Short answer: the Revel W228Be. It ranks #5 of 18 in-wall speakers by sound quality, rated 4.2/5, at $7,699.90. The KEF CI250RRM-THX ranks #6, rated 4.1/5, at $5,999.98, $1,699.92 cheaper, which does not close the gap in sound quality.
What the Revel W228Be does well: Revel’s own measurement, published on spinorama.org, gives a preference score of 6.79, or 8.33 with a perfect subwoofer. Watch for: Audio Science Review’s independent Klippel measurement was far weaker than Revel’s own (preference score 2.31, or 6.15 with a subwoofer, and -3dB at 108Hz), so real bass depends heavily on the installation and enclosure.
What the KEF CI250RRM-THX does well: Independently measured by Audio Science Review to a genuine 51.3Hz at -3dB and roughly 23.3Hz at -10dB, the deepest bass extension of any in-wall or in-ceiling speaker in this category. The tradeoff: At $3000 each, this is the most expensive speaker in this category.
Buy the Revel W228Be. It is rated higher for sound quality, and the $1,699.92 you would save on the KEF CI250RRM-THX does not close the gap.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| Revel W228Be | KEF CI250RRM-THX | |
|---|---|---|
| Price | $7,699.90 per pair | $5,999.98 per pair |
| Ranked | #5 of 18 in In-Wall & In-Ceiling Speakers | #6 of 18 in In-Wall & In-Ceiling Speakers |
| Drivers | 2x 8” DCC aluminum woofers, 5.25” DCC aluminum midrange, 1” beryllium dome tweeter with acoustic lens waveguide (3-way) | 10” LF woofer, 4” Uni-Q midrange, 1” vented aluminum dome tweeter with MAT (3-way coaxial) |
| Enclosure | In-wall, 27-54L enclosure (optional W228BEBB back box sold separately) | Open-backed, in-ceiling |
| Mounting Cutout | 309W x 896H mm | 300mm (11.81 in) |
| Dimensions | 37”H x 13.9”W x 4.1”D (939 x 353 x 105 mm) (96mm mounting depth) | 13.6” x 13.6” x 6.9” (346 x 346 x 175 mm) (168mm mounting depth) |
| Weight | 31.5 lbs (14.3 kg) | 13.2 lbs (6 kg) |
| Sensitivity | 90dB | 89dB |
| Impedance | 6 ohms nominal (4 ohm minimum) | 8 ohms |
| Power Handling | 50-400W RMS at 4 ohms | 50-250W recommended amplifier power |
| Frequency Response | 35Hz-40kHz (-6dB, manufacturer) | 28Hz-20kHz +/-6dB (manufacturer, open-backed) |
| Maximum SPL | 115dB (manufacturer specified) | - |
| Crossover Frequency | 220Hz, 2,500Hz | - |
| Bass Extension (-3dB) | 43.4Hz (measured, Revel vendor data on spinorama.org) | 51.3Hz (measured, spinorama.org ASR data) |
| Bass Extension (-10dB) | 26.9Hz (measured, Revel vendor data on spinorama.org) | 23.3Hz (measured, spinorama.org ASR data) |
| Spinorama Preference Score | 6.79 | 4.67 |
| Spinorama Preference Score with Perfect Sub | 8.33 | 6.68 |
| DIY Kit | No | No |
| Certification | - | THX |
Related Speaker Comparisons
More top alternatives to Revel W228Be:
- Revel W226Be vs Revel W228Be
- Revel W228Be vs JBL Synthesis SCL-3
- Revel W228Be vs JBL Synthesis SCL-4
- Revel W228Be vs MartinLogan Tribute 5XW
- KEF CI250RRM-THX vs MartinLogan Tribute 5XW
Prices on this page were last checked September 26, 2026 at 11:14 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel W228Be: $7,699.90 per pair Crutchfield eBay
Pros: Revel’s own measurement, published on spinorama.org, gives a preference score of 6.79, or 8.33 with a perfect subwoofer. Bass measures to 43.4Hz at -3dB and 34.3Hz at -6dB, exceptional for an in-wall, and predicted in-room response is very smooth (0.91 smoothness) with tightly controlled directivity (SPDI deviation 1.89dB). Its three-way design uses dual 8” aluminum woofers, a 5.25” midrange and a 1” beryllium tweeter, rated for 115dB output, and the midrange and tweeter module rotates for vertical or horizontal mounting. Measured bass extension of 43.4Hz (-3dB).
