Short answer: choose between the Yamaha DXR12mkIII and RCF HD 12-A MK5 for the requirements of the venue and system, not from rank alone. In this size class, coverage, bass extension, output capability, DSP, cabinet construction, and service support often decide the better fit.
Why choose the Yamaha DXR12mkIII. The third-generation DXR raises claimed output to 134dB and adds 2000W amplification, app-based control and more capable onboard DSP while staying light at 38.4 lbs (17.4 kg). Medium-quality vendor data shows measured extension around 60Hz.
Why choose the RCF HD 12-A MK5. Medium-quality vendor data indicates useful extension into the low 60Hz region.
What to weigh before buying. The truncated Spinorama data does not produce a preference score, so its tonal advantage over the proven DXR12mkII is not yet quantified. Wireless connectivity is for remote control, not a substitute for a wired production-audio input. The truncated Spinorama measurement cannot produce a preference score, so tonal confidence is lower than for the fully scored leaders. Controls are intentionally simple and omit app control, networking and a multi-input mixer.
Buy the Yamaha DXR12mkIII when its stated coverage, output, processing, and deployment format best match the job.
Buy the RCF HD 12-A MK5 when its stated strengths are the better match for the room and the rest of the PA.
Still deciding? The full PA & Live Sound rankings cover every ranked option.
A light, loud 12 inch powered PA speaker with strong amplification, app control and capable onboard DSP.
An affordable powered 12 inch PA speaker with loud output, simple controls, and onboard processing that keeps bass tidy.
Prices on this page were last checked October 23, 2026 at 8:27 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Specifications Side By Side
| Yamaha DXR12mkIII | RCF HD 12-A MK5 | |
|---|---|---|
| Price | $999.99 | $600.00 Discontinued |
| Ranked | #13 of 83 in 12-Inch PA Speakers | #44 of 83 in 12-Inch PA Speakers |
| Passive | No | No |
| Configuration | Active 2-way bass-reflex PA speaker | Active 2-way bass-reflex PA speaker |
| Drivers | 12” woofer, 1” throat/1.75” diaphragm compression driver | 12” woofer, 1.4” compression driver |
| Frequency Response | 50Hz - 20kHz (-10dB, manufacturer specified) | 45Hz - 20kHz (manufacturer specified) |
| Dimensions | 23.6”H x 14.4”W x 13.8”D (600 x 366 x 350 mm) | 25.5”H x 15”W x 15”D (647 x 380 x 380 mm) |
| Bass Extension (-3dB) | 60Hz (measured, vendor Spinorama data) | 63Hz (measured, vendor Spinorama data) |
| Coverage | 90° x 60° | 90° x 60° |
| Maximum SPL | 134dB peak (manufacturer specified) | 130dB peak (manufacturer specified) |
| Inputs | Balanced mic/line inputs and link output | XLR/TRS combo input and XLR link |
| Amplifier Power | 2000W peak / 1000W RMS (1700W LF + 300W HF peak) | 1400W peak / 700W RMS (1000W LF + 400W HF peak) |
| Crossover Frequency | 1800Hz (FIR-X) | 1800Hz |
| Cabinet Material | PP plastic | PP composite |
| Rigging | 3 x M10 points plus U-bracket points; 35mm dual-angle pole mount | 2 x M10 inserts; 35mm pole mount |
| DSP | Yes, FIR-X tuning, Drive Motion Calibration and D-Remote | Yes, FiRPHASE and Bass Motion Control |
| Bluetooth | Yes | No |
| Bluetooth Version | 5.0 | - |
| Weight | 38.4 lbs (17.4 kg) | 40.3 lbs (18.3 kg) |
| XLR Input | No | Yes |
| RCA Input | No | No |
| TRS Input | No | Yes |
| Optical Input | No | No |
| Coaxial Input | No | No |
| USB Input | No | No |
| HDMI Input | No | No |
| AES Input | No | No |
| Aux Input | No | No |
| Microphone Input | Yes | No |
| Guitar Input | No | No |
Frequency Response Compared
Both speakers’ spinorama measurements, overlaid. A flatter line is more neutral: peaks sound forward or harsh, dips sound recessed. Each curve is shifted so its average from 300 Hz to 3 kHz sits at 0 dB, so loudness differences between the two are removed and only the shape is compared.
Measurement data: Yamaha DXR12mkIII (measured by the manufacturer) and RCF HD 12-A MK5 (measured by the manufacturer), via spinorama.org.
