Short answer: choose between the HK Audio LINEAR 7 112 XA and Yamaha DXR12mkII for the deployment, not from the automatic ranking alone. Their driver format, power requirements, coverage, bass reach, output capability, and control features determine which is the more practical PA for a particular room or system. The Yamaha DXR12mkII is discontinued; its replacement is the Yamaha DXR12mkIII. If you are buying new, get the Yamaha DXR12mkIII.
The case for the HK Audio LINEAR 7 112 XA. High-quality vendor data gives it a 5.66 ideal-subwoofer preference score, and networked 10-band parametric EQ, delay and filtering support sophisticated system tuning. Its rotatable horn and monitor enclosure are flexible for stage or main use.
The case for the Yamaha DXR12mkII. A proven, broadly distributed workhorse with a flexible three-channel input section and 134dB claimed maximum output. Medium-quality vendor Spinorama data and 61Hz measured extension provide more evidence than many PA competitors, while Yamaha’s FIR-X processing and D-CONTOUR presets simplify setup.
Important trade-offs. At 46.3 lbs (21 kg) it is manageable but not especially light. The 5.49 ideal-subwoofer preference score is only mid-pack, with meaningful response/directivity irregularity in the supplied data. It lacks app control and Bluetooth audio, and newer competitors offer more user-adjustable DSP.
Buy the HK Audio LINEAR 7 112 XA when its stated format, coverage, and system features fit the job better.
Buy the Yamaha DXR12mkII when its stated output, control, and deployment strengths better match the system.
Want more options? Browse the full PA & Live Sound rankings.
A good sounding 12 inch powered PA speaker with networked EQ and delay and a rotatable horn for stage monitor or main use.
A proven 12 inch PA workhorse with good sound, loud output, three input channels and easy processing presets.
Prices on this page were last checked October 23, 2026 at 8:27 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Specifications Side By Side
| HK Audio LINEAR 7 112 XA | Yamaha DXR12mkII | |
|---|---|---|
| Price | $2,043.57 | $864.99 Discontinued |
| Ranked | #14 of 83 in 12-Inch PA Speakers | #17 of 83 in 12-Inch PA Speakers |
| Passive | No | No |
| Configuration | Active 2-way bass-reflex PA speaker/monitor | Active 2-way bass-reflex PA speaker |
| Drivers | 12” woofer, 1” compression driver | 12” woofer, 1.75” compression driver |
| Frequency Response | 67Hz - 19kHz (±3dB, manufacturer specified); 62Hz - 20kHz (-10dB) | 52Hz - 20kHz (manufacturer specified) |
| Dimensions | 26.4”H x 14.6”W x 12.2”D (670 x 370 x 310 mm) | 23.7”H x 14.3”W x 13.8”D (601 x 362 x 350 mm) |
| Crossover Frequency | 1.6kHz FIR (60dB/octave, manufacturer specified) | - |
| Amplifier Power | 2,000W peak (Class D bi-amped, manufacturer specified) | 1100W dynamic / 700W continuous (950W LF + 150W HF dynamic) |
| Cabinet Material | Hybrid birch multiplex/MDF | Matte-finish ABS |
| Rigging | M8 rigging points; DuoTilt 3°/7° pole mount | 3 x M10 points; 35mm dual-angle pole mount |
| Network Control | EtherCON input/thru; DSP CONTROL software | - |
| Bass Extension (-3dB) | 90Hz (measured, vendor Spinorama data) | 61Hz (measured, vendor Spinorama data) |
| Coverage | 70° x 50°, rotatable | 90° x 60° |
| Maximum SPL | 131dB peak (manufacturer specified) | 134dB peak (manufacturer specified) |
| Inputs | XLR/TRS combo, XLR thru/DSP out, EtherCON network | 2 x XLR/TRS combo, stereo RCA |
| DSP | Yes, networked 10-band PEQ, filters, delay and limiter | Yes |
| Bluetooth | No | No |
| Weight | 46.3 lbs (21 kg) | 41 lbs (18.6 kg) |
| Spinorama Preference Score | 2.40 | 2.78 |
| Spinorama Preference Score with Perfect Sub | 5.66 | 5.49 |
| XLR Input | Yes | Yes |
| RCA Input | No | Yes |
| TRS Input | Yes | Yes |
| Optical Input | No | No |
| Coaxial Input | No | No |
| USB Input | No | No |
| HDMI Input | No | No |
| AES Input | No | No |
| Aux Input | No | No |
| Microphone Input | No | No |
| Guitar Input | No | No |
Frequency Response Compared
Both speakers’ spinorama measurements, overlaid. A flatter line is more neutral: peaks sound forward or harsh, dips sound recessed. Each curve is shifted so its average from 300 Hz to 3 kHz sits at 0 dB, so loudness differences between the two are removed and only the shape is compared.
Measurement data: HK Audio LINEAR 7 112 XA (measured by the manufacturer) and Yamaha DXR12mkII (measured by the manufacturer), via spinorama.org.
