Short answer: choose between the Yamaha DXR10mkII and RCF ART 745-A MK5 by matching the speaker to the deployment rather than treating their ranking positions as a universal verdict. Coverage, cabinet format, bass extension, output capability, DSP, and service support all matter in a PA system. The Yamaha DXR10mkII is discontinued; its replacement is the Yamaha DXR10mkIII.
Why choose the Yamaha DXR10mkII. A proven, broadly distributed workhorse: medium-quality vendor data shows a 5.16 ideal-subwoofer preference score with 67Hz measured extension, and Yamaha’s FIR-X processing and D-Contour compressor simplify setup.
Why choose the RCF ART 745-A MK5. The top of the ART7 range pairs 133dB claimed peak output with a light 41.4 lbs (18.8 kg) enclosure, RCF’s largest ART7-tier compression driver and FiRPHASE processing carried over from the smaller 712/732-A MK5 models.
What to weigh before buying. It lacks app control or Bluetooth audio found on some newer competitors, and its measured preference sits mid-pack for this ranking. The low-quality vendor measurement is truncated and cannot generate a preference score, so its tonal position relies on published engineering rather than a confirmed result.
Buy the Yamaha DXR10mkII when its stated coverage, output, processing, and installation format fit the job better.
Buy the RCF ART 745-A MK5 when its stated strengths better suit the venue and the rest of the system.
Still deciding? The full PA & Live Sound rankings cover every ranked option.
A proven, easy to set up 10 inch PA workhorse with a flexible input section and simple processing presets.
A light powered 15 inch PA speaker with loud peaks and a large compression driver for strong vocals.
Prices on this page were last checked October 23, 2026 at 8:27 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Specifications Side By Side
| Yamaha DXR10mkII | RCF ART 745-A MK5 | |
|---|---|---|
| Price | $814.99 Discontinued | $1,149.00 |
| Ranked | #13 of 42 in 10-Inch PA Speakers | #35 of 76 in 15-Inch PA Speakers |
| Passive | No | No |
| Configuration | Active 2-way bass-reflex PA speaker | Active 2-way bass-reflex PA speaker |
| Drivers | 10” woofer, 1.75” compression driver | 15” woofer, 1.4” exit/3” diaphragm compression driver |
| Frequency Response | 56Hz - 20kHz (-10dB, manufacturer specified) | 45Hz - 20kHz (manufacturer specified) |
| Dimensions | 19.8”H x 12”W x 12.2”D (502 x 305 x 310 mm) | 27.9”H x 17.2”W x 15.3”D (708 x 437 x 389 mm) |
| Maximum SPL | 132dB peak (manufacturer specified) | 133dB peak (manufacturer specified) |
| Inputs | XLR, dual 1/4-inch, stereo RCA; XLR thru and link outputs | XLR and 1/4-inch jack input; XLR output |
| Amplifier Power | 1100W dynamic / 700W continuous (950W LF + 150W HF dynamic) | 1400W peak (1000W LF + 400W HF) |
| Cabinet Material | Matte-finish ABS | PP composite |
| Rigging | 3 x M8 points; 35mm dual-angle pole mount | 2 x M10 inserts; 35mm pole mount |
| Bass Extension (-3dB) | 73Hz (measured, vendor Spinorama data) | 65Hz (measured, vendor Spinorama data) |
| DSP | Yes | Yes, FiRPHASE, EQ, limiting and protection |
| Bluetooth | No | No |
| Weight | 30.6 lbs (13.9 kg) | 41.4 lbs (18.8 kg) |
| Spinorama Preference Score | 2.30 | - |
| Spinorama Preference Score with Perfect Sub | 5.16 | - |
| XLR Input | Yes | Yes |
| RCA Input | Yes | No |
| TRS Input | Yes | Yes |
| Optical Input | No | No |
| Coaxial Input | No | No |
| USB Input | No | No |
| HDMI Input | No | No |
| AES Input | No | No |
| Aux Input | No | No |
| Microphone Input | No | No |
| Guitar Input | No | No |
| Coverage | 90° x 60° (wide-dispersion constant directivity horn) | 90° x 60° |
| Crossover Frequency | - | 650Hz |
Frequency Response Compared
Both speakers’ spinorama measurements, overlaid. A flatter line is more neutral: peaks sound forward or harsh, dips sound recessed. Each curve is shifted so its average from 300 Hz to 3 kHz sits at 0 dB, so loudness differences between the two are removed and only the shape is compared.
Measurement data: Yamaha DXR10mkII (measured by the manufacturer) and RCF ART 745-A MK5 (measured by the manufacturer), via spinorama.org.
