The DIYSG HT-10 ranks #150 out of 197 total Large Size Bookshelf Speakers for sound quality. See all Passive Home rankings for every top pick.
Brand: DIYSG
Prices on this page were last checked October 7, 2026 at 9:25 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#150 DIYSG HT-10: $496 per pair DIY Sound Group eBay
Same family: the DIYSG HT-8 (smaller bookshelf, ranked lower, rated 2.9/5) and the DIYSG HT-12 (larger bookshelf, ranked higher, rated 3.5/5).
Pros: A distinct kit design from DIY Sound Group’s HTM-12 v2, a 10” ported LCR/surround box built around a Celestion woofer and compression tweeter. Sound-power smoothness of 0.197 is solid for a budget DIY kit. Measured bass extension of 73.4Hz (-3dB), with a measured sensitivity of 91.3dB.
Cons: On-axis deviation of 0.537dB is rough, with a pronounced -0.43dB per octave downward tilt giving it a notably dark tonal character, a somewhat resonant bass-alignment Q of 1.76, and the Harman in-room bass extension estimate is a modest 56Hz for a 10” woofer. It ships as a flat-pack cabinet kit requiring assembly, sold in a minimum order of two units.
| Bass Extension (-3dB) | 73.4Hz (measured, spinorama.org) |
|---|---|
| Country | United States (kit design) |
| DIY Kit | Yes |
| Dimensions | 15W x 19.5H x 9D in |
| Drivers | Celestion TF1020 10” woofer, Celestion CDX1-1445DA compression tweeter |
| Enclosure | Ported, MDF flat-pack cabinet kit |
| Impedance | 8 ohms |
| Sensitivity | 91.3dB (measured average 300Hz-3kHz @ 2.83V/1m, spinorama.org); 95dB manufacturer specified |
| Spinorama Preference Score | 4.26 |
| Spinorama Preference Score with Perfect Sub | 6.80 |
| Weight | approx. 28 lbs (12.7 kg) assembled |
