Short answer: the Revel F226Be for better sound quality, the Klipsch Forte IV for the lower price. The Revel F226Be ranks #9 of 54 floorstanding speakers at $7700. The Klipsch Forte IV ranks #31 at $5499.98, $2200.02 cheaper.
What the Revel F226Be offers: Compact three-way tower with a beryllium dome tweeter in an acoustic lens waveguide, a dedicated 5.25” mid-range, and dual 6.5” woofers (not a coaxial layout) - all Deep Ceramic Composite aluminum cones engineered specifically to… Watch for: Minimum impedance dips to about 3.7-4 ohms below roughly 500Hz despite the 8-ohm nominal rating, so it wants a genuine 4-ohm-capable two-channel amplifier; budget AVRs rated only for 6 or 8 ohms may struggle.
What the Klipsch Forte IV offers: Three-way heritage design: a 1” titanium tweeter and 1.75” compression driver for the midrange mated to a 12” woofer, plus a 15” passive radiator for extra bass reinforcement. Watch for: Contrary to the classic Klipsch reputation for being forward and bright, this model is actually somewhat recessed in the 1.5-4kHz “presence” region, which can make some tracks sound dull or lacking in detail.
Buy the Revel F226Be if sound quality matters more than the price. Buy the Klipsch Forte IV if the price matters more than sound quality.
Specifications Side By Side
| Revel F226Be | Klipsch Forte IV | |
|---|---|---|
| Price | $7700 | $5,499.98 |
| Ranked | #9 of 54 in Large Size Floorstanding Speakers | #31 of 54 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 36Hz (measured, Erin’s Audio Corner) | 39Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 56Hz (measured, Erin’s Audio Corner) | 82Hz (measured, Erin’s Audio Corner) |
| Dimensions | 41.3"H x 9.8"W x 13.7"D (1049 x 248.9 x 348 mm) | 36"H x 16.5"W x 13"D (914.4 x 419.1 x 330.2 mm) |
| Impedance | 8 ohms nominal (3.7 ohms minimum, measured, Erin’s Audio Corner) | 8 ohms |
| Drivers | Two 6.5" (165mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter | 1x 12" (305mm) fiber-composite woofer + 15" passive radiator, 1x 1.75" compression driver midrange on horn, 1x 1" titanium compression tweeter on horn |
| Sensitivity | 89.7dB (measured, Erin’s Audio Corner) | 93.8dB (measured average, Erin’s Audio Corner; manufacturer rates 99dB in-room / ~94dB anechoic) |
| Weight | 58.2 lbs / 26.4 kg each | 117.3 lbs / 53.2 kg |
| Woofer Cabinet | ported, front | passive radiator |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- MoFi SourcePoint 888 vs KEF R5
- Klipsch Heresy IV vs SVS Ultra Evolution Pinnacle
- JBL HDI-3800 vs JBL 4367
- MoFi SourcePoint 888 vs Revel F226Be
- Klipsch Forte IV vs MoFi SourcePoint V10 Master Edition
The Two Speakers In Full
Revel F226Be: $7700 Crutchfield
Pros: Compact three-way tower with a beryllium dome tweeter in an acoustic lens waveguide, a dedicated 5.25” mid-range, and dual 6.5” woofers (not a coaxial layout) - all Deep Ceramic Composite aluminum cones engineered specifically to avoid breakup outside their crossover bands, and it measures that way: neither the woofers nor the mid-range show breakup spikes even well outside their intended pass bands, and even the front port measures unusually clean (only a mild ~3dB bump around 150Hz, well controlled versus the resonances the reviewer typically sees from ports). On-axis frequency response holds within about ±1.5dB above roughly 65Hz - excellent linearity - and off-axis behavior tracks it closely, with only mild, subdued peaking around 4-6kHz that doesn’t show up as real resonance in the spinorama data. Average sensitivity around 90dB (2.83V/1m), notably higher than some competing three-way designs and most bookshelf speakers, translating directly into better dynamic range at both low and high listening levels - one reviewer specifically praised its ability to deliver full transient impact (snare hits, kick drum) even at quiet, conversational volumes rather than needing to be cranked up to feel dynamic. Wide, consistent horizontal radiation of about ±60-70° at the -6dB point, landing right in the reviewer’s preferred range for an enveloping soundstage without excess diffusion, and exceptionally wide vertical dispersion - roughly ±80° up to 10kHz and still ±70° above that, which one reviewer called the widest vertical radiation pattern he had measured to date. Distortion stays under 3% even at 104dB SPL, and in real-world testing up to 105dB from 12-14 feet away, full-range with no crossover, the reviewer heard no audible mechanical noise, port chuffing, or compression at all. Flat enough on- and off-axis response that toeing the speaker 10-15° away from the listener preserves the same tonal balance rather than changing it, and the wide, well-controlled directivity lets sidewall reflections reinforce rather than smear the soundstage.