Cons: Audio Science Review’s independent Klippel measurement was far weaker than Revel’s own (preference score 2.31, or 6.15 with a subwoofer, and -3dB at 108Hz), so real bass depends heavily on the installation and enclosure. The Revel figures are manufacturer supplied and digitized. At $3850 each a stereo pair costs twice that, and the speaker is about 939mm tall and 14.3kg with a 27 to 54 liter enclosure requirement, with the back box sold separately.
Full Revel W228Be review and specifications →
| Bass Extension (-10dB) | 26.9Hz (measured, Revel vendor data on spinorama.org) |
|---|---|
| Bass Extension (-3dB) | 43.4Hz (measured, Revel vendor data on spinorama.org) |
| Crossover Frequency | 220Hz, 2,500Hz |
| DIY Kit | No |
| Dimensions | 37”H x 13.9”W x 4.1”D (939 x 353 x 105 mm) (96mm mounting depth) |
| Drivers | 2x 8” DCC aluminum woofers, 5.25” DCC aluminum midrange, 1” beryllium dome tweeter with acoustic lens waveguide (3-way) |
| Enclosure | In-wall, 27-54L enclosure (optional W228BEBB back box sold separately) |
| Frequency Response | 35Hz-40kHz (-6dB, manufacturer) |
| Impedance | 6 ohms nominal (4 ohm minimum) |
| Maximum SPL | 115dB (manufacturer specified) |
| Mounting Cutout | 309W x 896H mm |
| Power Handling | 50-400W RMS at 4 ohms |
| Sensitivity | 90dB |
| Spinorama Preference Score | 6.79 |
| Spinorama Preference Score with Perfect Sub | 8.33 |
| Weight | 31.5 lbs (14.3 kg) |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
KEF CI250RRM-THX: $5,999.98 per pair Abt Electronics eBay
Pros: Independently measured by Audio Science Review to a genuine 51.3Hz at -3dB and roughly 23.3Hz at -10dB, the deepest bass extension of any in-wall or in-ceiling speaker in this category. It’s a THX-certified 3-way coaxial design, a 10” woofer built around a 4” Uni-Q midrange and 1” aluminum dome tweeter, deliberately voiced for the 30-60 degree off-axis angle typical of a ceiling-mounted Dolby Atmos height or surround channel rather than a straight-down listening position. Run through a receiver’s automated room correction, spinorama’s EQ-adjusted figures show its preference score climbing from 4.67 to 5.68, so it responds well to correction. Measured bass extension of 51.3Hz (-3dB).
Cons: At $3000 each, this is the most expensive speaker in this category. Its raw on-axis measurement trails the Ci3160RLM-THX (preference score 4.67 vs. 4.62) since the driver array is tuned for off-axis dispersion rather than a flat straight-ahead response, and its on-axis deviation averages 1.14dB, one of the roughest of the batch measured on-axis.
Full KEF CI250RRM-THX review and specifications →
| Bass Extension (-10dB) | 23.3Hz (measured, spinorama.org ASR data) |
|---|---|
| Bass Extension (-3dB) | 51.3Hz (measured, spinorama.org ASR data) |
| Certification | THX |
| DIY Kit | No |
| Dimensions | 13.6” x 13.6” x 6.9” (346 x 346 x 175 mm) (168mm mounting depth) |
| Drivers | 10” LF woofer, 4” Uni-Q midrange, 1” vented aluminum dome tweeter with MAT (3-way coaxial) |
| Enclosure | Open-backed, in-ceiling |
| Frequency Response | 28Hz-20kHz +/-6dB (manufacturer, open-backed) |
| Impedance | 8 ohms |
| Mounting Cutout | 300mm (11.81 in) |
| Power Handling | 50-250W recommended amplifier power |
| Sensitivity | 89dB |
| Spinorama Preference Score | 4.67 |
| Spinorama Preference Score with Perfect Sub | 6.68 |
| Weight | 13.2 lbs (6 kg) |
