Coverage note. Speaker Ranking currently covers 7 DIYSG models across passive speakers. These are the products in our database, not a complete list of everything DIYSG makes.
What this page covers. The DIYSG models ranked here span passive speakers, including DIYSG HTM-12 v2, DIYSG HTM-12 v1 and DIYSG HT-12. Use each model’s category position to compare it with alternatives of the same size and use case.
This page lists all 7 DIYSG speakers ranked on this site across passive speakers. Each model is shown in the category where it competes, with its current rank and the size of that ranking.
Use the category position rather than the brand name alone: speakers from the same manufacturer can perform very differently by size, price and product family.
Prices on this page were last checked October 15, 2026 at 5:41 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Quick Navigation
Large Size Bookshelf Speakers
Ranked #168 of 222 in Large Size Bookshelf Speakers - DIYSG HT-10: $496 per pair DIY Sound Group $248 eBay
Same family: the DIYSG HT-8 (smaller bookshelf, ranked lower, rated 2.9/5) and the DIYSG HT-12 (larger bookshelf, ranked higher, rated 3.5/5).
Pros: A distinct kit design from DIYSG HTM-12 v2, a 10” ported LCR/surround box built around a Celestion woofer and compression tweeter. Sound-power smoothness of 0.197 is solid for a budget DIY kit. Measured bass extension of 73.4Hz (-3dB), with a measured sensitivity of 91.3dB.
Cons: On-axis deviation of 0.537dB is rough, with a pronounced -0.43dB per octave downward tilt giving it a notably dark tonal character, a somewhat resonant bass-alignment Q of 1.76, and the Harman in-room bass extension estimate is a modest 56Hz for a 10” woofer. It ships as a flat-pack cabinet kit requiring assembly, sold in a minimum order of two units.
Full DIYSG HT-10 review and specifications →
| Bass Extension (-10dB) | about 44.9Hz (measured, Spinorama data) |
|---|---|
| Bass Extension (-3dB) | 73.4Hz (measured, spinorama.org) |
| Country | United States (kit design) |
| DIY Kit | Yes |
| Dimensions | 15W x 19.5H x 9D in |
| Drivers | Celestion TF1020 10” woofer, Celestion CDX1-1445DA compression tweeter |
| Enclosure | Ported, MDF flat-pack cabinet kit |
| Impedance | 8 ohms |
| Sensitivity | 91.3dB (measured average 300Hz-3kHz @ 2.83V/1m, spinorama.org); 95dB manufacturer specified |
| Spinorama Preference Score | 4.26 |
| Spinorama Preference Score with Perfect Sub | 6.80 |
| Weight | approx. 28 lbs (12.7 kg) assembled |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Ranked #205 of 222 in Large Size Bookshelf Speakers - DIYSG Volt-8 v2: $300 per pair kit eBay
Same family: the DIYSG Volt-6 (smaller bookshelf, ranked lower, rated 2.3/5).
Pros: A DIY kit from DIY Sound Group built around an 8” coaxial driver. Erin measured a preference score of 1.81 that reaches 4.56 with an ideal subwoofer, with 0.70 listening window deviation. Measured bass extension of 90.8Hz (-3dB).
Cons: Bass rolls off early and the on-axis response is uneven (0.94 average deviation). It is a kit to build yourself. Bass reaches 90.8Hz (-3dB) and about 57Hz (-10dB).
Full DIYSG Volt-8 v2 review and specifications →
| Bass Extension (-10dB) | about 57.1Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 90.8Hz (measured, Erin’s Audio Corner) |
| DIY Kit | Yes |
| Drivers | 8” coaxial driver |
| Impedance | 8 ohms nominal (manufacturer specified) |
| Sensitivity | 94dB (manufacturer specified) |
| Spinorama Preference Score | 1.81 |
| Spinorama Preference Score with Perfect Sub | 4.56 |
| Weight | 22.9 lbs (10.4 kg) |
- Reviews, Comparisons and Sound Samples
Ranked #215 of 222 in Large Size Bookshelf Speakers - DIYSG Volt-6: $300 per pair kit eBay
Same family: the DIYSG Volt-8 v2 (larger bookshelf, ranked higher, rated 2.6/5).
