Short answer: the Revel F226Be for better sound quality, the SVS Ultra Evolution Pinnacle for the lower price. The Revel F226Be ranks #9 of 54 floorstanding speakers at $7700. The SVS Ultra Evolution Pinnacle ranks #37 at $4999.98, $2700.02 cheaper.
What the Revel F226Be offers: Compact three-way tower with a beryllium dome tweeter in an acoustic lens waveguide, a dedicated 5.25” mid-range, and dual 6.5” woofers (not a coaxial layout) - all Deep Ceramic Composite aluminum cones engineered specifically to… Watch for: Minimum impedance dips to about 3.7-4 ohms below roughly 500Hz despite the 8-ohm nominal rating, so it wants a genuine 4-ohm-capable two-channel amplifier; budget AVRs rated only for 6 or 8 ohms may struggle.
What the SVS Ultra Evolution Pinnacle offers: A large curved-baffle tower built for time alignment: a 1” dome tweeter flanked by two 5.25” midranges above two 8” mid-bass drivers, plus a matching pair of 8” drivers and dual ports on the back. Watch for: Not a fully linear speaker: a dip in the upper midrange followed closely by a peak (roughly 2-3kHz) gives vocals and other midrange content a shouty, forward quality that toe-out alone doesn’t resolve, pointing to a genuine…
Buy the Revel F226Be if sound quality matters more than the price. Buy the SVS Ultra Evolution Pinnacle if the price matters more than sound quality.
Specifications Side By Side
| Revel F226Be | SVS Ultra Evolution Pinnacle | |
|---|---|---|
| Price | $7700 | $4,999.98 |
| Ranked | #9 of 54 in Large Size Floorstanding Speakers | #37 of 54 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 36Hz (measured, Erin’s Audio Corner) | 27Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 56Hz (measured, Erin’s Audio Corner) | 40Hz (measured, Erin’s Audio Corner) |
| Dimensions | 41.3"H x 9.8"W x 13.7"D (1049 x 248.9 x 348 mm) | 49"H x 12"W x 18"D (1245.0 x 305.0 x 457.0 mm) |
| Impedance | 8 ohms nominal (3.7 ohms minimum, measured, Erin’s Audio Corner) | 6 ohms nominal, 2.6 ohms minimum (measured, Erin’s Audio Corner) |
| Drivers | Two 6.5" (165mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter | 1" dome tweeter, two 5.25" midranges, four 8" mid-bass drivers (2 front, 2 rear) |
| Sensitivity | 89.7dB (measured, Erin’s Audio Corner) | 88.1dB (measured, Erin’s Audio Corner) |
| Weight | 58.2 lbs / 26.4 kg each | 100.1 lbs / 45.4 kg (100 lb) each |
| Woofer Cabinet | ported, front | ported, rear (dual) |
| Frequency Response | - | 24Hz - 40kHz (±3dB, Manufacturer specified) |
| Crossovers | - | 140Hz & 1.8kHz |
| Recommended Power | - | 20-300W |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- MoFi SourcePoint 888 vs KEF R5
- JBL HDI-3800 vs KEF R5
- JBL HDI-3800 vs JBL 4367
- Revel F226Be vs JBL HDI-3800
- Revel F226Be vs KEF Reference 203
The Two Speakers In Full
Revel F226Be: $7700 Crutchfield
Pros: Compact three-way tower with a beryllium dome tweeter in an acoustic lens waveguide, a dedicated 5.25” mid-range, and dual 6.5” woofers (not a coaxial layout) - all Deep Ceramic Composite aluminum cones engineered specifically to avoid breakup outside their crossover bands, and it measures that way: neither the woofers nor the mid-range show breakup spikes even well outside their intended pass bands, and even the front port measures unusually clean (only a mild ~3dB bump around 150Hz, well controlled versus the resonances the reviewer typically sees from ports). On-axis frequency response holds within about ±1.5dB above roughly 65Hz - excellent linearity - and off-axis behavior tracks it closely, with only mild, subdued peaking around 4-6kHz that doesn’t show up as real resonance in the spinorama data. Average sensitivity around 90dB (2.83V/1m), notably higher than some competing three-way designs and most bookshelf speakers, translating directly into better dynamic range at both low and high listening levels - one reviewer specifically praised its ability to deliver full transient impact (snare hits, kick drum) even at quiet, conversational volumes rather than needing to be cranked up to feel dynamic. Wide, consistent horizontal radiation of about ±60-70° at the -6dB point, landing right in the reviewer’s preferred range for an enveloping soundstage without excess diffusion, and exceptionally wide vertical dispersion - roughly ±80° up to 10kHz and still ±70° above that, which one reviewer called the widest vertical radiation pattern he had measured to date. Distortion stays under 3% even at 104dB SPL, and in real-world testing up to 105dB from 12-14 feet away, full-range with no crossover, the reviewer heard no audible mechanical noise, port chuffing, or compression at all. Flat enough on- and off-axis response that toeing the speaker 10-15° away from the listener preserves the same tonal balance rather than changing it, and the wide, well-controlled directivity lets sidewall reflections reinforce rather than smear the soundstage.
