DIYSG HTM-12 v2 vs DIYSG HTM-12 v1

Last updated: October 21, 2026

Bottom line: both are discontinued, so this only matters if you are buying used. Used, the DIYSG HTM-12 v2 is the better pick: it ranks #14 of 222 bookshelf speakers by sound quality (rated 4.5/5), against #116 (rated 3.8/5) for the DIYSG HTM-12 v1. If you want one new, the AsciLab C6B ranks #6 at $1,145.

DIYSG HTM-12 v2 vs DIYSG HTM-12 v1

The DIYSG HTM-12 v2 is the more accurate, deeper-bass pick. A high output home theater kit with a 12 inch woofer and horn tweeter, very low distortion, and an easy load for most receivers. Its measured preference score, a predictor of how neutral it sounds, is 3.26 against 2.59 for the DIYSG HTM-12 v1. Its bass reaches about 67Hz before falling 3dB, against 78Hz for the DIYSG HTM-12 v1. Keep in mind: Erin measured F3 at approximately 67Hz, the normal efficiency/bass-extension tradeoff of a high-sensitivity 12-inch design, so a subwoofer is mandatory.

Where the DIYSG HTM-12 v1 wins: A high-output home theater kit with a 12 inch woofer and horn that plays very loud with very low distortion. The catch: A dip around 3kHz makes voices sound less natural and calls for EQ, and the radiation pattern changes with frequency, for a preference score of 2.59 that reaches 5.38 with an ideal subwoofer.

Buy the DIYSG HTM-12 v2 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, start with the AsciLab C6B instead.

Still deciding? The full Passive Home rankings cover every ranked option.

Measured Differences

Prices on this page were last checked November 18, 2026 at 8:41 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Specifications Side By Side

DIYSG HTM-12 v2 DIYSG HTM-12 v1
Price$920 per pair per kit, Discontinued$660 per pair per kit, Discontinued
Ranked#14 of 222 in Large Size Bookshelf Speakers#116 of 222 in Large Size Bookshelf Speakers
Bass Extension (-10dB)45Hz (measured, Erin’s Audio Corner)53Hz (measured, Erin’s Audio Corner)
Bass Extension (-3dB)67Hz (measured, Erin’s Audio Corner)78Hz (measured, Erin’s Audio Corner)
Sensitivity91dB/2.83V/1m (measured, Erin’s Audio Corner)94dB/2.83V/1m (measured average, Erin’s Audio Corner)
ImpedanceAVR-compatible impedance profile (measured, Erin’s Audio Corner)-
Drivers12” woofer; compression driver in SEOS waveguide12” Eminence Deltalite woofer; Denovo DNA-325 compression driver in SEOS-15 waveguide
Woofer Cabinetported-
Spinorama Preference Score3.262.59
Spinorama Preference Score with Perfect Sub5.885.38
Dimensions25”H x 18”W x 9.5”D (635 x 457.2 x 241.3 mm)-
Weight39.9 lbs (18.1 kg) assembled-
DIY KitYesYes

Where the Ratings Come From

This comparison is generated from the ratings, specifications and measurements on each product’s own page, and it updates when that data changes. How we rank explains how each rating is decided.
