The Revel W226Be is rated 4.2/5 for sound quality, #5 of 28 In-Wall & In-Ceiling Speakers. See all Passive Home rankings for every top pick.
Prices on this page were last checked November 7, 2026 at 7:34 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Brand: Revel
#5 Revel W226Be: $4,949.90 per pair Crutchfield $2,474.95 eBay
Same family: the Revel W126Be (smaller in-wall, ranked higher, rated 4.3/5) and the Revel W228Be (larger in-wall, ranked lower, rated 4.2/5).
Pros: A premium in-wall speaker with twin woofers for deeper bass, a beryllium tweeter, accurate sound and high output. Revel’s own measurement, published on spinorama.org, gives a preference score of 5.51, or 7.60 with a perfect subwoofer. Bass measures to 48.1Hz at -3dB and 43.7Hz at -6dB, deeper than the single-woofer Revel W126Be, and directivity is well controlled (SPDI deviation 1.95dB). Dual 6.5” aluminum cone woofers and a 1” beryllium dome tweeter behind an acoustic lens waveguide give 90dB sensitivity and a rated 110dB maximum output, and it accepts 50-200W of amplifier power. Measured bass extension of 48.1Hz (-3dB).
Cons: The measurement comes from Revel, digitized from its published curves, and has no independent second test, so treat the figures as manufacturer supplied. At $2475 each a stereo pair costs twice that, and the back box is not included and is sold separately. Predicted in-room smoothness (0.81) and on-axis deviation (0.33dB) are good but not ahead of the cheaper Revel W126Be, so the extra cost buys bass and output rather than a cleaner midrange.
Is the Revel W226Be right for you?
Buy it if
- you want measurably neutral sound (preference score 7.6 with a subwoofer).
- you have a modest amplifier (90 dB sensitivity is easy to drive).
Skip it if
- you want the best value: the higher-rated Revel W553L costs about $3,860 less.
| Released | Sep 2023 (3 years ago) |
|---|---|
| Bass Extension (-10dB) | 36.4Hz (measured, Revel vendor data on spinorama.org) |
| Bass Extension (-3dB) | 48.1Hz (measured, Revel vendor data on spinorama.org) |
| Crossover Frequency | 2,000Hz |
| DIY Kit | No |
| Dimensions | 23”H x 10.2”W x 3.8”D (583 x 259 x 96 mm) (88mm mounting depth) |
| Drivers | 2x 6.5” Deep Ceramic Composite (DCC) aluminum cone woofers, 1” beryllium dome tweeter with acoustic lens waveguide (2-way) |
| Enclosure | In-wall, 18-36L enclosure (optional W226BEBB back box sold separately) |
| Frequency Response | 43Hz-40kHz (-6dB, manufacturer) |
| Impedance | 6 ohms nominal (4 ohm minimum) |
| Maximum SPL | 110dB (manufacturer specified) |
| Mounting Cutout | 226W x 549H mm |
| Power Handling | 50-200W RMS at 4 ohms |
| Sensitivity | 90dB |
| Spinorama Preference Score | 5.51 |
| Spinorama Preference Score with Perfect Sub | 7.60 |
| Weight | 15.7 lbs (7.1 kg) |
