HK Audio LINEAR 5 112 X vs HK Audio LINEAR 5 112 F

Short answer: the HK Audio LINEAR 5 112 X. It ranks #41 of 50 12-inch pa speakers by sound quality, rated 3.5/5, at $899. The HK Audio LINEAR 5 112 F ranks #46, rated 3.2/5, at $666, $233 cheaper, a saving that is not big enough to make up the sound-quality gap.

Why pick the HK Audio LINEAR 5 112 X: High-quality manufacturer measurements give a 5.51 preference score with an ideal subwoofer and 0.63 predicted in-room smoothness. The tradeoff: It is designed as a top for use with a subwoofer: bass measures 103Hz at -3dB and about 67Hz at -10dB, and the standalone preference score is only 2.20.

Why pick the HK Audio LINEAR 5 112 F: The passive version of the LINEAR 5 112 FA, with a 12-inch woofer and 1-inch compression driver on a rotatable asymmetric horn that widens from 60° to 90°, rated to 135dB peak. The tradeoff: The standalone preference score is only 1.13, with a 0.806 listening-window deviation and bass measuring 82.5Hz at -3dB, so tonal balance is uneven and it needs a subwoofer.

Buy the HK Audio LINEAR 5 112 X. It is rated higher for sound quality, and the $233 saving on the HK Audio LINEAR 5 112 F is not enough to make up the difference.

Looking for alternatives? See the complete PA & Live Sound rankings.

Specifications Side By Side

Related Speaker Comparisons

More worthwhile head-to-heads for HK Audio LINEAR 5 112 X:

• RCF ART 712-A MK5 vs HK Audio LINEAR 5 112 X
• HK Audio LINEAR 5 112 X vs PreSonus CDL12
• RCF ART 712-A MK5 vs HK Audio LINEAR 5 112 F
• PreSonus CDL12 vs HK Audio LINEAR 5 112 F
• HK Audio LINEAR 5 112 F vs PreSonus ULT12

Prices on this page were last checked September 26, 2026 at 11:14 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

The Two Speakers In Full

HK Audio LINEAR 5 112 X: $899.00 Passive B&H Photo Video eBay

Pros: High-quality manufacturer measurements give a 5.51 preference score with an ideal subwoofer and 0.63 predicted in-room smoothness. A 12-inch woofer and 1-inch compression driver on a rotatable 60° x 40° CD horn give a 135dB peak and long throw, and the birch and MDF cabinet doubles as a floor monitor. Measured bass extension of 103Hz (-3dB).

Cons: It is designed as a top for use with a subwoofer: bass measures 103Hz at -3dB and about 67Hz at -10dB, and the standalone preference score is only 2.20. A 3.1dB reference band and 0.625 listening-window deviation mean tonal balance is uneven. It is passive and needs an external amplifier, and B&H lists it as special order.

Full HK Audio LINEAR 5 112 X review and specifications →

AES Input	No
Amplifier Power	Passive speaker; requires external amplification
Aux Input	No
Bass Extension (-10dB)	about 67.1Hz (measured, vendor Spinorama data)
Bass Extension (-3dB)	103Hz (measured, vendor Spinorama data)
Bluetooth	No
Cabinet Material	Birch/MDF hybrid
Coaxial Input	No
Configuration	Passive 2-way PA speaker and floor monitor
Coverage	60° x 40° (rotatable)
DSP	No (passive)
Dimensions	26.4”H x 14.6”W x 11.8”D (670 x 370 x 300 mm)
Drivers	12” woofer (2.5” voice coil), 1” compression driver (1.75” voice coil)
Frequency Response	100Hz - 18kHz (-6dB, manufacturer specified)
Guitar Input	No
HDMI Input	No
Maximum SPL	135dB peak (manufacturer specified)
Microphone Input	No
Optical Input	No
Power Handling	500W RMS / 1,000W program
RCA Input	No
Spinorama Preference Score	2.20
Spinorama Preference Score with Perfect Sub	5.51
TRS Input	No
USB Input	No
Weight	43 lbs (19.5 kg)
XLR Input	No

• Links
  • HK Audio LINEAR 5 112 X Product Page
• Reviews, Comparisons and Sound Samples
  • Spinorama Measurements
• Head-to-Head Comparisons
  • HK Audio LINEAR 5 112 X vs PreSonus CDL12
  • HK Audio LINEAR 5 112 X vs RCF ART 712-A MK5

HK Audio LINEAR 5 112 F: $666 Passive Thomann eBay

Pros: The passive version of the LINEAR 5 112 FA, with a 12-inch woofer and 1-inch compression driver on a rotatable asymmetric horn that widens from 60° to 90°, rated to 135dB peak. High-quality manufacturer measurements give a 4.21 preference score with an ideal subwoofer, and bass reaches about 60Hz at -10dB. Measured bass extension of 82.5Hz (-3dB).

Cons: The standalone preference score is only 1.13, with a 0.806 listening-window deviation and bass measuring 82.5Hz at -3dB, so tonal balance is uneven and it needs a subwoofer. It is passive and needs an external amplifier; B&H no longer carries it.

Full HK Audio LINEAR 5 112 F review and specifications →

AES Input	No
Amplifier Power	Passive speaker; requires external amplification
Aux Input	No
Bass Extension (-10dB)	about 60Hz (measured, vendor Spinorama data)
Bass Extension (-3dB)	82.5Hz (measured, vendor Spinorama data)
Bluetooth	No
Coaxial Input	No
Configuration	Passive 2-way PA speaker
Coverage	60°-90° asymmetric x 55° (rotatable)
DSP	No (passive)
Dimensions	26.3”H x 14.6”W x 14.4”D (668 x 370 x 365 mm)
Drivers	12” woofer (2.5” voice coil), 1” compression driver (1.75” voice coil)
Frequency Response	79Hz - 18kHz (-6dB, manufacturer specified)
Guitar Input	No
HDMI Input	No
Maximum SPL	135dB peak (manufacturer specified)
Microphone Input	No
Optical Input	No
Power Handling	500W RMS / 1,000W program
RCA Input	No
Spinorama Preference Score	1.13
Spinorama Preference Score with Perfect Sub	4.21
TRS Input	No
USB Input	No
Weight	52.7 lbs (23.9 kg)
XLR Input	No

• Links
  • HK Audio LINEAR 5 112 F Product Page
• Reviews, Comparisons and Sound Samples
  • Spinorama Measurements
• Head-to-Head Comparisons
  • HK Audio LINEAR 5 112 F vs PreSonus CDL12
  • HK Audio LINEAR 5 112 F vs PreSonus ULT12
  • HK Audio LINEAR 5 112 F vs RCF ART 712-A MK5
