Short answer: it depends on placement. The ELAC DBR62’s 6.5” woofer and 1” dome tweeter sit close together in a shallow waveguide for near-point-source coherence, giving more vertical leeway than typical two-ways, though a slight recess in the 1-2kHz region reduces vocal presence. The Revel M16 is flat on-axis from 200Hz to 10kHz, but distortion peaks around 80Hz and spikes around 350Hz.
Buy the ELAC DBR62 if you want one new; the Revel Concerta2 M16 is discontinued, so only look for it used.
Still deciding? The full Passive Home rankings cover every ranked option.
Measured Differences
- Close enough not to matter: bass extension (41.6 Hz vs 41 Hz, 10 dB down); preference score with a subwoofer (7.3 vs 7.3).
Prices on this page were last checked November 14, 2026 at 6:17 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Specifications Side By Side
| Revel Concerta2 M16 | ELAC DBR62 | |
|---|---|---|
| Price | $600 per pair used (about), Discontinued | $699.98 per pair |
| Ranked | #62 of 222 in Large Size Bookshelf Speakers | #79 of 222 in Large Size Bookshelf Speakers |
| Drivers | 25mm tweeter + 165mm woofer | 6.5” Aramid Fiber woofer, 1” soft dome tweeter |
| Weight | 32 lbs (14.5 kg) | 18.1 lbs (8.2 kg) each |
| Sensitivity | 86dB | 84.3dB (measured average 300Hz-3kHz @ 2.83V/1m, Erin’s Audio Corner; 86dB manufacturer specified) |
| Impedance | 6 ohms | 6 ohms nominal, 5.2 ohms minimum (measured above 80Hz, Erin’s Audio Corner) |
| Dimensions | 14.8”H x 8.6”W x 10.8”D (374.7 x 218.4 x 273.3 mm) | 14.1”H x 8.2”W x 10.8”D (358.1 x 208.3 x 274.3 mm) |
| Woofer Cabinet | ported, rear | ported, front |
| Bass Extension (-3dB) | 60.1Hz (measured, Audio Science Review) | 53Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-10dB) | 41.6Hz (measured, Audio Science Review) | 41Hz (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 5.06 | 5.07 |
| Spinorama Preference Score with Perfect Sub | 7.28 | 7.27 |
| DIY Kit | No | No |
Where the Ratings Come From
- Revel Concerta2 M16: Spinorama.org measurements and reviews by Audio Science Review.
- ELAC DBR62: Spinorama.org measurements and reviews by Erin’s Audio Corner and Audio Science Review.
This comparison is generated from the ratings, specifications and measurements on each product’s own page, and it updates when that data changes. How we rank explains how each rating is decided.
