Short answer: the Revel M126Be. It ranks #34 of 131 bookshelf speakers by sound quality, rated 4.3/5, at $4,400; the Yamaha NS-800A ranks #56, rated 4.0/5, and costs $4,999.90, so there is not much of a tradeoff to weigh.
The case for the Revel M126Be: Two-way design pairing a 6.5” midwoofer with a 1” beryllium dome tweeter, the smaller sibling to the reviewer’s favorite Revel F226Be. Watch for: At $2200/pair, the reviewer doesn’t consider it a strong value: an improvement over Revel’s less expensive M106 and Performa3 models, but not proportional to the price jump.
The case for the Yamaha NS-800A: Exceptionally well-built cabinet with no internal resonance issues at all: confirmed clean in both burst decay and impedance measurements. The tradeoff: A wide, roughly 2kHz-10kHz scoop in the upper-midrange/lower-treble gives it a laidback, soft, low-attack character: notably worse than the reviewer’s Audio First Fidelia reference in an A/B comparison.
Buy the Revel M126Be. It is rated higher for sound quality than the Yamaha NS-800A and costs less, so it is the default pick unless a specific strength of the other one matters more to you.
Still deciding? The full Passive Home rankings cover every ranked option.
Specifications Side By Side
| Revel M126Be | Yamaha NS-800A | |
|---|---|---|
| Price | $4,400 per pair | $4,999.90 per pair |
| Ranked | #34 of 131 in Large Size Bookshelf Speakers | #56 of 131 in Large Size Bookshelf Speakers |
| Bass Extension (-10dB) | 44Hz (measured, Erin’s Audio Corner) | 35Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 103Hz (measured, Erin’s Audio Corner) | 68Hz (measured, Erin’s Audio Corner) |
| Dimensions | 15.2”H x 8.3”W x 10.3”D (386.1 x 210.8 x 261.6 mm) | 16.5”H x 9.1”W x 14.1”D (419.1 x 231.8 x 358.8 mm) |
| Impedance | 6 ohms nominal (4.9 ohms minimum, measured, Erin’s Audio Corner) | 6 ohms nominal, 4.3 ohms minimum (measured above 80Hz, Erin’s Audio Corner) |
| Sensitivity | 86.1dB (measured, Erin’s Audio Corner) | 84.9dB (measured average 300Hz-3kHz @ 2.83V/1m, Erin’s Audio Corner; 86.5dB manufacturer specified) |
| Drivers | 6.5” Deep Ceramic Composite (DCC) Aluminum Cone with cast frame woofer, 1” Beryllium dome with acoustic lens waveguide tweeter | 1.25” dome tweeter, 6.5” mid-woofer |
| Weight | 22 lbs (10.0 kg) each | 28.7 lbs (13.0 kg) each |
| Woofer Cabinet | ported, rear | Bass reflex |
| Spinorama Preference Score | 5.08 | 4.66 |
| Spinorama Preference Score with Perfect Sub | 7.34 | 6.43 |
| DIY Kit | No | No |
| Crossover Frequency | - | 2600Hz |
| Power Handling | - | 40W nominal, 120W max |
Related Speaker Comparisons
More worthwhile head-to-heads for Revel M126Be:
- AsciLab C6B vs Revel M126Be
- KEF R3 Meta vs Revel M126Be
- KEF Q Concerto Meta vs Revel M126Be
- Wharfedale Aura 2 vs Revel M126Be
- KEF R3 vs Revel M126Be
Prices on this page were last checked September 30, 2026 at 2:57 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel M126Be: $4,400 per pair Crutchfield eBay
Older model: the Revel M106 (ranked higher, rated 4.6/5).
Pros: Two-way design pairing a 6.5” midwoofer with a 1” beryllium dome tweeter, the smaller sibling to the reviewer’s favorite Revel F226Be. Wide, immersive stereo imaging: hard-panned sounds in test tracks localized 2-3 feet outside the physical speaker positions without losing pinpoint precision. Horizontal radiation of about 60-70°, landing right in the reviewer’s preferred range for an enveloping yet still well-focused soundstage. Extended bass-shelf tuning (similar in concept to the KEF R3 Meta) combines with in-room gain for a more linear low end rather than a boomy hump. Diffraction dips visible on-axis around 3kHz and 7kHz largely disappear in the estimated in-room response, since they fill in as you move off-axis. Distortion stays within 3% down to about 100Hz at both 86dB and 96dB output: strong performance for a 6.5” bookshelf woofer. Can be driven by a standard AVR thanks to a manageable 4.9-ohm minimum impedance. Measured bass extension of 103Hz (-3dB), with a measured sensitivity of 86.1dB.
