Short answer: the Ascend CBM-170 SE2, if you are buying new. The Revel Concerta2 M16 ranks higher than it (#51 vs #66 of 131 bookshelf speakers, 4.1/5 vs 3.8/5) but is discontinued, so only consider it used; the Ascend CBM-170 SE2 is still sold new at $468.
The case for the Revel Concerta2 M16: CEA2034 spinorama shows an on-axis response that’s essentially flat from 200Hz to 10kHz, with some bass boost around 100Hz. The tradeoff: Harmonic distortion shows a notable peak around 80Hz and a sharp spike around 350Hz, plus the woofer appears to get a bit unhappy right before handing off to the tweeter.
The case for the Ascend CBM-170 SE2: On-axis response is impressively flat from about 100Hz to 2kHz, staying within roughly ±1dB, with a clean, gradual bass rolloff below that. The catch: A narrow dip in the on-axis and listening-window response appears in the 3-5kHz range (down to about -2.7dB), mirrored by a matching dip in the directivity index at the same frequencies - likely a brief widening of dispersion right at the tweeter/woofer crossover.
Buy the Ascend CBM-170 SE2 new; the Revel Concerta2 M16 is no longer sold new, so it only makes sense as a used find.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| Revel Concerta2 M16 | Ascend CBM-170 SE2 | |
|---|---|---|
| Price | $600 per pair used (about), Discontinued | $468 per pair |
| Ranked | #51 of 131 in Large Size Bookshelf Speakers | #66 of 131 in Large Size Bookshelf Speakers |
| Drivers | 25mm tweeter + 165mm woofer | 27mm custom SEAS soft dome tweeter, 6.5” proprietary composite polygel cone woofer |
| Weight | 32 lbs (14.5 kg) | 15 lbs (6.8 kg) each |
| Sensitivity | 86dB | 86.8dB (2.83V/1m, measured, manufacturer spinorama data; 87dB manufacturer specified) |
| Impedance | 6 ohms | 8 ohms |
| Dimensions | 14.8”H x 8.6”W x 10.8”D (374.7 x 218.4 x 273.3 mm) | 12H x 9W x 9.5D in |
| Woofer Cabinet | ported, rear | ported, rear |
| Bass Extension (-3dB) | 60.1Hz (measured, Audio Science Review) | 70Hz (measured, manufacturer spinorama data) |
| Bass Extension (-10dB) | 41.6Hz (measured, Audio Science Review) | 50Hz (measured, manufacturer spinorama data) |
| Spinorama Preference Score | 5.06 | 6.30 |
| Spinorama Preference Score with Perfect Sub | 7.28 | 8.66 |
| DIY Kit | No | No |
| Discontinued | Yes | - |
| Power Handling | - | 200W continuous, 400W peak |
Related Speaker Comparisons
More top alternatives to Revel Concerta2 M16:
- AsciLab C6B vs Revel Concerta2 M16
- Revel M106 vs Revel Concerta2 M16
- KEF R3 Meta vs Revel Concerta2 M16
- KEF Q Concerto Meta vs Revel Concerta2 M16
- Ascend Acoustics CMT-340 SE2 vs Revel Concerta2 M16
Prices on this page were last checked September 26, 2026 at 11:14 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Revel Concerta2 M16: $600 per pair used (about) Discontinued eBay
Pros: CEA2034 spinorama shows an on-axis response that’s essentially flat from 200Hz to 10kHz, with some bass boost around 100Hz. Predicted in-room response is very nice, with just extra bass and a bit of roll-off above 20kHz - the reviewer calls it “nice!” Distortion is well controlled through most of the range at both test levels. Measured bass extension of 60.1Hz (-3dB).
Cons: Harmonic distortion shows a notable peak around 80Hz and a sharp spike around 350Hz, plus the woofer appears to get a bit unhappy right before handing off to the tweeter. Cumulative spectral decay (waterfall) shows some lingering resonances in the 300Hz-1kHz region. The reviewer cautions not to over-cover the cabinet/grille area with thin fabric, as it can audibly affect the top-end response. Discontinued.
