Yamaha DXR12mkII Review: Rated 4.0/5

Last updated: October 24, 2026

The Yamaha DXR12mkII is rated 4/5 for sound quality, #17 of 83 12-Inch PA Speakers. See all PA & Live Sound rankings for every top pick.

Yamaha DXR12mkII · Editor's rating 4/5, ranked #17 of 83 12-Inch PA Speakers
Check price at Amazon ($899.99 Discontinued) →

Prices on this page were last checked October 24, 2026 at 4:42 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Brand: Yamaha

#17 Yamaha DXR12mkII: $899.99 Discontinued Amazon $899.99 eBay

Newer model: the Yamaha DXR12mkIII, ranked higher, rated 4.1/5, released Jun 2026. It adds Bluetooth, but drops the XLR input and the RCA input. See every Yamaha DXR and CXR generation.

Same family: the Yamaha DXR8mkII (smaller model, rated 4/5), the Yamaha DXR10mkII (smaller model, rated 3.8/5) and the Yamaha DXR15mkII (larger model, rated 3.7/5).

Pros: A proven 12 inch PA workhorse with good sound, loud output, three input channels and easy processing presets. A proven, broadly distributed workhorse with a flexible three-channel input section and 134dB claimed maximum output. Medium-quality vendor Spinorama data and 61Hz measured extension provide more evidence than many PA competitors, while Yamaha’s FIR-X processing and D-CONTOUR presets simplify setup. Measured bass extension of 61Hz (-3dB).

Cons: The 5.49 ideal-subwoofer preference score is only mid-pack, with meaningful response/directivity irregularity in the supplied data. It lacks app control and Bluetooth audio, and newer competitors offer more user-adjustable DSP. Discontinued.

ReleasedMay 2022 (4 years ago)
AES InputNo
Amplifier Power1100W dynamic / 700W continuous (950W LF + 150W HF dynamic)
Aux InputNo
Bass Extension (-3dB)61Hz (measured, vendor Spinorama data)
BluetoothNo
Cabinet MaterialMatte-finish ABS
Coaxial InputNo
ConfigurationActive 2-way bass-reflex PA speaker
Coverage90° x 60°
DSPYes
Dimensions23.7”H x 14.3”W x 13.8”D (601 x 362 x 350 mm)
Drivers12” woofer, 1.75” compression driver
Frequency Response52Hz - 20kHz (manufacturer specified)
Guitar InputNo
HDMI InputNo
Inputs2 x XLR/TRS combo, stereo RCA
Maximum SPL134dB peak (manufacturer specified)
Microphone InputNo
Optical InputNo
PassiveNo
RCA InputYes
Rigging3 x M10 points; 35mm dual-angle pole mount
Spinorama Preference Score2.78
Spinorama Preference Score with Perfect Sub5.49
TRS InputYes
USB InputNo
Weight41 lbs (18.6 kg)
XLR InputYes
Check current price at Amazon ($899.99) →Search eBay for Yamaha DXR12mkII →

Frequency Response

How the Yamaha DXR12mkII measures across the audible range. A flatter listening window (the sound arriving straight at you) is more neutral: peaks sound forward or harsh, dips sound recessed. The estimated in-room response adds what a typical room does, and there a gentle, even tilt down toward the treble is ideal. Both curves are shifted so their 300 Hz to 3 kHz average sits at 0 dB.

Listening windowEstimated in-room response
Measured frequency response of the Yamaha DXR12mkII-24-18-12-60+6dB20501002005001k2k5k10k20k

Measurement data: spinorama.org, measured by the manufacturer.

EQ for a Neutral Response

No EQ preset: the best simple EQ we can fit to these measurements improves the predicted preference score by less than 0.2. The listening window is already close to flat, and what holds the score back, such as narrow ripple in the response or uneven output off-axis, is not something EQ can fix without making it worse elsewhere.
