Short answer: the Revel W228Be if sound quality matters most, the KEF CI250RRM-THX if price matters most. The Revel W228Be ranks #6 of 28 in-wall speakers, rated 4.2/5, at $7,699.90. The KEF CI250RRM-THX ranks #7, rated 4.1/5, at $4,357.90, $3,342 cheaper.
The Revel W228Be is the more accurate, deeper-bass option. A large three way in-wall speaker with dual 8 inch woofers, accurate smooth sound and a rotating module for vertical or horizontal mounting. Its measured preference score, a predictor of how neutral it sounds, is 6.79 against 4.67 for the KEF CI250RRM-THX. Its bass reaches about 43.4Hz before falling 3dB, against 51.3Hz for the KEF CI250RRM-THX. Watch for: Audio Science Review’s independent Klippel measurement was far weaker than Revel’s own (preference score 2.31, or 6.15 with a subwoofer, and -3dB at 108Hz), so real bass depends heavily on the installation and enclosure.
What the KEF CI250RRM-THX does well: An in-ceiling speaker with very deep bass for its type, voiced for Atmos height or surround channels and great with room correction. The tradeoff: At $2179 each, this is the most expensive speaker in this category.
Buy the Revel W228Be when sound quality outweighs the price for you, and the KEF CI250RRM-THX when the price outweighs sound quality instead.
Looking for alternatives? See the complete Passive Home rankings.
Prices on this page were last checked November 7, 2026 at 7:34 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Specifications Side By Side
| Revel W228Be | KEF CI250RRM-THX | |
|---|---|---|
| Price | $7,699.90 per pair | $4,357.90 per pair |
| Ranked | #6 of 28 in In-Wall & In-Ceiling Speakers | #7 of 28 in In-Wall & In-Ceiling Speakers |
| Drivers | 2x 8” DCC aluminum woofers, 5.25” DCC aluminum midrange, 1” beryllium dome tweeter with acoustic lens waveguide (3-way) | 10” LF woofer, 4” Uni-Q midrange, 1” vented aluminum dome tweeter with MAT (3-way coaxial) |
| Enclosure | In-wall, 27-54L enclosure (optional W228BEBB back box sold separately) | Open-backed, in-ceiling |
| Mounting Cutout | 309W x 896H mm | 300mm (11.81 in) |
| Dimensions | 37”H x 13.9”W x 4.1”D (939 x 353 x 105 mm) (96mm mounting depth) | 13.6” x 13.6” x 6.9” (346 x 346 x 175 mm) (168mm mounting depth) |
| Weight | 31.5 lbs (14.3 kg) | 13.2 lbs (6 kg) |
| Sensitivity | 90dB | 89dB |
| Impedance | 6 ohms nominal (4 ohm minimum) | 8 ohms |
| Power Handling | 50-400W RMS at 4 ohms | 50-250W recommended amplifier power |
| Frequency Response | 35Hz-40kHz (-6dB, manufacturer) | 28Hz-20kHz +/-6dB (manufacturer, open-backed) |
| Maximum SPL | 115dB (manufacturer specified) | - |
| Crossover Frequency | 220Hz, 2,500Hz | - |
| Bass Extension (-3dB) | 43.4Hz (measured, Revel vendor data on spinorama.org) | 51.3Hz (measured, spinorama.org ASR data) |
| Bass Extension (-10dB) | 26.9Hz (measured, Revel vendor data on spinorama.org) | 23.3Hz (measured, spinorama.org ASR data) |
| Spinorama Preference Score | 6.79 | 4.67 |
| Spinorama Preference Score with Perfect Sub | 8.33 | 6.68 |
| DIY Kit | No | No |
| Certification | - | THX |
