Short answer: the Revel F226Be for better sound quality, the JBL Studio 590 for the lower price. The Revel F226Be ranks #11 of 71 floorstanding speakers at $7700. The JBL Studio 590 ranks #68 at $2000, $5700 cheaper.
What the Revel F226Be offers: Compact three-way tower with a beryllium dome tweeter in an acoustic lens waveguide, a dedicated 5.25” mid-range, and dual 6.5” woofers (not a coaxial layout) - all Deep Ceramic Composite aluminum cones engineered specifically to avoid breakup outside their crossover bands, and it measures that way: neither the woofers nor the mid-range show breakup spikes even well outside their intended pass bands, and even the front port measures unusually clean (only a mild ~3dB bump around 150Hz, well controlled versus the resonances the reviewer typically sees from ports). On-axis frequency response holds within about ±1.5dB above roughly 65Hz - excellent linearity - and off-axis behavior tracks it closely, with only mild, subdued peaking around 4-6kHz that doesn’t show up as real resonance in the spinorama data. Average sensitivity around 90dB (2.83V/1m), notably higher than some competing three-way designs and most bookshelf speakers, translating directly into better dynamic range at both low and high listening levels - one reviewer specifically praised its ability to deliver full transient impact (snare hits, kick drum) even at quiet, conversational volumes rather than needing to be cranked up to feel dynamic. Wide, consistent horizontal radiation of about ±60-70° at the -6dB point, landing right in the reviewer’s preferred range for an enveloping soundstage without excess diffusion, and exceptionally wide vertical dispersion - roughly ±80° up to 10kHz and still ±70° above that, which one reviewer called the widest vertical radiation pattern he had measured to date. Distortion stays under 3% even at 104dB SPL, and in real-world testing up to 105dB from 12-14 feet away, full-range with no crossover, the reviewer heard no audible mechanical noise, port chuffing, or compression at all. Flat enough on- and off-axis response that toeing the speaker 10-15° away from the listener preserves the same tonal balance rather than changing it, and the wide, well-controlled directivity lets sidewall reflections reinforce rather than smear the soundstage. Watch for: Minimum impedance dips to about 3.7-4 ohms below roughly 500Hz despite the 8-ohm nominal rating, so it wants a genuine 4-ohm-capable two-channel amplifier; budget AVRs rated only for 6 or 8 ohms may struggle. F3 of 56Hz and F10 of 36Hz mean it doesn’t extend nearly as low as some three-way rivals with larger woofers - a dedicated subwoofer (10-12”, or 15” for content below 30Hz) is recommended for home theater or bass-heavy music, even though the speaker itself can play surprisingly loud without one. Vertical directivity tolerance is tighter in the crossover handoff region than a true coaxial design would offer, since the tweeter, midrange, and woofers are physically separated - a mild directivity bump appears around 2-2.5kHz that’s typical of non-coaxial multi-way speakers, though not audibly problematic within about ±10° vertically. On-axis, the top end reads as a bit bright according to one reviewer’s subjective impression, generally benefiting from some toe-out. High-gloss cabinet finish can create distracting reflections if used behind a projector screen in a home theater setup. Front-ported, so it can technically sit close to a wall, but doing so makes the bass boomier.
What the JBL Studio 590 offers: Pretty deep bass. CEA2034 spinorama is flat on-axis at a high level, with high sensitivity around 89-90dB. Predicted in-room response is good aside from a dip between 800Hz-1.5kHz. Distortion at 86dB SPL/1m is good outside of the 8.5kHz resonance. Watch for: 3dB peak at 1.7khz, about a 4dB peak from 8k to 13k, going to be bright up top. Just okay vertical off axis. Really bad resonance at 8.5khz, which shows up as a sharp distortion spike at both 86dB and 96dB SPL/1m. Cumulative spectral decay (waterfall) reveals many fine resonances across the midrange and treble. At 96dB SPL/1m the midrange and treble get notably messier, with broad distortion elevation from 2-8kHz.
