DIYSG HTM-12 v1 Review: Rated 3.8/5

Last updated: October 30, 2026

The DIYSG HTM-12 v1 is rated 3.8/5 for sound quality, #116 of 222 Large Size Bookshelf Speakers. See all Passive Home rankings for every top pick.

DIYSG HTM-12 v1 · Editor's rating 3.8/5, ranked #116 of 222 Large Size Bookshelf Speakers

Prices on this page were last checked November 18, 2026 at 8:41 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Brand: DIYSG

#116 DIYSG HTM-12 v1: $660 per pair per kit Discontinued eBay

Newer model: the DIYSG HTM-12 v2, ranked higher, rated 4.5/5, released 2020 (also discontinued). See every DIYSG HTM-12 generation.

Pros: A high-output home theater kit with a 12 inch woofer and horn that plays very loud with very low distortion. A high-output home theater kit with a 12” Eminence Deltalite woofer and a Denovo DNA-325 compression driver in a SEOS-15 waveguide. Erin measured about 94dB sensitivity and the lowest distortion and compression he had measured at the time, so it plays very loud cleanly. Measured bass extension of 78Hz (-3dB), with a measured sensitivity of 94dB.

Cons: A dip around 3kHz makes voices sound less natural and calls for EQ, and the radiation pattern changes with frequency, for a preference score of 2.59 that reaches 5.38 with an ideal subwoofer. Bass rolls off early, 78Hz (-3dB) and 53Hz (-10dB), so it needs a subwoofer. It is a kit: the cabinet must be built or bought separately. DIYSG replaced it with the DIYSG HTM-12 v2. Discontinued.

Is the DIYSG HTM-12 v1 right for you?

Buy it if

  • you have a modest amplifier (94 dB sensitivity is easy to drive).

Skip it if

  • you want to buy it new: it is discontinued.
Released2017 (9 years ago)
Bass Extension (-10dB)53Hz (measured, Erin’s Audio Corner)
Bass Extension (-3dB)78Hz (measured, Erin’s Audio Corner)
DIY KitYes
Drivers12” Eminence Deltalite woofer; Denovo DNA-325 compression driver in SEOS-15 waveguide
Sensitivity94dB/2.83V/1m (measured average, Erin’s Audio Corner)
Spinorama Preference Score2.59
Spinorama Preference Score with Perfect Sub5.38