Cons: At $2200/pair, the reviewer doesn’t consider it a strong value: an improvement over Revel’s less expensive M106 and Performa3 models, but not proportional to the price jump. Bass tops out around 50Hz in-room; a subwoofer is still needed for real low-end extension. Vertical placement is fairly critical: there’s a notable hole in the response around the 1.7kHz crossover if you sit above the tweeter axis. Toeing the speaker out to a full 30° introduces a roughly 1dB discontinuity in the midrange along with high-frequency rolloff; the reviewer recommends staying close to on-axis or within about 10°. An unexplained jump in distortion appears right at the 1.7kHz crossover point under compression testing, which may be linked to an occasional “glaring” quality the reviewer noticed in the 2-3kHz region at very high volumes (92-93dB from 2 meters). A mild 2-3kHz forwardness occasionally stood out on some tracks, correctable with about 1dB of EQ, though the reviewer considers it minor.
Full Revel M126Be review and specifications →
| Bass Extension (-10dB) | 44Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 103Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 15.2”H x 8.3”W x 10.3”D (386.1 x 210.8 x 261.6 mm) |
| Drivers | 6.5” Deep Ceramic Composite (DCC) Aluminum Cone with cast frame woofer, 1” Beryllium dome with acoustic lens waveguide tweeter |
| Impedance | 6 ohms nominal (4.9 ohms minimum, measured, Erin’s Audio Corner) |
| Sensitivity | 86.1dB (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 5.08 |
| Spinorama Preference Score with Perfect Sub | 7.34 |
| Weight | 22 lbs (10.0 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Revel M126Be vs ELAC VELA BS 403
- Revel M126Be vs Ascend Acoustics Sierra-LX
- Revel M126Be vs Wharfedale Linton 85
- Revel M126Be vs Selah Audio Purezza
- Revel M126Be vs Ascend Acoustics Sierra-2EX V2
- Revel M126Be vs JTR Noesis 210HT
- Revel M126Be vs Dynaudio Heritage Special
- Revel M126Be vs Radiant Acoustics Clarity 6.2
- See all 23 comparisons
Yamaha NS-800A: $4,999.90 per pair The Music Room eBay
Pros: Exceptionally well-built cabinet with no internal resonance issues at all: confirmed clean in both burst decay and impedance measurements. Good, wide directivity (~75 degrees horizontal) that stays consistent enough to EQ successfully. Distortion is low, staying under 3% at 96dB, and dynamic range holds up well until right near its 102dB limit. A shallower, higher-frequency bass rolloff profile (F3 68Hz, F10 35Hz) means it can be placed closer to the wall (about a foot) without turning boomy, actually gaining bass presence rather than losing it. Measured bass extension of 68Hz (-3dB), with a measured sensitivity of 84.9dB.
Cons: A wide, roughly 2kHz-10kHz scoop in the upper-midrange/lower-treble gives it a laidback, soft, low-attack character: notably worse than the reviewer’s Audio First Fidelia reference in an A/B comparison. On top of that, treble breaks up badly above 10kHz, swinging up as much as 8dB: a significant, named flaw. Sounds inconsistently voiced as a result (bright on some material like cymbals and shakers, dull/laidback on vocals and instrument attack) until corrected with real parametric EQ (the reviewer needed a +2dB boost around 4.5kHz at Q0.5 plus taming the treble spike to bring it to life) combined with near-wall placement and 30-degree toe-out. Without that combination, it’s a tough sale for a $5000 bookshelf speaker.
Full Yamaha NS-800A review and specifications →
| Bass Extension (-10dB) | 35Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 68Hz (measured, Erin’s Audio Corner) |
| Crossover Frequency | 2600Hz |
| DIY Kit | No |
| Dimensions | 16.5”H x 9.1”W x 14.1”D (419.1 x 231.8 x 358.8 mm) |
| Drivers | 1.25” dome tweeter, 6.5” mid-woofer |
| Impedance | 6 ohms nominal, 4.3 ohms minimum (measured above 80Hz, Erin’s Audio Corner) |
| Power Handling | 40W nominal, 120W max |
| Sensitivity | 84.9dB (measured average 300Hz-3kHz @ 2.83V/1m, Erin’s Audio Corner; 86.5dB manufacturer specified) |
| Spinorama Preference Score | 4.66 |
| Spinorama Preference Score with Perfect Sub | 6.43 |
| Weight | 28.7 lbs (13.0 kg) each |
| Woofer Cabinet | Bass reflex |
