Short answer: the Revel W126Be. It ranks #3 of 18 in-wall speakers by sound quality, rated 4.3/5, at $3,849.90; the Revel W226Be ranks #4, rated 4.2/5, and costs $4,949.90, which makes this an easy call rather than a real tradeoff.
What the Revel W126Be does well: Revel’s own measurement, published on spinorama.org, gives a preference score of 5.39, or 7.97 with a perfect subwoofer, with a smooth predicted in-room response (0.85 smoothness). The tradeoff: The measurement comes from Revel, digitized from its published curves, and has no independent second test, so treat the figures as manufacturer supplied.
What the Revel W226Be does well: Revel’s own measurement, published on spinorama.org, gives a preference score of 5.51, or 7.60 with a perfect subwoofer. Watch for: The measurement comes from Revel, digitized from its published curves, and has no independent second test, so treat the figures as manufacturer supplied.
Buy the Revel W126Be. It is rated higher for sound quality than the Revel W226Be and costs less, so it is the default pick unless a specific strength of the other one matters more to you.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| Revel W126Be | Revel W226Be | |
|---|---|---|
| Price | $3,849.90 per pair | $4,949.90 per pair |
| Ranked | #3 of 18 in In-Wall & In-Ceiling Speakers | #4 of 18 in In-Wall & In-Ceiling Speakers |
| Drivers | 6.5” Deep Ceramic Composite (DCC) aluminum cone woofer, 1” beryllium dome tweeter with acoustic lens waveguide (2-way) | 2x 6.5” Deep Ceramic Composite (DCC) aluminum cone woofers, 1” beryllium dome tweeter with acoustic lens waveguide (2-way) |
| Enclosure | In-wall, 9-18L enclosure (optional W126BEBB back box sold separately) | In-wall, 18-36L enclosure (optional W226BEBB back box sold separately) |
| Mounting Cutout | 226W x 357H mm | 226W x 549H mm |
| Dimensions | 15.6”H x 10.2”W x 3.8”D (395 x 260 x 97 mm) (88.7mm mounting depth) | 23”H x 10.2”W x 3.8”D (583 x 259 x 96 mm) (88mm mounting depth) |
| Weight | 10.4 lbs (4.7 kg) | 15.7 lbs (7.1 kg) |
| Sensitivity | 89dB | 90dB |
| Impedance | 6 ohms nominal (4 ohm minimum) | 6 ohms nominal (4 ohm minimum) |
| Power Handling | 50-150W RMS at 4 ohms | 50-200W RMS at 4 ohms |
| Frequency Response | 55Hz-40kHz (-6dB, manufacturer) | 43Hz-40kHz (-6dB, manufacturer) |
| Maximum SPL | 105dB (manufacturer specified) | 110dB (manufacturer specified) |
| Crossover Frequency | 2,100Hz | 2,000Hz |
| Bass Extension (-3dB) | 89.7Hz (measured, Revel vendor data on spinorama.org) | 48.1Hz (measured, Revel vendor data on spinorama.org) |
| Bass Extension (-10dB) | 42.5Hz (measured, Revel vendor data on spinorama.org) | 36.4Hz (measured, Revel vendor data on spinorama.org) |
| Spinorama Preference Score | 5.39 | 5.51 |
| Spinorama Preference Score with Perfect Sub | 7.97 | 7.60 |
| DIY Kit | No | No |
Related Speaker Comparisons
How Revel W126Be compares with other leading options:
- KEF Ci3160RLM-THX vs Revel W126Be
- Revel W553L vs Revel W126Be
- Revel W126Be vs JBL Synthesis SCL-6
- Revel W226Be vs Miller & Kreisel IW150
- Revel W226Be vs KEF CI250RRM-THX
Prices on this page were last checked September 26, 2026 at 11:14 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel W126Be: $3,849.90 per pair Crutchfield eBay
Pros: Revel’s own measurement, published on spinorama.org, gives a preference score of 5.39, or 7.97 with a perfect subwoofer, with a smooth predicted in-room response (0.85 smoothness). Directivity is tightly controlled (SPDI deviation 2.01dB) and on-axis deviation averages only 0.34dB. Bass measures to 62.6Hz at -6dB. It pairs a 1” beryllium dome tweeter and acoustic lens waveguide with a 6.5” aluminum cone woofer, rated at 89dB sensitivity and 105dB maximum output. Measured bass extension of 89.7Hz (-3dB).
