The Meyer Sound Ultra X20 is rated 3.6/5 for sound quality, #11 of 39 Compact 5 to 6.5-Inch PA Speakers. See all PA & Live Sound rankings for every top pick.
Prices on this page were last checked November 7, 2026 at 7:34 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Brand: Meyer Sound
#11 Meyer Sound Ultra X20: $5,540 eBay
Same family: the Meyer Sound Ultra X22 (larger model, ranked higher, rated 3.9/5), the Meyer Sound Ultra X23 (larger model, ranked lower, rated 3.3/5), the Meyer Sound Ultra X40 (larger model, rated 3.8/5) and the Meyer Sound Ultra X80 (larger model, estimated 3.9/5).
Pros: A slim self-powered fill speaker with surprisingly deep bass for two 5 inch woofers and a built in amplifier. Manufacturer measurements give preference scores of 2.88 standalone and 5.68 with an ideal subwoofer, and bass reaches 69Hz at -3dB, deep for two 5-inch woofers. The concentric 2-inch compression driver keeps coverage consistent across its 110° x 50° horn, and a built-in 860W peak amplifier with Meyer’s processing makes it a complete self-powered system. At 7.5 inches wide it suits fills, theaters and discreet installs. Measured bass extension of 69Hz (-3dB).
Cons: Its standalone score trails its narrower-coverage Meyer Sound Ultra X22 sibling. A 123.5dB peak rating limits it to small and medium spaces, and a 3.73 directivity-index deviation means off-axis tone varies. It is sold through pro dealers with no published price.
| Released | 2020 (6 years ago) |
|---|---|
| AES Input | No |
| Amplifier Power | 860W peak, 3-channel Class D |
| Aux Input | No |
| Bass Extension (-10dB) | about 61Hz (measured, vendor Spinorama data) |
| Bass Extension (-3dB) | 69Hz (measured, vendor Spinorama data) |
| Bluetooth | No |
| Coaxial Input | No |
| Configuration | Self-powered 2-way concentric compact loudspeaker |
| Coverage | 110° x 50° (rotatable horn) |
| DSP | Yes |
| Dimensions | 19.1”H x 7.5”W x 8.6”D (484 x 191 x 218 mm) |
| Drivers | 2x 5” cone woofers, concentric 2” compression driver |
| Guitar Input | No |
| HDMI Input | No |
| Maximum SPL | 123.5dB peak (M-Noise, manufacturer specified) |
| Microphone Input | No |
| Optical Input | No |
| Passive | No |
| RCA Input | No |
| Rigging | 4 x M8 inserts; 4 x M6 wall-mount holes; optional pole adapter |
| Spinorama Preference Score | 2.88 |
| Spinorama Preference Score with Perfect Sub | 5.68 |
| TRS Input | No |
| USB Input | No |
| Weight | 27.1 lbs (12.3 kg) |
| XLR Input | Yes |
