Yamaha NS-6490 Review: Rated 1.2/5

Last updated: October 31, 2026

The Yamaha NS-6490 is rated 1.2/5 for sound quality, #222 of 222 Large Size Bookshelf Speakers. See all Passive Home rankings for every top pick.

Yamaha NS-6490 · Editor's rating 1.2/5, ranked #222 of 222 Large Size Bookshelf Speakers

Prices on this page were last checked November 14, 2026 at 6:17 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Brand: Yamaha

#222 Yamaha NS-6490: $129.95 per pair Discontinued eBay

Pros: An inexpensive discontinued three way bookshelf speaker with a large 8 inch woofer and an attractive industrial design. Attractive industrial design with a large 8-inch woofer for the price. Simple direct-driven woofer with capacitor-only mid/tweeter crossovers keeps the design straightforward. Measured bass extension of 54.4Hz (-10dB), with a measured sensitivity of 89.6dB.

Cons: Amir found the woofer runs essentially full-range with only a capacitor separating the mid and tweeter, letting all three drivers bleed into each other’s range and so output climbs steadily across the response. Extensive narrow peaking indicates numerous cabinet resonances: they are unusually numerous. Distortion is high across the measurement range, and directivity is highly variable, particularly vertically. With a 1.6 preference score, ASR did not recommend it, noting that extensive EQ would not fix the underlying resonance issues. Discontinued and no longer sold new.

ReleasedOct 2020 (6 years ago)
Bass Extension (-10dB)54.4Hz (measured, Audio Science Review)
DIY KitNo
Dimensions16.2H x 10.5W x 13.2D in
Drivers8” woofer, 4” midrange cone, 7/8” balanced dome tweeter (3-way, acoustic suspension)
Frequency Response45Hz - 23kHz (Manufacturer specified)
Impedance8 ohms
Power Handling70W nominal, 140W max
Sensitivity89.6dB (2.83V/1m, measured, Audio Science Review)
Spinorama Preference Score2.17
Spinorama Preference Score with Perfect Sub5.05
Weight13.2 lbs (6 kg) each
