The HiVi DIY 3.1A ranks #95 out of 221 total Large Size Bookshelf Speakers for sound quality. See all Passive Home rankings for every top pick.
Brand: HiVi
Prices on this page were last checked October 14, 2026 at 2:38 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#95 HiVi DIY 3.1A: $249.99 per pair Amazon $249.99 eBay
Pros: A three-way speaker kit with a ribbon tweeter, a dome midrange and a 6.5-inch Kevlar woofer that Audio Science Review measured at 5.60, or 7.54 with an ideal subwoofer, outstanding for its price and higher than HiVi’s ready-made HiVi Swan X3. Bass reaches 55.7Hz at -3dB. Measured bass extension of 55.7Hz (-3dB).
Cons: A kit you assemble yourself, and the matching cabinets are sold separately (about $160 a pair). Directivity is uneven (4.12dB variation in the directivity index).
| Bass Extension (-10dB) | about 39.5Hz (derived, log-interpolated between spinorama.org -9dB/-12dB points) |
|---|---|
| Bass Extension (-3dB) | 55.7Hz (measured, Audio Science Review) |
| DIY Kit | Yes |
| Drivers | Isodynamic ribbon tweeter, soft dome midrange, 6.5” Kevlar mid-bass (3-way kit) |
| Spinorama Preference Score | 5.60 (spinorama.org) |
| Spinorama Preference Score with Perfect Sub | 7.54 (spinorama.org) |
| Woofer Cabinet | ported |
- Reviews, Comparisons and Sound Samples
Frequency Response
How the HiVi DIY 3.1A measures across the audible range. A flatter listening window (the sound arriving straight at you) is more neutral: peaks sound forward or harsh, dips sound recessed. The estimated in-room response adds what a typical room does, and there a gentle, even tilt down toward the treble is ideal. Both curves are shifted so their 300 Hz to 3 kHz average sits at 0 dB.
Measurement data: spinorama.org, measured by Audio Science Review.
EQ for a Neutral Response
Flattens the measured listening window from the HiVi DIY 3.1A's own bass extension up to 16 kHz. Set a preamp of -3.5 dB, then add these filters to any parametric equalizer in the signal path: the speaker's app or DSP if it has parametric EQ, a miniDSP, Equalizer APO or Wavelet. Boosts are kept to 3 dB, and EQ cannot fix how evenly the speaker spreads sound off-axis, which is why some speakers gain more than others. Predicted preference score with this EQ: 5.9, up from 5.6 (7.8 with an ideal subwoofer, up from 7.5). Calculated by Speaker Ranking from the spinorama measurements above.
| Filter | Frequency | Gain | Q |
|---|---|---|---|
| High shelf | 8,000 Hz | +0.5 dB | 0.70 |
| Peak | 294 Hz | +2.1 dB | 2.15 |
| Peak | 831 Hz | -1.6 dB | 2.38 |
| Peak | 14,820 Hz | +2.9 dB | 3.26 |
