Short answer: the ELAC BS U5 for better sound quality, the Pioneer SP-BS22-LR (Philharmonic AAM Mod) for the lower price. The ELAC BS U5 ranks #29 of 56 bookshelf speakers at $856. The Pioneer SP-BS22-LR (Philharmonic AAM Mod) ranks #33 at $168, $688 cheaper.
The case for the ELAC BS U5: This slim three-way coaxial design (an Andrew Jones creation) shows a fairly even on-axis response up to 3kHz, with off-axis behavior notably smoother than the on-axis curve. The tradeoff: Distortion is very high right at both crossover points - around 270Hz (mid-range) and 2700Hz (tweeter) - at both 86dB and 96dB SPL/1m, exceeding 3% at the mid-range crossover.
What the Pioneer SP-BS22-LR (Philharmonic AAM Mod) gets right: This is Dennis Murphy’s “Affordable Accuracy Monitor” (AAM) mod of the discontinued. The catch: Some directivity error appears near the crossover frequency.
Buy the ELAC BS U5 if sound quality matters more than the price. Buy the Pioneer SP-BS22-LR (Philharmonic AAM Mod) if the price matters more than sound quality.
Specifications Side By Side
| ELAC BS U5 | Pioneer SP-BS22-LR (Philharmonic AAM Mod) | |
|---|---|---|
| Price | $856 Discontinued | $168 |
| Ranked | #29 of 56 in Medium Size Bookshelf Speakers | #33 of 56 in Medium Size Bookshelf Speakers |
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) | 78Hz (measured, Audio Science Review) |
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) | 60Hz (measured, Audio Science Review) |
| Drivers | 1" tweeter + 5.25" woofer | 1x 4" curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1" silk dome tweeter (replacement) |
| Discontinued | Yes | - |
| Weight | 13.2 lbs / 6 kg | 9 lbs / 4.1 kg |
| Sensitivity | 83dB (2.83V/1m, measured, Audio Science Review) | 83dB (2.83V/1m, measured by Audio Science Review) |
| Impedance | 4 ohms nominal (3.4 ohms minimum) | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) |
| Dimensions | 13.4"H x 7"W x 11.5"D (339.1 x 178.0 x 293.1 mm) | 12.6"H x 7.1"W x 8.5"D (320.0 x 180.0 x 215.0 mm) |
| Woofer Cabinet | ported, rear | ported, rear |
| Crossover Frequency | - | 3000Hz |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- Sony SS-CS5 M2 vs Dynaudio Emit M10
- Dynaudio Emit M10 vs JBL Stage A120
- Boston Acoustics A25 vs Dynaudio Emit M10
- ELAC BS U5 vs Micca RB42
- Dynaudio Emit M10 vs Pioneer SP-BS22-LR (Philharmonic AAM Mod)
The Two Speakers In Full
ELAC BS U5: $856 Discontinued
Pros: This slim three-way coaxial design (an Andrew Jones creation) shows a fairly even on-axis response up to 3kHz, with off-axis behavior notably smoother than the on-axis curve. Predicted in-room response looks like it should give good tonality. Vertical directivity is better than average, a benefit of the coaxial layout.
Cons: Distortion is very high right at both crossover points - around 270Hz (mid-range) and 2700Hz (tweeter) - at both 86dB and 96dB SPL/1m, exceeding 3% at the mid-range crossover. Minimum impedance dips to 3.4 ohms with a possible resonance around 500Hz visible in the impedance/phase curve. Discontinued.
Full ELAC BS U5 review and specifications →
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| Dimensions | 13.4"H x 7"W x 11.5"D (339.1 x 178.0 x 293.1 mm) |
| Discontinued | Yes |
| Drivers | 1" tweeter + 5.25" woofer |
| Impedance | 4 ohms nominal (3.4 ohms minimum) |
| Sensitivity | 83dB (2.83V/1m, measured, Audio Science Review) |
| Weight | 13.2 lbs / 6 kg |
| Woofer Cabinet | ported, rear |
As an eBay Partner, we may be compensated if you make a purchase.
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Pioneer SP-BS22-LR (Philharmonic AAM Mod): $168
Pros: This is Dennis Murphy’s “Affordable Accuracy Monitor” (AAM) mod of the discontinued, budget Pioneer SP-BS22-LR: the stock tweeter is swapped for a Peerless BC25TG15 dome and a redesigned 3rd-order crossover is built to match it to the stock 4” woofer. CEA2034 spinorama shows only small variations from a flat on-axis response with some directivity error near the crossover, a marked improvement over the unmodified Pioneer, which the reviewer notes shows much more variation from flat. Distortion at 86dB SPL/1m is reasonably controlled above 200Hz, and tweeter distortion barely rises even at 96dB SPL/1m.
Cons: Some directivity error appears near the crossover frequency. Distortion climbs in the woofer’s range (below 200Hz) at both 86dB and 96dB SPL/1m. Minimum impedance dips to about 5 ohms with a couple of resonance peaks. This is a DIY project, not a finished retail product: Murphy sold ~$168 pre-built pairs for a while but no longer does, so it now requires sourcing a used/discontinued Pioneer SP-BS22-LR pair plus building the crossover and swapping the tweeter yourself. The mod itself is public domain, but there is no current turnkey way to buy this speaker.
Full Pioneer SP-BS22-LR (Philharmonic AAM Mod) review and specifications →
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| Crossover Frequency | 3000Hz |
| Dimensions | 12.6"H x 7.1"W x 8.5"D (320.0 x 180.0 x 215.0 mm) |
| Drivers | 1x 4" curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1" silk dome tweeter (replacement) |
| Impedance | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 83dB (2.83V/1m, measured by Audio Science Review) |
| Weight | 9 lbs / 4.1 kg |
| Woofer Cabinet | ported, rear |