Pros: A DIY kit from DIY Sound Group built around a 6.5” coaxial driver. Erin measured a preference score of 0.26 that reaches 3.97 with an ideal subwoofer, with 0.87 listening window deviation. Measured bass extension of 124.5Hz (-3dB).
Cons: Bass rolls off early and the on-axis response is less even (0.80 average deviation). It is a kit to build yourself. Bass reaches 124.5Hz (-3dB) and about 83Hz (-10dB).
Full DIYSG Volt-6 review and specifications →
| Bass Extension (-10dB) | about 83.3Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 124.5Hz (measured, Erin’s Audio Corner) |
| DIY Kit | Yes |
| Drivers | 6.5” coaxial driver |
| Spinorama Preference Score | 0.26 |
| Spinorama Preference Score with Perfect Sub | 3.97 |
- Reviews, Comparisons and Sound Samples
Discontinued DIYSG Models
Still ranked, and often still worth buying used, but no longer in production. Check availability before planning around one of these.
Large Size Bookshelf Speakers
Ranked #14 of 222 in Large Size Bookshelf Speakers - DIYSG HTM-12 v2: $920 per pair per kit Discontinued DIY Sound Group eBay
Older model: the DIYSG HTM-12 v1 (ranked lower, rated 3.8/5). See every DIYSG HTM-12 generation.
Pros: Purpose-built high-output cinema kit pairing a 12-inch woofer with a compression driver in a large SEOS waveguide. Erin measured 91dB/2.83V/1m sensitivity, extraordinarily low distortion (still below 1% to about 60Hz at 102dB) and only about 0.5dB tweeter compression at the same level. Horizontal directivity is consistent and crossover integration is unusually good, so response corrections remain EQ-friendly. The benign impedance curve can be driven by many capable AVRs. Measured bass extension of 67Hz (-3dB), with a measured sensitivity of 91dB.
Cons: Erin measured F3 at approximately 67Hz, the normal efficiency/bass-extension tradeoff of a high-sensitivity 12-inch design, so a subwoofer is mandatory. A few narrow resonances appear in the response, impedance and decay plots; Erin suggested crossover/component investigation could improve them. Vertical radiation narrows around the crossover, the unfinished kit requires cabinet assembly and finishing, and its broad baffle is visually and physically substantial. Discontinued.
Full DIYSG HTM-12 v2 review and specifications →
| Released | 2020 (6 years ago) |
|---|---|
| Bass Extension (-10dB) | 45Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 67Hz (measured, Erin’s Audio Corner) |
| DIY Kit | Yes |
| Dimensions | 25”H x 18”W x 9.5”D (635 x 457.2 x 241.3 mm) |
| Drivers | 12” woofer; compression driver in SEOS waveguide |
| Impedance | AVR-compatible impedance profile (measured, Erin’s Audio Corner) |
| Sensitivity | 91dB/2.83V/1m (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 3.26 |
| Spinorama Preference Score with Perfect Sub | 5.88 |
| Weight | 39.9 lbs (18.1 kg) assembled |
| Woofer Cabinet | ported |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Ranked #117 of 222 in Large Size Bookshelf Speakers - DIYSG HTM-12 v1: $660 per pair per kit Discontinued eBay
Newer model: the DIYSG HTM-12 v2, ranked higher, rated 4.5/5, released 2020 (also discontinued). See every DIYSG HTM-12 generation.
Pros: A high-output home theater kit with a 12” Eminence Deltalite woofer and a Denovo DNA-325 compression driver in a SEOS-15 waveguide. Erin measured about 94dB sensitivity and the lowest distortion and compression he had measured at the time, so it plays very loud cleanly. Measured bass extension of 78Hz (-3dB), with a measured sensitivity of 94dB.
Cons: A dip around 3kHz makes voices sound less natural and calls for EQ, and the radiation pattern changes with frequency, for a preference score of 2.59 that reaches 5.38 with an ideal subwoofer. Bass rolls off early, 78Hz (-3dB) and 53Hz (-10dB), so it needs a subwoofer. It is a kit: the cabinet must be built or bought separately. DIYSG replaced it with the DIYSG HTM-12 v2. Discontinued.