Cons: Minimum impedance dips to about 3.7-4 ohms below roughly 500Hz despite the 8-ohm nominal rating, so it wants a genuine 4-ohm-capable two-channel amplifier; budget AVRs rated only for 6 or 8 ohms may struggle. F3 of 56Hz and F10 of 36Hz mean it doesn’t extend nearly as low as some three-way rivals with larger woofers - a dedicated subwoofer (10-12”, or 15” for content below 30Hz) is recommended for home theater or bass-heavy music, even though the speaker itself can play surprisingly loud without one. Vertical directivity tolerance is tighter in the crossover handoff region than a true coaxial design would offer, since the tweeter, midrange, and woofers are physically separated - a mild directivity bump appears around 2-2.5kHz that’s typical of non-coaxial multi-way speakers, though not audibly problematic within about ±10° vertically. On-axis, the top end reads as a bit bright according to one reviewer’s subjective impression, generally benefiting from some toe-out. High-gloss cabinet finish can create distracting reflections if used behind a projector screen in a home theater setup. Front-ported, so it can technically sit close to a wall, but doing so makes the bass boomier.
Full Revel F226Be review and specifications →
| Bass Extension (-10dB) | 36Hz (measured, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 56Hz (measured, Erin's Audio Corner) |
| Dimensions | 41.3"H x 9.8"W x 13.7"D (1049 x 248.9 x 348 mm) |
| Drivers | Two 6.5" (165mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms nominal (3.7 ohms minimum, measured, Erin's Audio Corner) |
| Sensitivity | 89.7dB (measured, Erin's Audio Corner) |
| Weight | 58.2 lbs / 26.4 kg each |
| Woofer Cabinet | ported, front |
As an eBay Partner, we may be compensated if you make a purchase.
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
SVS Ultra Evolution Pinnacle: $4,999.98 SVS
Pros: A large curved-baffle tower built for time alignment: a 1” dome tweeter flanked by two 5.25” midranges above two 8” mid-bass drivers, plus a matching pair of 8” drivers and dual ports on the back. Impulse-response testing shows a single clean arrival rather than the staggered tweeter-then-woofer arrival typical of conventional flat-baffle designs, confirming genuinely effective time alignment. Excellent build quality throughout. Very wide, consistent horizontal radiation around ±70-80° gives a large, enveloping soundstage. Capable of very high output with very low harmonic distortion - the reviewer says this measured the lowest harmonic distortion of any speaker he has tested to date, at both 86dB and 96dB output, with distortion staying under 1% down to 40Hz.
Cons: Not a fully linear speaker: a dip in the upper midrange followed closely by a peak (roughly 2-3kHz) gives vocals and other midrange content a shouty, forward quality that toe-out alone doesn’t resolve, pointing to a genuine on-axis response issue rather than just room reflections. A wide, high-Q bass bump around 70-80Hz makes the speaker sound boomy unless pulled at least 3 feet from the rear wall or tamed with EQ (a -3dB cut with a Q of 1 around 70Hz worked well in testing). Minimum impedance dips to about 2.6 ohms around 80Hz, a genuinely demanding load - the reviewer could not drive these to satisfying output with budget-oriented amplifiers and receivers, and recommends a robust stereo amp or monoblocks instead. At around 100 lbs and roughly 4 feet tall with the tweeter about 32.5” off the ground, seating position matters: straying beyond about 10° of the tweeter axis loses real detail in the upper midrange, and the crossover region shows lobing that shifts from about 10° to 50° between 2-4kHz. Multitone distortion and dynamic compression both increase in that same upper-midrange/tweeter region at higher output, consistent with the on-axis dip-then-peak character.
Full SVS Ultra Evolution Pinnacle review and specifications →
| Bass Extension (-10dB) | 27Hz (measured, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 40Hz (measured, Erin's Audio Corner) |
| Crossovers | 140Hz & 1.8kHz |
| Dimensions | 49"H x 12"W x 18"D (1245.0 x 305.0 x 457.0 mm) |
| Drivers | 1" dome tweeter, two 5.25" midranges, four 8" mid-bass drivers (2 front, 2 rear) |
| Frequency Response | 24Hz - 40kHz (±3dB, Manufacturer specified) |
| Impedance | 6 ohms nominal, 2.6 ohms minimum (measured, Erin's Audio Corner) |
| Recommended Power | 20-300W |
| Sensitivity | 88.1dB (measured, Erin's Audio Corner) |
| Weight | 100.1 lbs / 45.4 kg (100 lb) each |
| Woofer Cabinet | ported, rear (dual) |
