dB claimed peak, the highest in the NX range, and a wide 100° x 70° pattern. RCF’s FiRPHASE and Bass Motion Control processing carry over from the smaller NX models. Measured bass extension of 65Hz (-3dB).

Cons: The measurement is truncated and does not produce a preference score, so its tonal position relies on published engineering rather than a confirmed result. At 27.3kg it is heavier than the RCF ART 945-A alternative.

Released	2024 (2 years ago)
AES Input	No
Amplifier Power	2100W peak (1400W LF + 700W HF)
Aux Input	No
Bass Extension (-3dB)	65Hz (measured, vendor Spinorama data)
Bluetooth	No
Cabinet Material	Plywood
Coaxial Input	No
Configuration	Active 2-way bass-reflex PA speaker
Coverage	100° x 70°
Crossover Frequency	650Hz
DSP	Yes, FiRPHASE and Bass Motion Control
Dimensions	27.8”H x 16.5”W x 17.8”D (705 x 420 x 451 mm)
Drivers	15” woofer, compression driver
Frequency Response	45Hz - 20kHz (manufacturer specified)
Guitar Input	No
HDMI Input	No
Inputs	XLR/TRS combo input and XLR output
Maximum SPL	135dB peak (manufacturer specified)
Microphone Input	No
Optical Input	No
Passive	No
RCA Input	No
Rigging	M10 and quick-lock rigging; 35mm pole mount
TRS Input	Yes
USB Input	No
Weight	60.2 lbs (27.3 kg)
XLR Input	Yes

• Links
  • RCF NX 945-A Product Information
• Reviews, Comparisons and Sound Samples
  • Spinorama Measurements

Frequency Response

How the RCF NX 945-A measures across the audible range. A flatter listening window (the sound arriving straight at you) is more neutral: peaks sound forward or harsh, dips sound recessed. The estimated in-room response adds what a typical room does, and there a gentle, even tilt down toward the treble is ideal. Both curves are shifted so their 300 Hz to 3 kHz average sits at 0 dB.

Listening windowEstimated in-room response

Measurement data: spinorama.org, measured by the manufacturer.

EQ for a Neutral Response

No EQ preset: the best simple EQ we can fit to these measurements improves the predicted preference score by less than 0.2. The listening window is already close to flat, and what holds the score back, such as narrow ripple in the response or uneven output off-axis, is not something EQ can fix without making it worse elsewhere.
