Short answer: both are discontinued, so this only matters if you are buying used. Used, the JBL HDI-3800 is the better pick: it ranks #25 of 188 floorstanding speakers by sound quality (rated 4.5/5), against #178 (rated 2.8/5) for the JBL Studio 590. If you want one new, the JBL Studio 698 replaces the JBL Studio 590 and is rated 4.3/5 at $1,499.90.
The JBL HDI-3800 is the more accurate, deeper-bass pick. 2410H-2 1” Teonex compression driver matched to a custom High-Definition Imaging (HDI) horn geometry achieves exceptional horizontal directivity control, high output capability, and effortless transient response. Its measured preference score, a predictor of how neutral it sounds, is 5.62 against 4.49 for the JBL Studio 590. Its bass reaches about 37Hz before falling 3dB, against 48Hz for the JBL Studio 590. Watch for: On-axis frequency response features a narrow upper-frequency elevation around 8-10kHz, performing noticeably smoother when toed out 10-20° off-axis.
Why pick the JBL Studio 590: Pretty deep bass. Watch for: 3dB peak at 1.7kHz, about a 4dB peak from 8k to 13k, going to be bright up top.
Buy the JBL HDI-3800 only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, buy the JBL Studio 698, which replaces the JBL Studio 590.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| JBL HDI-3800 | JBL Studio 590 | |
|---|---|---|
| Price | $5,000 per pair Discontinued | $2,000 per pair Discontinued |
| Ranked | #25 of 188 in Large Size Floorstanding Speakers | #178 of 188 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 28Hz (measured, Erin’s Audio Corner) | 32Hz (measured, Audio Science Review) |
| Bass Extension (-3dB) | 37Hz (measured, Erin’s Audio Corner) | 48Hz (measured, Audio Science Review) |
| Dimensions | 43.3”H x 11.8”W x 16.4”D (1100.5 x 300.0 x 417.8 mm) | 49.7”H x 12.7”W x 16.3”D (1263.0 x 322.0 x 413.0 mm) |
| Impedance | 4 ohms nominal (3.8 ohms minimum, measured by Erin’s Audio Corner) | 6 ohms nominal (5 ohms measured minimum, Audio Science Review) |
| Sensitivity | 92dB (measured average, Erin’s Audio Corner) | 90.3dB (2.83V/1m, measured by Audio Science Review) |
| Drivers | 1 in. 2410H-2 Teonex compression driver with HDI horn, triple 8 in. Advanced Aluminum Matrix cone woofers | 2x 8” (200mm) PolyPlas cone woofers, 1x 1” (25mm) Teonex dome tweeter on Bi-Radial horn (2.5-way) |
| Weight | 83.8 lbs (38.0 kg) each | 107.8 lbs (48.9 kg) |
| Woofer Cabinet | ported, rear | ported, rear |
| Spinorama Preference Score | 5.62 | 4.49 |
| Spinorama Preference Score with Perfect Sub | 7.03 | 6.22 |
| DIY Kit | No | No |
Related Speaker Comparisons
More top alternatives to JBL HDI-3800:
- KEF Blade Two Meta vs JBL HDI-3800
- JBL HDI-3800 vs MoFi SourcePoint V10 Master Edition
- MoFi SourcePoint 888 vs JBL HDI-3800
- JBL HDI-3800 vs Revel F328Be
- Ascend Acoustics ELX Ribbon Tower vs JBL HDI-3800
Prices on this page were last checked October 9, 2026 at 8:01 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
JBL HDI-3800: $5,000 per pair Discontinued eBay
Same family: the JBL HDI-1600 (bookshelf, rated 4.2/5), the JBL HDI-3600 (smaller floorstanding, ranked lower, rated 4.3/5) and the JBL HDI-4500 (center, rated 3.7/5).
Pros: 2410H-2 1” Teonex compression driver matched to a custom High-Definition Imaging (HDI) horn geometry achieves exceptional horizontal directivity control, high output capability, and effortless transient response. Triple 8” Advanced Aluminum Matrix woofers deliver deep, authoritative bass extension down to an F3 of 37Hz and F10 of 28Hz with minimal low-frequency compression. Outstanding sensitivity (92dB SPL at 2.83V/1m) and ultra-low THD/multitone distortion allow extremely high undistorted SPL output in large home theater spaces. Measured bass extension of 37Hz (-3dB), with a measured sensitivity of 92dB.
Cons: On-axis frequency response features a narrow upper-frequency elevation around 8-10kHz, performing noticeably smoother when toed out 10-20° off-axis. Vertical directivity handoff across the triple woofer layout creates vertical soundstage height tilt depending on listening distance and ear height. Minimum impedance dips to 3.8 ohms, requiring high-current amplifier stability. Substantial cabinet dimensions and 38kg weight require significant room real estate. Discontinued.
Full JBL HDI-3800 review and specifications →
| Bass Extension (-10dB) | 28Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 37Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 43.3”H x 11.8”W x 16.4”D (1100.5 x 300.0 x 417.8 mm) |
| Drivers | 1 in. 2410H-2 Teonex compression driver with HDI horn, triple 8 in. Advanced Aluminum Matrix cone woofers |
| Impedance | 4 ohms nominal (3.8 ohms minimum, measured by Erin’s Audio Corner) |
| Sensitivity | 92dB (measured average, Erin’s Audio Corner) |
| Spinorama Preference Score | 5.62 |
| Spinorama Preference Score with Perfect Sub | 7.03 |
| Weight | 83.8 lbs (38.0 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
JBL Studio 590: $2,000 per pair Discontinued eBay
Newer model: the JBL Studio 698, ranked higher, rated 4.3/5.
Same family: the JBL Studio 530 (bookshelf, rated 3.3/5) and the JBL Studio 520C (center, rated 3.4/5).
Pros: Pretty deep bass. CEA2034 spinorama is flat on-axis at a high level, with high sensitivity around 89-90dB. Predicted in-room response is good aside from a dip between 800Hz-1.5kHz. Distortion at 86dB SPL/1m is good outside of the 8.5kHz resonance. Measured bass extension of 48Hz (-3dB), with a measured sensitivity of 90.3dB.
Cons: 3dB peak at 1.7kHz, about a 4dB peak from 8k to 13k, going to be bright up top. Just okay vertical off axis. Really bad resonance at 8.5kHz, which shows up as a sharp distortion spike at both 86dB and 96dB SPL/1m. Cumulative spectral decay (waterfall) reveals many fine resonances across the midrange and treble. At 96dB SPL/1m the midrange and treble get notably messier, with broad distortion elevation from 2-8kHz. Discontinued.
Full JBL Studio 590 review and specifications →
| Bass Extension (-10dB) | 32Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 48Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 49.7”H x 12.7”W x 16.3”D (1263.0 x 322.0 x 413.0 mm) |
| Drivers | 2x 8” (200mm) PolyPlas cone woofers, 1x 1” (25mm) Teonex dome tweeter on Bi-Radial horn (2.5-way) |
| Impedance | 6 ohms nominal (5 ohms measured minimum, Audio Science Review) |
| Sensitivity | 90.3dB (2.83V/1m, measured by Audio Science Review) |
| Spinorama Preference Score | 4.49 |
| Spinorama Preference Score with Perfect Sub | 6.22 |
| Weight | 107.8 lbs (48.9 kg) |
| Woofer Cabinet | ported, rear |
