The Revel W126Be ranks #3 out of 14 total In-Wall & In-Ceiling Speakers for sound quality. See all Passive Home rankings for every top pick.
Brand: Revel
Prices on this page were last checked September 24, 2026 at 10:28 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
#3 Revel W126Be: $3,849.90 per pair Crutchfield eBay
Pros: Revel’s own measurement, published on spinorama.org, gives a preference score of 5.39, or 7.97 with a perfect subwoofer, with a smooth predicted in-room response (0.85 smoothness). Directivity is tightly controlled (SPDI deviation 2.01dB) and on-axis deviation averages only 0.34dB. Bass measures to 62.6Hz at -6dB. It pairs a 1” beryllium dome tweeter and acoustic lens waveguide with a 6.5” aluminum cone woofer, rated at 89dB sensitivity and 105dB maximum output. Measured bass extension of 89.7Hz (-3dB).
Cons: The measurement comes from Revel, digitized from its published curves, and has no independent second test, so treat the figures as manufacturer supplied. Bass is limited, with -3dB at 89.7Hz, so a subwoofer is needed for full range sound. At $1925 each a stereo pair costs twice that, and the optional back box is sold separately. A single 6.5” woofer gives less output than the dual-woofer W226Be.
How it compares: Just above it: Revel W553L - $1380 cheaper, 1Hz higher bass extension (-3dB). Just below it: Revel W226Be - $550 more, 1Hz higher bass extension (-3dB).
| Bass Extension (-10dB) | 42.5Hz (measured, Revel vendor data on spinorama.org) |
|---|---|
| Bass Extension (-3dB) | 89.7Hz (measured, Revel vendor data on spinorama.org) |
| Crossover Frequency | 2,100Hz |
| DIY Kit | No |
| Dimensions | 15.6”H x 10.2”W x 3.8”D (395 x 260 x 97 mm) (88.7mm mounting depth) |
| Drivers | 6.5” Deep Ceramic Composite (DCC) aluminum cone woofer, 1” beryllium dome tweeter with acoustic lens waveguide (2-way) |
| Enclosure | In-wall, 9-18L enclosure (optional W126BEBB back box sold separately) |
| Frequency Response | 55Hz-40kHz (-6dB, manufacturer) |
| Impedance | 6 ohms nominal (4 ohm minimum) |
| Maximum SPL | 105dB (manufacturer specified) |
| Mounting Cutout | 226W x 357H mm |
| Power Handling | 50-150W RMS at 4 ohms |
| Sensitivity | 89dB |
| Spinorama Preference Score | 5.39 |
| Spinorama Preference Score with Perfect Sub | 7.97 |
| Weight | 10.4 lbs (4.7 kg) |
