Short answer: it depends on placement. The ELAC DBR62’s 6.5” woofer and 1” dome tweeter sit close together in a shallow waveguide for near-point-source coherence, giving more vertical leeway than typical two-ways, though a slight recess in the 1-2kHz region reduces vocal presence. The Revel M16 is flat on-axis from 200Hz to 10kHz, but distortion peaks around 80Hz and spikes around 350Hz.
Buy the ELAC DBR62 if you want one new; the Revel Concerta2 M16 is discontinued, so only look for it used.
Still deciding? The full Passive Home rankings cover every ranked option.
Specifications Side By Side
| Revel Concerta2 M16 | ELAC DBR62 | |
|---|---|---|
| Price | $600 per pair used (about), Discontinued | $678.97 per pair |
| Ranked | #51 of 134 in Large Size Bookshelf Speakers | #57 of 134 in Large Size Bookshelf Speakers |
| Drivers | 25mm tweeter + 165mm woofer | 6.5” Aramid Fiber woofer, 1” soft dome tweeter |
| Weight | 32 lbs (14.5 kg) | 18.1 lbs (8.2 kg) each |
| Sensitivity | 86dB | 84.3dB (measured average 300Hz-3kHz @ 2.83V/1m, Erin’s Audio Corner; 86dB manufacturer specified) |
| Impedance | 6 ohms | 6 ohms nominal, 5.2 ohms minimum (measured above 80Hz, Erin’s Audio Corner) |
| Dimensions | 14.8”H x 8.6”W x 10.8”D (374.7 x 218.4 x 273.3 mm) | 14.1”H x 8.2”W x 10.8”D (358.1 x 208.3 x 274.3 mm) |
| Woofer Cabinet | ported, rear | ported, front |
| Bass Extension (-3dB) | 60.1Hz (measured, Audio Science Review) | 53Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-10dB) | 41.6Hz (measured, Audio Science Review) | 41Hz (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 5.06 | 5.07 |
| Spinorama Preference Score with Perfect Sub | 7.28 | 7.27 |
| DIY Kit | No | No |
Related Speaker Comparisons
More worthwhile head-to-heads for Revel Concerta2 M16:
- AsciLab C6B vs Revel Concerta2 M16
- Revel M106 vs Revel Concerta2 M16
- KEF R3 Meta vs Revel Concerta2 M16
- KEF Q Concerto Meta vs Revel Concerta2 M16
- Ascend Acoustics CMT-340 SE2 vs Revel Concerta2 M16
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel Concerta2 M16: $600 per pair used (about) Discontinued eBay
Pros: CEA2034 spinorama shows an on-axis response that’s essentially flat from 200Hz to 10kHz, with some bass boost around 100Hz. Predicted in-room response is very nice, with just extra bass and a bit of roll-off above 20kHz: the reviewer calls it “nice!” Distortion is well controlled through most of the range at both test levels. Measured bass extension of 60.1Hz (-3dB).
Cons: Harmonic distortion shows a notable peak around 80Hz and a sharp spike around 350Hz, plus the woofer appears to get a bit unhappy right before handing off to the tweeter. Cumulative spectral decay (waterfall) shows some lingering resonances in the 300Hz-1kHz region. The reviewer cautions not to over-cover the cabinet/grille area with thin fabric, as it can audibly affect the top-end response. Discontinued.
Full Revel Concerta2 M16 review and specifications →
| Bass Extension (-10dB) | 41.6Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 60.1Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 14.8”H x 8.6”W x 10.8”D (374.7 x 218.4 x 273.3 mm) |
| Drivers | 25mm tweeter + 165mm woofer |
| Impedance | 6 ohms |
| Sensitivity | 86dB |
| Spinorama Preference Score | 5.06 |
| Spinorama Preference Score with Perfect Sub | 7.28 |
| Weight | 32 lbs (14.5 kg) |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Revel Concerta2 M16 vs ELAC Uni-Fi Reference UBR62
- Revel Concerta2 M16 vs JBL HDI-1600
- Revel Concerta2 M16 vs Yamaha NS-800A
- Revel Concerta2 M16 vs Definitive Technology Demand D11
- Revel Concerta2 M16 vs ELAC Debut 3.0 DB63
- Revel Concerta2 M16 vs Technics SB-C700
- Revel Concerta2 M16 vs Emotiva Airmotiv XB2
- Revel Concerta2 M16 vs Dynaudio Contour 20i
- See all 26 comparisons
ELAC DBR62: $678.97 per pair Amazon Crutchfield eBay
Pros: Two-way design with a 6.5” woofer and 1” dome tweeter in a shallow waveguide, with the tweeter positioned close to the woofer for near-point-source coherence: giving more vertical listening leeway than typical two-ways. Notably forgiving of placement and aiming: sounds good from directly on-axis all the way to 30° of toe-out (parallel with the rear wall), making it more room-independent than many speakers this price. Wide horizontal radiation of about ±70° until the tweeter starts beaming, right in the reviewer’s preferred sweet spot. A mild, wide-Q bass bump centered around 100Hz adds a bit of extra punch that the reviewer personally likes. On-axis linearity within about ±2.5dB, with a strong measured preference score of 5.3. Distortion stays below 3% at both 86dB and 96dB until around 50Hz. Vertical sweet spot of about ±10-20° works well for multi-row home theater seating. The reviewer calls it “the epitome of a good speaker” for its price, with no reservations recommending it. Measured bass extension of 53Hz (-3dB), with a measured sensitivity of 84.3dB.
Cons: A slight recess in the 1-2kHz region reduces vocal presence somewhat compared to other speakers in direct comparison. A mild hot spot around 4-5kHz can read as slight sibilance when pointed directly on-axis. Low-to-mid sensitivity (about 84.3dB) combined with a current draw that behaves like roughly 2.4 ohms between 100-200Hz means it’s best driven by a dedicated 4-ohm-capable amplifier rather than an AVR. A diffraction dip from the baffle edge is visible in measurements: typical of any standard rectangular-baffle speaker and not correctable without a much more expensive curved-baffle design. Multitone distortion testing suggests some potential midrange distortion could be audible on certain material, though the reviewer didn’t personally notice it. Minor resonances appear around 700Hz and 1-1.5kHz, possibly tied to the enclosure, port, or cone/surround edge termination, though their audible impact appears minimal. F3 of 53Hz means a subwoofer is still needed for real bass extension below about 40Hz.
Full ELAC DBR62 review and specifications →
| Bass Extension (-10dB) | 41Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 53Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 14.1”H x 8.2”W x 10.8”D (358.1 x 208.3 x 274.3 mm) |
| Drivers | 6.5” Aramid Fiber woofer, 1” soft dome tweeter |
| Impedance | 6 ohms nominal, 5.2 ohms minimum (measured above 80Hz, Erin’s Audio Corner) |
| Sensitivity | 84.3dB (measured average 300Hz-3kHz @ 2.83V/1m, Erin’s Audio Corner; 86dB manufacturer specified) |
| Spinorama Preference Score | 5.07 |
| Spinorama Preference Score with Perfect Sub | 7.27 |
| Weight | 18.1 lbs (8.2 kg) each |
| Woofer Cabinet | ported, front |
