Short answer: the JBL Studio 698 for controlled high frequencies, with an EQ caveat. Its HDI horn waveguide and 1” compression driver give excellent high-frequency directivity control and a seamless handoff to the 6” PolyPlas midrange. A prominent mid-bass bump around 80Hz can sound thick or chesty in smaller rooms without DSP EQ, while the Revel F208 is the more even on-axis performer at ~87-88dB sensitivity.
Buy the JBL Studio 698 new; the Revel F208 is no longer sold new, so it only makes sense as a used find.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| Revel F208 | JBL Studio 698 | |
|---|---|---|
| Price | $4,800 per pair used, Discontinued | $1,499.90 per pair |
| Ranked | #16 of 74 in Large Size Floorstanding Speakers | #30 of 74 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 24Hz (measured, Audio Science Review) | 34Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 47Hz (measured, Audio Science Review) | 53Hz (measured, Erin’s Audio Corner) |
| Dimensions | 46.6”H x 13.5”W x 14.8”D (1183.6 x 342.9 x 375.9 mm) | 41.7”H x 11.8”W x 15.7”D (1058 x 300 x 400 mm) |
| Impedance | 8 ohms nominal, 3.5 ohms minimum (measured, Audio Science Review) | 6 ohms nominal (4.1 ohms minimum above 80Hz, measured by Erin’s Audio Corner) |
| Drivers | Dual 8” (20 cm) Aluminum Cone, Cast-frame Woofers, 5.25” (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1” (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide | 1 in. High-Definition Imaging compression driver, 6 in. PolyPlas midrange, dual 8 in. PolyPlas woofers |
| Sensitivity | 88.2dB (measured by Audio Science Review; 88.5dB manufacturer specified) | 90dB (measured average, Erin’s Audio Corner) |
| Weight | 79.4 lbs (36 kg) each | 78.9 lbs (35.8 kg) each |
| Woofer Cabinet | ported, front | ported, rear |
| Spinorama Preference Score | 6.35 | 4.20 |
| Spinorama Preference Score with Perfect Sub | 7.67 | 6.14 |
| DIY Kit | No | No |
Related Speaker Comparisons
More worthwhile head-to-heads for Revel F208:
- KEF Blade Two Meta vs Revel F208
- MoFi SourcePoint V10 Master Edition vs Revel F208
- Revel F208 vs MoFi SourcePoint 888
- Revel F208 vs Revel F328Be
- KEF R5 Meta vs Revel F208
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel F208: $4,800 per pair used Discontinued eBay
Newer model: the Revel F228Be, ranked lower, rated 4.5/5.
Pros: CEA2034 spinorama shows a fairly even on-axis response with sensitivity matching spec at ~87-88dB. Predicted in-room response is a smooth, textbook-quality downward slope that should translate well to most rooms without correction. Early reflections sum so cleanly with the direct sound that side-wall absorption isn’t recommended: it would work against the speaker’s naturally well-integrated off-axis behavior. Distortion stays below 0.5% from 100Hz up at 96dB/1m, with all distortion components falling below audible threshold above 200Hz. Very wide horizontal directivity of about ±75 degrees. Measured performance was judged very close to Revel’s own flagship Salon2, and Revel’s speakers (including this one) are developed using Harman’s double-blind listening test methodology. Preference score of 7.4 (7.7 with a subwoofer added). Measured bass extension of 47Hz (-3dB), with a measured sensitivity of 88.2dB.
Cons: Some directivity error and tweeter-response ripple right at the 2.2kHz crossover point. A notable on-axis dip at about 4kHz, attributed to probable cabinet diffraction. Cumulative spectral decay (waterfall) shows an unexplained resonance around 4-5kHz that the reviewer couldn’t pin down a clear cause for. Vertical directivity shows narrowband interference nulls just above and below the tweeter axis (roughly 2-3kHz), typical of a non-coaxial tower with vertically separated drivers, so listening height matters more than it would with a coincident design. Minimum impedance dips to 3.4 ohms, calling for a robust, high-current amplifier. Distortion climbs substantially below about 80-100Hz (up to ~5% in the deep bass) when driven hard, an excursion-limited trade-off typical of towers at high output. Isolating the woofers alone shows their usable range ending around 500-700Hz at the crossover, with somewhat elevated (though still low in absolute terms) 2nd/3rd harmonic distortion in the 100-300Hz region. Discontinued.
Full Revel F208 review and specifications →
| Bass Extension (-10dB) | 24Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 47Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 46.6”H x 13.5”W x 14.8”D (1183.6 x 342.9 x 375.9 mm) |
| Drivers | Dual 8” (20 cm) Aluminum Cone, Cast-frame Woofers, 5.25” (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1” (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide |
| Impedance | 8 ohms nominal, 3.5 ohms minimum (measured, Audio Science Review) |
| Sensitivity | 88.2dB (measured by Audio Science Review; 88.5dB manufacturer specified) |
| Spinorama Preference Score | 6.35 |
| Spinorama Preference Score with Perfect Sub | 7.67 |
| Weight | 79.4 lbs (36 kg) each |
| Woofer Cabinet | ported, front |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
JBL Studio 698: $1,499.90 per pair Crutchfield eBay
Older model: the JBL Studio 590 (ranked lower, rated 2.8/5).
Pros: High-Definition Imaging (HDI) horn waveguide paired with a 1” compression driver provides excellent high-frequency directivity control and seamless acoustic handoff to the 6” PolyPlas midrange. Dual 8” PolyPlas woofers deliver robust low-end authority with solid bass extension down to an F3 of 53Hz and F10 of 34Hz. High voltage sensitivity (90dB SPL at 2.83V/1m) and clean power handling provide effortless dynamic headroom and low distortion for home theater and music listening. Measured bass extension of 53Hz (-3dB), with a measured sensitivity of 90dB.
Cons: Measured response exhibits a prominent mid-bass emphasis bump around 80Hz that can sound overly thick or chesty in smaller rooms without DSP EQ. Treble response lacks top-octave ‘air’ above 12kHz compared to high-end dome or ribbon tweeters. Physically large, heavy cabinet (35.8 kg per speaker) requires careful room placement and a wide acoustic footprint.
Full JBL Studio 698 review and specifications →
| Bass Extension (-10dB) | 34Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 53Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 41.7”H x 11.8”W x 15.7”D (1058 x 300 x 400 mm) |
| Drivers | 1 in. High-Definition Imaging compression driver, 6 in. PolyPlas midrange, dual 8 in. PolyPlas woofers |
| Impedance | 6 ohms nominal (4.1 ohms minimum above 80Hz, measured by Erin’s Audio Corner) |
| Sensitivity | 90dB (measured average, Erin’s Audio Corner) |
| Spinorama Preference Score | 4.20 |
| Spinorama Preference Score with Perfect Sub | 6.14 |
| Weight | 78.9 lbs (35.8 kg) each |
| Woofer Cabinet | ported, rear |