Full Revel Concerta2 M16 review and specifications →
| Bass Extension (-10dB) | 41.6Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 60.1Hz (measured, Audio Science Review) |
| DIY Kit | No |
| Dimensions | 14.8”H x 8.6”W x 10.8”D (374.7 x 218.4 x 273.3 mm) |
| Discontinued | Yes |
| Drivers | 25mm tweeter + 165mm woofer |
| Impedance | 6 ohms |
| Sensitivity | 86dB |
| Spinorama Preference Score | 5.06 |
| Spinorama Preference Score with Perfect Sub | 7.28 |
| Weight | 32 lbs (14.5 kg) |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Revel Concerta2 M16 vs ELAC Uni-Fi Reference UBR62
- Revel Concerta2 M16 vs ELAC DBR62
- Revel Concerta2 M16 vs Yamaha NS-800A
- Revel Concerta2 M16 vs JBL HDI-1600
- Revel Concerta2 M16 vs Definitive Technology Demand D11
- Revel Concerta2 M16 vs Technics SB-C700
- Revel Concerta2 M16 vs ELAC Debut 3.0 DB63
- Revel Concerta2 M16 vs Dynaudio Contour 20i
- See all 26 comparisons
Ascend CBM-170 SE2: $468 per pair Ascend Acoustics eBay
Older model: the Ascend CBM-170 SE (rated 2.1/5).
Pros: On-axis response is impressively flat from about 100Hz to 2kHz, staying within roughly ±1dB, with a clean, gradual bass rolloff below that. The directivity index rises smoothly and predictably through the crossover region, and the estimated in-room response shows a smooth, consistent downward tilt from 100Hz to 10kHz with no major discontinuities - close to the ideal in-room target shape. Measured sensitivity of 86.8dB nearly matches Ascend’s 87dB spec. The manufacturer’s own preference-score modeling comes out to 6.30 unequalized (rising to 8.66 with an ideal subwoofer, or 6.79/8.86 with EQ applied) - a strong result for a compact 2-way, and a clear step up from the original CBM-170 SE this replaces. Measured sensitivity of 86.8dB.
Cons: A narrow dip in the on-axis and listening-window response appears in the 3-5kHz range (down to about -2.7dB), mirrored by a matching dip in the directivity index at the same frequencies - likely a brief widening of dispersion right at the tweeter/woofer crossover. High-frequency directivity narrows substantially above 10kHz, typical for a small dome tweeter, so the top octave will sound more reserved off-axis than on-axis. Bass rolls off as expected for a compact 2-way monitor: -3dB around 70Hz and -10dB around 50Hz, so a subwoofer is needed for full-range use. This data comes from the manufacturer’s own Klippel measurements rather than an independent third-party review, so there’s no outside verification of channel matching, distortion, or unit-to-unit consistency.
Full Ascend CBM-170 SE2 review and specifications →
| Bass Extension (-10dB) | 50Hz (measured, manufacturer spinorama data) |
|---|---|
| Bass Extension (-3dB) | 70Hz (measured, manufacturer spinorama data) |
| DIY Kit | No |
| Dimensions | 12H x 9W x 9.5D in |
| Drivers | 27mm custom SEAS soft dome tweeter, 6.5” proprietary composite polygel cone woofer |
| Impedance | 8 ohms |
| Power Handling | 200W continuous, 400W peak |
| Sensitivity | 86.8dB (2.83V/1m, measured, manufacturer spinorama data; 87dB manufacturer specified) |
| Spinorama Preference Score | 6.30 |
| Spinorama Preference Score with Perfect Sub | 8.66 |
| Weight | 15 lbs (6.8 kg) each |
| Woofer Cabinet | ported, rear |
