Short answer: choose between the Yamaha DXR12mkII and RCF HD 12-A MK5 for the requirements of the venue and system, not from rank alone. In this size class, coverage, bass extension, output capability, DSP, cabinet construction, and service support often decide the better fit. The Yamaha DXR12mkII has been replaced by the Yamaha DXR12mkIII. If you are buying new, get the Yamaha DXR12mkIII.
Why choose the Yamaha DXR12mkII. A proven, broadly distributed workhorse with a flexible three-channel input section and 134dB claimed maximum output. Medium-quality vendor Spinorama data and 61Hz measured extension provide more evidence than many PA competitors, while Yamaha’s FIR-X processing and D-CONTOUR presets simplify setup.
Why choose the RCF HD 12-A MK5. Medium-quality vendor data indicates useful extension into the low 60Hz region.
What to weigh before buying. The 5.49 ideal-subwoofer preference score is only mid-pack, with meaningful response/directivity irregularity in the supplied data. It lacks app control and Bluetooth audio, and newer competitors offer more user-adjustable DSP. The truncated Spinorama measurement cannot produce a preference score, so tonal confidence is lower than for the fully scored leaders. Controls are intentionally simple and omit app control, networking and a multi-input mixer.
Buy the Yamaha DXR12mkII when its stated coverage, output, processing, and deployment format best match the job.
Buy the RCF HD 12-A MK5 when its stated strengths are the better match for the room and the rest of the PA.
Want more options? Browse the full PA & Live Sound rankings.
A proven 12 inch PA workhorse with good sound, loud output, three input channels and easy processing presets.
An affordable powered 12 inch PA speaker with loud output, simple controls, and onboard processing that keeps bass tidy.
Prices on this page were last checked October 23, 2026 at 8:27 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Specifications Side By Side
| Yamaha DXR12mkII | RCF HD 12-A MK5 | |
|---|---|---|
| Price | $864.99 Discontinued | $600.00 Discontinued |
| Ranked | #17 of 83 in 12-Inch PA Speakers | #44 of 83 in 12-Inch PA Speakers |
| Passive | No | No |
| Configuration | Active 2-way bass-reflex PA speaker | Active 2-way bass-reflex PA speaker |
| Drivers | 12” woofer, 1.75” compression driver | 12” woofer, 1.4” compression driver |
| Frequency Response | 52Hz - 20kHz (manufacturer specified) | 45Hz - 20kHz (manufacturer specified) |
| Dimensions | 23.7”H x 14.3”W x 13.8”D (601 x 362 x 350 mm) | 25.5”H x 15”W x 15”D (647 x 380 x 380 mm) |
| Amplifier Power | 1100W dynamic / 700W continuous (950W LF + 150W HF dynamic) | 1400W peak / 700W RMS (1000W LF + 400W HF peak) |
| Cabinet Material | Matte-finish ABS | PP composite |
| Rigging | 3 x M10 points; 35mm dual-angle pole mount | 2 x M10 inserts; 35mm pole mount |
| Bass Extension (-3dB) | 61Hz (measured, vendor Spinorama data) | 63Hz (measured, vendor Spinorama data) |
| Coverage | 90° x 60° | 90° x 60° |
| Maximum SPL | 134dB peak (manufacturer specified) | 130dB peak (manufacturer specified) |
| Inputs | 2 x XLR/TRS combo, stereo RCA | XLR/TRS combo input and XLR link |
| DSP | Yes | Yes, FiRPHASE and Bass Motion Control |
| Bluetooth | No | No |
| Weight | 41 lbs (18.6 kg) | 40.3 lbs (18.3 kg) |
| Spinorama Preference Score | 2.78 | - |
| Spinorama Preference Score with Perfect Sub | 5.49 | - |
| XLR Input | Yes | Yes |
| RCA Input | Yes | No |
| TRS Input | Yes | Yes |
| Optical Input | No | No |
| Coaxial Input | No | No |
| USB Input | No | No |
| HDMI Input | No | No |
| AES Input | No | No |
| Aux Input | No | No |
| Microphone Input | No | No |
| Guitar Input | No | No |
| Crossover Frequency | - | 1800Hz |
Frequency Response Compared
Both speakers’ spinorama measurements, overlaid. A flatter line is more neutral: peaks sound forward or harsh, dips sound recessed. Each curve is shifted so its average from 300 Hz to 3 kHz sits at 0 dB, so loudness differences between the two are removed and only the shape is compared.
Measurement data: Yamaha DXR12mkII (measured by the manufacturer) and RCF HD 12-A MK5 (measured by the manufacturer), via spinorama.org.