Cons: Minimum impedance dips to about 3.7-4 ohms below roughly 500Hz despite the 8-ohm nominal rating, so it wants a genuine 4-ohm-capable two-channel amplifier; budget AVRs rated only for 6 or 8 ohms may struggle. F3 of 56Hz and F10 of 36Hz mean it doesn’t extend nearly as low as some three-way rivals with larger woofers - a dedicated subwoofer (10-12”, or 15” for content below 30Hz) is recommended for home theater or bass-heavy music, even though the speaker itself can play surprisingly loud without one. Vertical directivity tolerance is tighter in the crossover handoff region than a true coaxial design would offer, since the tweeter, midrange, and woofers are physically separated - a mild directivity bump appears around 2-2.5kHz that’s typical of non-coaxial multi-way speakers, though not audibly problematic within about ±10° vertically. On-axis, the top end reads as a bit bright according to one reviewer’s subjective impression, generally benefiting from some toe-out. High-gloss cabinet finish can create distracting reflections if used behind a projector screen in a home theater setup. Front-ported, so it can technically sit close to a wall, but doing so makes the bass boomier.
Full Revel F226Be review and specifications →
| Bass Extension (-10dB) | 36Hz (measured, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 56Hz (measured, Erin's Audio Corner) |
| Dimensions | 41.3"H x 9.8"W x 13.7"D (1049 x 248.9 x 348 mm) |
| Drivers | Two 6.5" (165mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms nominal (3.7 ohms minimum, measured, Erin's Audio Corner) |
| Sensitivity | 89.7dB (measured, Erin's Audio Corner) |
| Weight | 58.2 lbs / 26.4 kg each |
| Woofer Cabinet | ported, front |
As an eBay Partner, we may be compensated if you make a purchase.
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Klipsch Forte IV: $5,499.98 Amazon Crutchfield
Pros: Three-way heritage design: a 1” titanium tweeter and 1.75” compression driver for the midrange mated to a 12” woofer, plus a 15” passive radiator for extra bass reinforcement. Genuinely resonance-free cabinet, a clear improvement over the notably boomy, resonant Heresy 4 in the same lineup. Surprisingly wide, expansive soundstage that beat both the Heresy 4 and a KEF LS50 Wireless 2 in direct comparison - images occasionally appeared several feet outside the physical speaker location. Deeper bass extension than the Heresy 4 (F3 of 82Hz, about 10Hz lower). Distortion measures well below 1% at 86dB and stays mostly within 1% even at 96dB. Comes as a factory-matched serial-numbered pair, backed by an unusually generous 10-year warranty. Mostly above 4 ohms impedance, so it’s compatible with AVRs, solid-state, or tube amplifiers. More neutral overall than other Klipsch models the reviewer has tested, making it a reasonable pick for listeners who already like the “Klipsch sound” but want something more balanced.
Cons: Contrary to the classic Klipsch reputation for being forward and bright, this model is actually somewhat recessed in the 1.5-4kHz “presence” region, which can make some tracks sound dull or lacking in detail. A peak around 6kHz reads as sibilant and “painful” when seated exactly on the tweeter axis; sitting a bit above that axis reduces it somewhat. Klipsch’s marketed 99dB sensitivity figure is an in-room rating that assumes 3-6dB of boundary gain - anechoic sensitivity measures closer to 94dB, which the manufacturer does disclose but can still mislead buyers comparing spec sheets. Radiation width isn’t consistent across all frequencies - a noticeable notch around 2-3kHz interrupts otherwise wide dispersion, which can cause a fundamental tone and its harmonics to image in slightly different places in the soundstage. Uses shallow low-pass crossover slopes (despite Klipsch’s steep-crossover marketing, which applies only to the high-pass side), likely contributing to some of the measured dips and possible cone-breakup artifacts. Some compression shows up around the midrange crossover point at very high output (102dB), though likely only audible at extreme volumes. At around $5,000/pair, a significant investment, and still needs a subwoofer for material extending below about 50Hz.
Full Klipsch Forte IV review and specifications →
| Bass Extension (-10dB) | 39Hz (measured, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 82Hz (measured, Erin's Audio Corner) |
| Dimensions | 36"H x 16.5"W x 13"D (914.4 x 419.1 x 330.2 mm) |
| Drivers | 1x 12" (305mm) fiber-composite woofer + 15" passive radiator, 1x 1.75" compression driver midrange on horn, 1x 1" titanium compression tweeter on horn |
| Impedance | 8 ohms |
| Sensitivity | 93.8dB (measured average, Erin's Audio Corner; manufacturer rates 99dB in-room / ~94dB anechoic) |
| Weight | 117.3 lbs / 53.2 kg |
| Woofer Cabinet | passive radiator |