Buy the Revel F226Be if sound quality matters more than the price. Buy the JBL Studio 590 if the price matters more than sound quality.
If sound quality matters at all to you, skip the JBL Studio 590. It ranks near the bottom of the 71 floorstanding speakers, so look higher up the list instead.
Specifications Side By Side
| Revel F226Be | JBL Studio 590 | |
|---|---|---|
| Price | $7700 | $2000 Discontinued |
| Ranked | #11 of 71 in Large Size Floorstanding Speakers | #68 of 71 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 36Hz (measured, Erin’s Audio Corner) | 32Hz (measured, Audio Science Review) |
| Bass Extension (-3dB) | 56Hz (measured, Erin’s Audio Corner) | 48Hz (measured, Audio Science Review) |
| Dimensions | 41.3"H x 9.8"W x 13.7"D (1049 x 248.9 x 348 mm) | 49.7"H x 12.7"W x 16.3"D (1263.0 x 322.0 x 413.0 mm) |
| Impedance | 8 ohms nominal (3.7 ohms minimum, measured, Erin’s Audio Corner) | 6 ohms nominal (5 ohms measured minimum, Audio Science Review) |
| Drivers | Two 6.5" (165mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter | 2x 8" (200mm) PolyPlas cone woofers, 1x 1" (25mm) Teonex dome tweeter on Bi-Radial horn (2.5-way) |
| Sensitivity | 89.7dB (measured, Erin’s Audio Corner) | 90.3dB (2.83V/1m, measured by Audio Science Review) |
| Weight | 58.2 lbs / 26.4 kg each | 107.8 lbs / 48.9 kg |
| Woofer Cabinet | ported, front | ported, rear |
| Discontinued | - | Yes |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- KEF R5 vs Revel F228Be
- MoFi SourcePoint 888 vs KEF R5
- Klipsch Forte IV vs KEF R5
- Revel F206 vs Revel F226Be
- Klipsch RP-8000F II vs Revel F226Be
Prices on this page were last checked August 25, 2026 at 6:19 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel F226Be: $7700 Crutchfield eBay
Pros: Compact three-way tower with a beryllium dome tweeter in an acoustic lens waveguide, a dedicated 5.25” mid-range, and dual 6.5” woofers (not a coaxial layout) - all Deep Ceramic Composite aluminum cones engineered specifically to avoid breakup outside their crossover bands, and it measures that way: neither the woofers nor the mid-range show breakup spikes even well outside their intended pass bands, and even the front port measures unusually clean (only a mild ~3dB bump around 150Hz, well controlled versus the resonances the reviewer typically sees from ports). On-axis frequency response holds within about ±1.5dB above roughly 65Hz - excellent linearity - and off-axis behavior tracks it closely, with only mild, subdued peaking around 4-6kHz that doesn’t show up as real resonance in the spinorama data. Average sensitivity around 90dB (2.83V/1m), notably higher than some competing three-way designs and most bookshelf speakers, translating directly into better dynamic range at both low and high listening levels - one reviewer specifically praised its ability to deliver full transient impact (snare hits, kick drum) even at quiet, conversational volumes rather than needing to be cranked up to feel dynamic. Wide, consistent horizontal radiation of about ±60-70° at the -6dB point, landing right in the reviewer’s preferred range for an enveloping soundstage without excess diffusion, and exceptionally wide vertical dispersion - roughly ±80° up to 10kHz and still ±70° above that, which one reviewer called the widest vertical radiation pattern he had measured to date. Distortion stays under 3% even at 104dB SPL, and in real-world testing up to 105dB from 12-14 feet away, full-range with no crossover, the reviewer heard no audible mechanical noise, port chuffing, or compression at all. Flat enough on- and off-axis response that toeing the speaker 10-15° away from the listener preserves the same tonal balance rather than changing it, and the wide, well-controlled directivity lets sidewall reflections reinforce rather than smear the soundstage.
