The HK Audio LINEAR 5 112 F is rated 3.2/5 for sound quality, #62 of 83 12-Inch PA Speakers. See all PA & Live Sound rankings for every top pick.
Prices on this page were last checked November 7, 2026 at 7:34 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Brand: HK Audio
#62 HK Audio LINEAR 5 112 F: $666 Passive Thomann $666 eBay
Same family: the HK Audio LINEAR 5 112 X (larger model, ranked higher, rated 3.5/5) and the HK Audio LINEAR 5 115 F (larger model, estimated 3.1/5).
Pros: A passive 12 inch PA speaker with a rotatable horn that widens up close and loud rated peaks, for use with an external amp. The passive version of the HK Audio LINEAR 5 112 FA, with a 12-inch woofer and 1-inch compression driver on a rotatable asymmetric horn that widens from 60° to 90°, rated to 135dB peak. High-quality manufacturer measurements give a 4.21 preference score with an ideal subwoofer, and bass reaches about 60Hz at -10dB. Measured bass extension of 82.5Hz (-3dB).
Cons: The standalone preference score is only 1.13, with a 0.806 listening-window deviation and bass measuring 82.5Hz at -3dB, so tonal balance is uneven and it needs a subwoofer. It is passive and needs an external amplifier; B&H no longer carries it.
Is the HK Audio LINEAR 5 112 F right for you?
Skip it if
- you want neutral sound: its measured preference score is 4.2 even with a subwoofer.
- you want the best value: the higher-rated Yamaha DBR12 costs about $206 less.
| AES Input | No |
|---|---|
| Amplifier Power | Passive speaker; requires external amplification |
| Aux Input | No |
| Bass Extension (-10dB) | about 60Hz (measured, vendor Spinorama data) |
| Bass Extension (-3dB) | 82.5Hz (measured, vendor Spinorama data) |
| Bluetooth | No |
| Coaxial Input | No |
| Configuration | Passive 2-way PA speaker |
| Coverage | 60°-90° asymmetric x 55° (rotatable) |
| DSP | No (passive) |
| Dimensions | 26.3”H x 14.6”W x 14.4”D (668 x 370 x 365 mm) |
| Drivers | 12” woofer (2.5” voice coil), 1” compression driver (1.75” voice coil) |
| Frequency Response | 79Hz - 18kHz (-6dB, manufacturer specified) |
| Guitar Input | No |
| HDMI Input | No |
| Maximum SPL | 135dB peak (manufacturer specified) |
| Microphone Input | No |
| Optical Input | No |
| Passive | Yes |
| Power Handling | 500W RMS / 1,000W program |
| RCA Input | No |
| Rigging | 3 x M8 rigging points; DuoTilt 3°/7° pole mount |
| Spinorama Preference Score | 1.13 |
| Spinorama Preference Score with Perfect Sub | 4.21 |
| TRS Input | No |
| USB Input | No |
| Weight | 52.7 lbs (23.9 kg) |
| XLR Input | No |
