Short answer: the Revel M106. It ranks #9 of 84 bookshelf speakers by sound quality; the Revel Concerta2 M16 ranks #36.
What the Revel M106 offers: CEA2034 spinorama shows a fairly even on-axis response with no obvious resonances, and a listening window that sits comfortably above the on-axis curve. Watch for: Some directivity error and response variation shows up in the crossover region.
What the Revel Concerta2 M16 offers: CEA2034 spinorama shows an on-axis response that’s essentially flat from 200Hz to 10kHz, with some bass boost around 100Hz. Watch for: Harmonic distortion shows a notable peak around 80Hz and a sharp spike around 350Hz, plus the woofer appears to get a bit unhappy right before handing off to the tweeter.
Buy the Revel M106 if sound quality matters more than the price. Buy the Revel Concerta2 M16 if the price matters more than sound quality.
Specifications Side By Side
| Revel M106 | Revel Concerta2 M16 | |
|---|---|---|
| Price | Discontinued | about $600 used |
| Ranked | #9 of 84 in Large Size Bookshelf Speakers | #36 of 84 in Large Size Bookshelf Speakers |
| Bass Extension (-10dB) | 43Hz (measured, Audio Science Review) | - |
| Bass Extension (-3dB) | 60Hz (measured, Audio Science Review) | 60.1Hz (measured, Audio Science Review) |
| Impedance | 4 ohms | 6 ohms |
| Sensitivity | 86dB (measured, Audio Science Review) | 86dB |
| Drivers | 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofer, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide | 25mm tweeter + 165mm woofer |
| Discontinued | Yes | - |
| Weight | 9.9 lbs / 4.5 kg | 32 lbs / 14.5 kg |
| Dimensions | 15"H x 8.3"W x 11"D (381.0 x 210.8 x 279.4 mm) | 14.8"H x 8.6"W x 10.8"D (374.7 x 218.4 x 273.3 mm) |
| Woofer Cabinet | ported, rear | ported, rear |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- Emotiva Airmotiv XB2 vs StarkSound Beta 5
- StarkSound Beta 5 vs Monolith Encore B6
- StarkSound Beta 5 vs Monolith Encore C6
- ELAC DB63 vs Revel Concerta2 M16
- Revel Concerta2 M16 vs Philharmonic BMR Monitor
The Two Speakers In Full
Revel M106: Discontinued
Pros: CEA2034 spinorama shows a fairly even on-axis response with no obvious resonances, and a listening window that sits comfortably above the on-axis curve. Predicted in-room response is called “near ideal” by the reviewer, with a smooth downward slope from bass to treble. Distortion at 96dB SPL/1m stays well controlled through the midrange and treble.
Cons: Some directivity error and response variation shows up in the crossover region. Horizontal beamwidth of about ±50 degrees is on the narrower side. Vertical directivity requires staying within about ±20 degrees of the reference axis for accurate tonal balance. Minimum impedance dips to 4.6 ohms with several peaks, a moderately demanding load for a compact bookshelf speaker. Discontinued.
Full Revel M106 review and specifications →
| Bass Extension (-10dB) | 43Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 60Hz (measured, Audio Science Review) |
| Dimensions | 15"H x 8.3"W x 11"D (381.0 x 210.8 x 279.4 mm) |
| Discontinued | Yes |
| Drivers | 6.5" (16.5 cm) Aluminum Cone, Cast-frame Woofer, 1" (2.5 cm) Aluminum Tweeter with Acoustic Lens Waveguide |
| Impedance | 4 ohms |
| Sensitivity | 86dB (measured, Audio Science Review) |
| Weight | 9.9 lbs / 4.5 kg |
| Woofer Cabinet | ported, rear |
As an eBay Partner, we may be compensated if you make a purchase.
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
Revel Concerta2 M16: about $600 used
Pros: CEA2034 spinorama shows an on-axis response that’s essentially flat from 200Hz to 10kHz, with some bass boost around 100Hz. Predicted in-room response is very nice, with just extra bass and a bit of roll-off above 20kHz - the reviewer calls it “nice!” Distortion is well controlled through most of the range at both test levels.
Cons: Harmonic distortion shows a notable peak around 80Hz and a sharp spike around 350Hz, plus the woofer appears to get a bit unhappy right before handing off to the tweeter. Cumulative spectral decay (waterfall) shows some lingering resonances in the 300Hz-1kHz region. The reviewer cautions not to over-cover the cabinet/grille area with thin fabric, as it can audibly affect the top-end response.
Full Revel Concerta2 M16 review and specifications →
| Bass Extension (-3dB) | 60.1Hz (measured, Audio Science Review) |
|---|---|
| Dimensions | 14.8"H x 8.6"W x 10.8"D (374.7 x 218.4 x 273.3 mm) |
| Drivers | 25mm tweeter + 165mm woofer |
| Impedance | 6 ohms |
| Sensitivity | 86dB |
| Weight | 32 lbs / 14.5 kg |
| Woofer Cabinet | ported, rear |