Cons: Minimum impedance dips to about 3.7-4 ohms below roughly 500Hz despite the 8-ohm nominal rating, so it wants a genuine 4-ohm-capable two-channel amplifier; budget AVRs rated only for 6 or 8 ohms may struggle. F3 of 56Hz and F10 of 36Hz mean it doesn’t extend nearly as low as some three-way rivals with larger woofers - a dedicated subwoofer (10-12”, or 15” for content below 30Hz) is recommended for home theater or bass-heavy music, even though the speaker itself can play surprisingly loud without one. Vertical directivity tolerance is tighter in the crossover handoff region than a true coaxial design would offer, since the tweeter, midrange, and woofers are physically separated - a mild directivity bump appears around 2-2.5kHz that’s typical of non-coaxial multi-way speakers, though not audibly problematic within about ±10° vertically. On-axis, the top end reads as a bit bright according to one reviewer’s subjective impression, generally benefiting from some toe-out. High-gloss cabinet finish can create distracting reflections if used behind a projector screen in a home theater setup. Front-ported, so it can technically sit close to a wall, but doing so makes the bass boomier.
Full Revel F226Be review and specifications →
| Bass Extension (-10dB) | 36Hz (measured, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 56Hz (measured, Erin's Audio Corner) |
| Dimensions | 41.3"H x 9.8"W x 13.7"D (1049 x 248.9 x 348 mm) |
| Drivers | Two 6.5" (165mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4" (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1" (25mm) Beryllium dome, with acoustic lens waveguide tweeter |
| Impedance | 8 ohms nominal (3.7 ohms minimum, measured, Erin's Audio Corner) |
| Sensitivity | 89.7dB (measured, Erin's Audio Corner) |
| Weight | 58.2 lbs / 26.4 kg each |
| Woofer Cabinet | ported, front |
- Links
- Reviews, Comparisons and Sound Samples
- Erin’s Audio Corner: Revel PerformaBe F226Be Floorstanding Loudspeaker Review. I love this speaker. More from Erin’s Audio Corner →
- Erin’s Audio Corner: Should You Buy the Revel F226Be or the MoFi 888?
- Erin’s Audio Review Website Revel F226B
- Erin’s Audio Corner: My Top 5 Speakers at Any Price
- Erin’s Audio Corner Measurements (spinorama.org)
- Reddit Search for Revel F226Be Review
- Head-to-Head Comparisons
JBL Studio 590: $2000 Discontinued eBay
Pros: Pretty deep bass. CEA2034 spinorama is flat on-axis at a high level, with high sensitivity around 89-90dB. Predicted in-room response is good aside from a dip between 800Hz-1.5kHz. Distortion at 86dB SPL/1m is good outside of the 8.5kHz resonance.
Cons: 3dB peak at 1.7khz, about a 4dB peak from 8k to 13k, going to be bright up top. Just okay vertical off axis. Really bad resonance at 8.5khz, which shows up as a sharp distortion spike at both 86dB and 96dB SPL/1m. Cumulative spectral decay (waterfall) reveals many fine resonances across the midrange and treble. At 96dB SPL/1m the midrange and treble get notably messier, with broad distortion elevation from 2-8kHz. Discontinued.
Full JBL Studio 590 review and specifications →
| Bass Extension (-10dB) | 32Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 48Hz (measured, Audio Science Review) |
| Dimensions | 49.7"H x 12.7"W x 16.3"D (1263.0 x 322.0 x 413.0 mm) |
| Discontinued | Yes |
| Drivers | 2x 8" (200mm) PolyPlas cone woofers, 1x 1" (25mm) Teonex dome tweeter on Bi-Radial horn (2.5-way) |
| Impedance | 6 ohms nominal (5 ohms measured minimum, Audio Science Review) |
| Sensitivity | 90.3dB (2.83V/1m, measured by Audio Science Review) |
| Weight | 107.8 lbs / 48.9 kg |
| Woofer Cabinet | ported, rear |
