Short answer: both are discontinued, so this only matters if you are buying used. Used, the Revel F206 is the better pick: it ranks #29 of 188 floorstanding speakers by sound quality (rated 4.5/5), against #178 (rated 2.8/5) for the JBL Studio 590. If you want one new, the Revel F226Be replaces the Revel F206 and is rated 4.6/5 at $8,469.90.
The Revel F206 is the more accurate option. CEA2034 spinorama shows a pretty even on-axis response. Its measured preference score, a predictor of how neutral it sounds, is 5.51 against 4.49 for the JBL Studio 590. The catch: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz.
The JBL Studio 590 is the deeper-bass pick. Pretty deep bass. Its bass reaches about 48Hz before falling 3dB, against 60Hz for the Revel F206. Watch for: 3dB peak at 1.7kHz, about a 4dB peak from 8k to 13k, going to be bright up top.
Buy the Revel F206 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, buy the Revel F226Be, which replaces the Revel F206.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| Revel F206 | JBL Studio 590 | |
|---|---|---|
| Price | $2,000 per pair used, Discontinued | $2,000 per pair Discontinued |
| Ranked | #29 of 188 in Large Size Floorstanding Speakers | #178 of 188 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 34Hz (measured, Audio Science Review) | 32Hz (measured, Audio Science Review) |
| Bass Extension (-3dB) | 60Hz (measured, Audio Science Review) | 48Hz (measured, Audio Science Review) |
| Dimensions | 40.3”H x 8.4”W x 12.2”D (1023.6 x 213.4 x 309.9 mm) | 49.7”H x 12.7”W x 16.3”D (1263.0 x 322.0 x 413.0 mm) |
| Impedance | 4 ohms nominal (3.3 ohms minimum, measured by Audio Science Review) | 6 ohms nominal (5 ohms measured minimum, Audio Science Review) |
| Drivers | Dual 6.5” (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25” (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1” (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide | 2x 8” (200mm) PolyPlas cone woofers, 1x 1” (25mm) Teonex dome tweeter on Bi-Radial horn (2.5-way) |
| Sensitivity | 87dB (measured, Audio Science Review) | 90.3dB (2.83V/1m, measured by Audio Science Review) |
| Weight | 57.3 lbs (26 kg) each | 107.8 lbs (48.9 kg) |
| Woofer Cabinet | ported, front | ported, rear |
| Spinorama Preference Score | 5.51 | 4.49 |
| Spinorama Preference Score with Perfect Sub | 7.52 | 6.22 |
| DIY Kit | No | No |
Related Speaker Comparisons
How Revel F206 compares with other leading options:
- Revel F206 vs KEF Blade Two Meta
- MoFi SourcePoint 888 vs Revel F206
- Revel F328Be vs Revel F206
- KEF R5 Meta vs Revel F206
- Revel F206 vs Revel F226Be
Prices on this page were last checked October 9, 2026 at 8:01 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel F206: $2,000 per pair used Discontinued eBay
Newer model: the Revel F226Be, ranked higher, rated 4.6/5.
Same family: the Revel M105 (smaller bookshelf, rated 4.2/5), the Revel M106 (larger bookshelf, rated 4.6/5), the Revel F208 (larger floorstanding, ranked higher, rated 4.5/5), the Revel Performa3 C205 (smaller center, rated 4.1/5) and the Revel Performa3 C208 (larger center, rated 4/5).
Pros: CEA2034 spinorama shows a pretty even on-axis response. Predicted in-room response is excellent, with a smooth downward slope. Horizontal beamwidth of about ±65 degrees is wide, if a bit uneven. Distortion is very nice at 86dB SPL/1m, falling below the frequency range where human hearing is most sensitive, and stays excellent even at 96dB SPL/1m. Near-field measurements of the individual drivers show nice suppression of port and woofer resonances. Really amazing value for the performance. Measured bass extension of 60Hz (-3dB), with a measured sensitivity of 87dB.
Cons: Some directivity error and a small peak around 4.5kHz show up alongside the directivity error around 3kHz. Vertical directivity means listening position needs to stay within the tweeter axis, though the reviewer notes there is some leeway. Minimum impedance dips to 3.3 ohms, calling for an amplifier comfortable with a demanding load. Discontinued.
Full Revel F206 review and specifications →
| Bass Extension (-10dB) | 34Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 60Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 40.3”H x 8.4”W x 12.2”D (1023.6 x 213.4 x 309.9 mm) |
| Drivers | Dual 6.5” (16.5 cm) Aluminum Cone, Cast-frame Woofers, 5.25” (13.3 cm) Aluminum Cone, Cast-frame Midrange, 1” (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide |
| Impedance | 4 ohms nominal (3.3 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 87dB (measured, Audio Science Review) |
| Spinorama Preference Score | 5.51 |
| Spinorama Preference Score with Perfect Sub | 7.52 |
| Weight | 57.3 lbs (26 kg) each |
| Woofer Cabinet | ported, front |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
JBL Studio 590: $2,000 per pair Discontinued eBay
Newer model: the JBL Studio 698, ranked higher, rated 4.3/5.
Same family: the JBL Studio 530 (bookshelf, rated 3.3/5) and the JBL Studio 520C (center, rated 3.4/5).
Pros: Pretty deep bass. CEA2034 spinorama is flat on-axis at a high level, with high sensitivity around 89-90dB. Predicted in-room response is good aside from a dip between 800Hz-1.5kHz. Distortion at 86dB SPL/1m is good outside of the 8.5kHz resonance. Measured bass extension of 48Hz (-3dB), with a measured sensitivity of 90.3dB.
Cons: 3dB peak at 1.7kHz, about a 4dB peak from 8k to 13k, going to be bright up top. Just okay vertical off axis. Really bad resonance at 8.5kHz, which shows up as a sharp distortion spike at both 86dB and 96dB SPL/1m. Cumulative spectral decay (waterfall) reveals many fine resonances across the midrange and treble. At 96dB SPL/1m the midrange and treble get notably messier, with broad distortion elevation from 2-8kHz. Discontinued.
Full JBL Studio 590 review and specifications →
| Bass Extension (-10dB) | 32Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 48Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 49.7”H x 12.7”W x 16.3”D (1263.0 x 322.0 x 413.0 mm) |
| Drivers | 2x 8” (200mm) PolyPlas cone woofers, 1x 1” (25mm) Teonex dome tweeter on Bi-Radial horn (2.5-way) |
| Impedance | 6 ohms nominal (5 ohms measured minimum, Audio Science Review) |
| Sensitivity | 90.3dB (2.83V/1m, measured by Audio Science Review) |
| Spinorama Preference Score | 4.49 |
| Spinorama Preference Score with Perfect Sub | 6.22 |
| Weight | 107.8 lbs (48.9 kg) |
| Woofer Cabinet | ported, rear |
