Short answer: the Pioneer SP-BS22-LR (Philharmonic AAM Mod) ranks #51 of 74 bookshelf speakers by sound quality at $168; the JBL Control 1 Pro ranks #64 at $164. Close enough in price that the sound-quality gap is the deciding factor.
What the Pioneer SP-BS22-LR (Philharmonic AAM Mod) offers: This is Dennis Murphy’s “Affordable Accuracy Monitor” (AAM) mod of the discontinued, budget Pioneer SP-BS22-LR: the stock tweeter is swapped for a Peerless BC25TG15 dome and a redesigned 3rd-order crossover is built to match it to the stock 4” woofer. CEA2034 spinorama shows only small variations from a flat on-axis response with some directivity error near the crossover, a marked improvement over the unmodified Pioneer, which the reviewer notes shows much more variation from flat. Distortion at 86dB SPL/1m is reasonably controlled above 200Hz, and tweeter distortion barely rises even at 96dB SPL/1m. Watch for: Some directivity error appears near the crossover frequency. Distortion climbs in the woofer’s range (below 200Hz) at both 86dB and 96dB SPL/1m. Minimum impedance dips to about 5 ohms with a couple of resonance peaks. This is a DIY project, not a finished retail product: Murphy sold ~$168 pre-built pairs for a while but no longer does, so it now requires sourcing a used/discontinued Pioneer SP-BS22-LR pair plus building the crossover and swapping the tweeter yourself. The mod itself is public domain, but there is no current turnkey way to buy this speaker.
What the JBL Control 1 Pro offers: Magnetically shielded transducers and a rugged molded enclosure make it a durable choice for wall-mount or install use, with SonicGuard overload protection built into the crossover. Feels solidly built despite the low price, and the professional crossover network uses steep slopes. Watch for: Sound power and predicted in-room response measurements are badly uneven compared to the JBL 305P Mark II tested alongside it, with no waveguide to control directivity as the woofer beams before handing off to the tweeter. The reviewer performed no distortion or dedicated listening test on this unit and concluded he didn’t “think there is a reason to purchase it” over a proper studio monitor at a similar price.
Buy the Pioneer SP-BS22-LR (Philharmonic AAM Mod) if sound quality matters more than the price. Buy the JBL Control 1 Pro if the price matters more than sound quality.
If sound quality matters at all to you, skip the JBL Control 1 Pro. It ranks near the bottom of the 74 bookshelf speakers, so look higher up the list instead.
Specifications Side By Side
| Pioneer SP-BS22-LR (Philharmonic AAM Mod) | JBL Control 1 Pro | |
|---|---|---|
| Price | $168 | $164 |
| Ranked | #51 of 74 in Medium Size Bookshelf Speakers | #64 of 74 in Medium Size Bookshelf Speakers |
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) | 78Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) | 55Hz (measured, Audio Science Review) |
| Drivers | 1x 4" curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1" silk dome tweeter (replacement) | 5.25" low frequency driver, 0.75" polycarbonate dome tweeter |
| Weight | 9 lbs / 4.1 kg | 4 lbs / 1.8 kg each |
| Sensitivity | 83dB (2.83V/1m, measured by Audio Science Review) | 87dB (2.83V/1m, measured, Audio Science Review) |
| Impedance | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) | 4 ohms |
| Crossover Frequency | 3000Hz | - |
| Dimensions | 12.6"H x 7.1"W x 8.5"D (320.0 x 180.0 x 215.0 mm) | 9.3H x 6.3W x 5.6D in |
| Woofer Cabinet | ported, rear | sealed |
| Frequency Response | - | 80Hz - 20kHz -10dB (Manufacturer specified) |
| Power Handling | - | 150W |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- Fluance Signature HFS vs Polk T15
- Fluance Signature HFS vs Klipsch R-41M
- Micca RB42 vs Polk T15
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Micca RB42
- Micca RB42 vs JBL Control 1 Pro
Prices on this page were last checked August 24, 2026 at 6:53 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Pioneer SP-BS22-LR (Philharmonic AAM Mod): $168 eBay
Pros: This is Dennis Murphy’s “Affordable Accuracy Monitor” (AAM) mod of the discontinued, budget Pioneer SP-BS22-LR: the stock tweeter is swapped for a Peerless BC25TG15 dome and a redesigned 3rd-order crossover is built to match it to the stock 4” woofer. CEA2034 spinorama shows only small variations from a flat on-axis response with some directivity error near the crossover, a marked improvement over the unmodified Pioneer, which the reviewer notes shows much more variation from flat. Distortion at 86dB SPL/1m is reasonably controlled above 200Hz, and tweeter distortion barely rises even at 96dB SPL/1m.
Cons: Some directivity error appears near the crossover frequency. Distortion climbs in the woofer’s range (below 200Hz) at both 86dB and 96dB SPL/1m. Minimum impedance dips to about 5 ohms with a couple of resonance peaks. This is a DIY project, not a finished retail product: Murphy sold ~$168 pre-built pairs for a while but no longer does, so it now requires sourcing a used/discontinued Pioneer SP-BS22-LR pair plus building the crossover and swapping the tweeter yourself. The mod itself is public domain, but there is no current turnkey way to buy this speaker.
Full Pioneer SP-BS22-LR (Philharmonic AAM Mod) review and specifications →
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| Crossover Frequency | 3000Hz |
| Dimensions | 12.6"H x 7.1"W x 8.5"D (320.0 x 180.0 x 215.0 mm) |
| Drivers | 1x 4" curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1" silk dome tweeter (replacement) |
| Impedance | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 83dB (2.83V/1m, measured by Audio Science Review) |
| Weight | 9 lbs / 4.1 kg |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL L52 Classic
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Dynaudio X14
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Parts Express Copperhead Desktop Kit
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL Stage A120
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL Stage 2 250B
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs ELAC Uni-Fi 2.0 UB52
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs ELAC BS U5
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs KEF Q100
- See all 31 comparisons
JBL Control 1 Pro: $164 Parts Express eBay
Pros: Magnetically shielded transducers and a rugged molded enclosure make it a durable choice for wall-mount or install use, with SonicGuard overload protection built into the crossover. Feels solidly built despite the low price, and the professional crossover network uses steep slopes.
Cons: Sound power and predicted in-room response measurements are badly uneven compared to the JBL 305P Mark II tested alongside it, with no waveguide to control directivity as the woofer beams before handing off to the tweeter. The reviewer performed no distortion or dedicated listening test on this unit and concluded he didn’t “think there is a reason to purchase it” over a proper studio monitor at a similar price.
Full JBL Control 1 Pro review and specifications →
| Bass Extension (-10dB) | 55Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| Dimensions | 9.3H x 6.3W x 5.6D in |
| Drivers | 5.25" low frequency driver, 0.75" polycarbonate dome tweeter |
| Frequency Response | 80Hz - 20kHz -10dB (Manufacturer specified) |
| Impedance | 4 ohms |
| Power Handling | 150W |
| Sensitivity | 87dB (2.83V/1m, measured, Audio Science Review) |
| Weight | 4 lbs / 1.8 kg each |
| Woofer Cabinet | sealed |