Full DIYSG HTM-12 v1 review and specifications →
| Released | 2017 (9 years ago) |
|---|---|
| Bass Extension (-10dB) | 53Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 78Hz (measured, Erin’s Audio Corner) |
| DIY Kit | Yes |
| Drivers | 12” Eminence Deltalite woofer; Denovo DNA-325 compression driver in SEOS-15 waveguide |
| Sensitivity | 94dB/2.83V/1m (measured average, Erin’s Audio Corner) |
| Spinorama Preference Score | 2.59 |
| Spinorama Preference Score with Perfect Sub | 5.38 |
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Ranked #152 of 222 in Large Size Bookshelf Speakers - DIYSG HT-12: $330 per pair kit Discontinued eBay
Same family: the DIYSG HT-8 (smaller bookshelf, ranked lower, rated 2.9/5) and the DIYSG HT-10 (smaller bookshelf, ranked lower, rated 3.3/5).
Pros: A DIY home theater kit with a 12” woofer and a compression driver on a waveguide, built for high output. Measurements show a preference score of 3.73 that reaches 6.55 with an ideal subwoofer, with 0.43 listening window deviation. Measured bass extension of 74.4Hz (-3dB).
Cons: It is a kit to build yourself and is no longer listed by DIY Sound Group. Bass reaches 74.4Hz (-3dB) and about 47Hz (-10dB). That data is low quality.
Full DIYSG HT-12 review and specifications →
| Bass Extension (-10dB) | about 46.7Hz (measured, third-party data via spinorama.org) |
|---|---|
| Bass Extension (-3dB) | 74.4Hz (measured, third-party data via spinorama.org) |
| DIY Kit | Yes |
| Dimensions | 25”H x 18”W x 9.5”D (635 x 457 x 241 mm) |
| Drivers | 12” woofer, compression driver on waveguide |
| Impedance | 8 ohms nominal (manufacturer specified) |
| Sensitivity | 96dB (manufacturer specified) |
| Spinorama Preference Score | 3.73 |
| Spinorama Preference Score with Perfect Sub | 6.55 |
| Weight | 39.9 lbs (18.1 kg) |
- Reviews, Comparisons and Sound Samples
Ranked #193 of 222 in Large Size Bookshelf Speakers - DIYSG HT-8: $164 per pair kit Discontinued eBay
Same family: the DIYSG HT-10 (larger bookshelf, ranked higher, rated 3.3/5) and the DIYSG HT-12 (larger bookshelf, ranked higher, rated 3.5/5).
Pros: A DIY home theater kit from DIY Sound Group with an 8” woofer and a compression driver on a waveguide, built for high output. Measurements show a preference score of 2.37 that reaches 6.18 with an ideal subwoofer, with 0.44 listening window deviation. Measured bass extension of 138.5Hz (-3dB).
Cons: The on-axis response is very uneven (2.18 average deviation). It is a kit to build yourself and DIY Sound Group no longer lists it. Bass reaches 138.5Hz (-3dB) and about 60Hz (-10dB). That data is low quality. Discontinued.
Full DIYSG HT-8 review and specifications →
| Bass Extension (-10dB) | about 60.2Hz (measured, third-party data via spinorama.org) |
|---|---|
| Bass Extension (-3dB) | 138.5Hz (measured, third-party data via spinorama.org) |
| DIY Kit | Yes |
| Dimensions | 16.7”H x 12.5”W x 7.5”D (425 x 318 x 191 mm) |
| Drivers | 8” woofer, compression driver on waveguide |
| Impedance | 8 ohms nominal (manufacturer specified) |
| Sensitivity | 94dB (manufacturer specified) |
| Spinorama Preference Score | 2.37 |
| Spinorama Preference Score with Perfect Sub | 6.18 |
| Weight | 20.1 lbs (9.1 kg) |
- Reviews, Comparisons and Sound Samples