Cons: The measurement comes from Revel, digitized from its published curves, and has no independent second test, so treat the figures as manufacturer supplied. Bass is limited, with -3dB at 89.7Hz, so a subwoofer is needed for full range sound. At $1925 each a stereo pair costs twice that, and the optional back box is sold separately. A single 6.5” woofer gives less output than the dual-woofer W226Be.
Full Revel W126Be review and specifications →
| Bass Extension (-10dB) | 42.5Hz (measured, Revel vendor data on spinorama.org) |
|---|---|
| Bass Extension (-3dB) | 89.7Hz (measured, Revel vendor data on spinorama.org) |
| Crossover Frequency | 2,100Hz |
| DIY Kit | No |
| Dimensions | 15.6”H x 10.2”W x 3.8”D (395 x 260 x 97 mm) (88.7mm mounting depth) |
| Drivers | 6.5” Deep Ceramic Composite (DCC) aluminum cone woofer, 1” beryllium dome tweeter with acoustic lens waveguide (2-way) |
| Enclosure | In-wall, 9-18L enclosure (optional W126BEBB back box sold separately) |
| Frequency Response | 55Hz-40kHz (-6dB, manufacturer) |
| Impedance | 6 ohms nominal (4 ohm minimum) |
| Maximum SPL | 105dB (manufacturer specified) |
| Mounting Cutout | 226W x 357H mm |
| Power Handling | 50-150W RMS at 4 ohms |
| Sensitivity | 89dB |
| Spinorama Preference Score | 5.39 |
| Spinorama Preference Score with Perfect Sub | 7.97 |
| Weight | 10.4 lbs (4.7 kg) |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Revel W226Be: $4,949.90 per pair Crutchfield eBay
Pros: Revel’s own measurement, published on spinorama.org, gives a preference score of 5.51, or 7.60 with a perfect subwoofer. Bass measures to 48.1Hz at -3dB and 43.7Hz at -6dB, deeper than the single-woofer W126Be, and directivity is well controlled (SPDI deviation 1.95dB). Dual 6.5” aluminum cone woofers and a 1” beryllium dome tweeter behind an acoustic lens waveguide give 90dB sensitivity and a rated 110dB maximum output, and it accepts 50-200W of amplifier power. Measured bass extension of 48.1Hz (-3dB).
Cons: The measurement comes from Revel, digitized from its published curves, and has no independent second test, so treat the figures as manufacturer supplied. At $2475 each a stereo pair costs twice that, and the back box is not included and is sold separately. Predicted in-room smoothness (0.81) and on-axis deviation (0.33dB) are good but not ahead of the cheaper W126Be, so the extra cost buys bass and output rather than a cleaner midrange.
Full Revel W226Be review and specifications →
| Bass Extension (-10dB) | 36.4Hz (measured, Revel vendor data on spinorama.org) |
|---|---|
| Bass Extension (-3dB) | 48.1Hz (measured, Revel vendor data on spinorama.org) |
| Crossover Frequency | 2,000Hz |
| DIY Kit | No |
| Dimensions | 23”H x 10.2”W x 3.8”D (583 x 259 x 96 mm) (88mm mounting depth) |
| Drivers | 2x 6.5” Deep Ceramic Composite (DCC) aluminum cone woofers, 1” beryllium dome tweeter with acoustic lens waveguide (2-way) |
| Enclosure | In-wall, 18-36L enclosure (optional W226BEBB back box sold separately) |
| Frequency Response | 43Hz-40kHz (-6dB, manufacturer) |
| Impedance | 6 ohms nominal (4 ohm minimum) |
| Maximum SPL | 110dB (manufacturer specified) |
| Mounting Cutout | 226W x 549H mm |
| Power Handling | 50-200W RMS at 4 ohms |
| Sensitivity | 90dB |
| Spinorama Preference Score | 5.51 |
| Spinorama Preference Score with Perfect Sub | 7.60 |
| Weight | 15.7 lbs (7.1 kg) |
