Short answer: the Pioneer SP-BS22-LR in Philharmonic AAM form, narrowly, though neither ranks well in its class. Both are budget monitors with directivity caveats, but the JBL Stage A130 carries a bass bump, a midrange dip, and a cabinet-resonance peak around 800Hz-1.7kHz confirmed by accelerometer testing. The Philharmonic AAM mod of the discontinued Pioneer, at $168 against $399, answers only for some directivity error near the crossover. Both are rated below 3.0/5 among the 90 bookshelf speakers, and the Ascend Acoustics HTM-200SE2, ranked #7 at $368, is a better place to start if sound quality matters.
Buy the Pioneer SP-BS22-LR (Philharmonic AAM Mod) only if you find one used in good condition; both are discontinued, and it is the better rated of the two. For a new speaker, start with the Ascend Acoustics HTM-200SE2 instead.
Want more options? Browse the full Passive Home rankings.
Specifications Side By Side
| Pioneer SP-BS22-LR (Philharmonic AAM Mod) | JBL Stage A130 | |
|---|---|---|
| Price | $168 per pair Discontinued | $399 per pair Discontinued |
| Ranked | #63 of 90 in Medium Size Bookshelf Speakers | #78 of 90 in Medium Size Bookshelf Speakers |
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) | 66Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) | 50Hz (measured, Erin’s Audio Corner) |
| Drivers | 1x 4” curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1” silk dome tweeter (replacement) | 5.25” (133mm) polycellulose woofer, 1” (25mm) aluminum dome tweeter |
| Weight | 9 lbs (4.1 kg) | 12 lbs (5.45 kg) each |
| Sensitivity | 83dB (2.83V/1m, measured by Audio Science Review) | 85.2dB (measured, Erin’s Audio Corner) |
| Impedance | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) | 6 ohms nominal, about 4.3 ohms minimum (measured, Erin’s Audio Corner) |
| Crossover Frequency | 3000Hz | 3.2kHz |
| Dimensions | 12.6”H x 7.1”W x 8.5”D (320.0 x 180.0 x 215.0 mm) | 12.6”H x 7.5”W x 9.1”D (321 x 190 x 230 mm) |
| Woofer Cabinet | ported, rear | ported |
| Spinorama Preference Score | 5.07 | 4.04 |
| Spinorama Preference Score with Perfect Sub | 7.82 | 6.51 |
| DIY Kit | Yes | No |
Related Speaker Comparisons
More worthwhile head-to-heads for Pioneer SP-BS22-LR (Philharmonic AAM Mod):
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Ascend Sierra 1 v2
- KEF LS50 Meta vs Pioneer SP-BS22-LR (Philharmonic AAM Mod)
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Arendal 1961 Monitor
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Revel M105
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Klipsch RP-500M II
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
Pioneer SP-BS22-LR (Philharmonic AAM Mod): $168 per pair Discontinued eBay
Pros: This is Dennis Murphy’s “Affordable Accuracy Monitor” (AAM) mod of the discontinued, budget Pioneer SP-BS22-LR: the stock tweeter is swapped for a Peerless BC25TG15 dome and a redesigned 3rd-order crossover is built to match it to the stock 4” woofer. CEA2034 spinorama shows only small variations from a flat on-axis response with some directivity error near the crossover, a marked improvement over the unmodified Pioneer, which the reviewer notes shows much more variation from flat. Distortion at 86dB SPL/1m is reasonably controlled above 200Hz, and tweeter distortion barely rises even at 96dB SPL/1m. Measured bass extension of 78Hz (-3dB), with a measured sensitivity of 83dB.
Cons: Some directivity error appears near the crossover frequency. Distortion climbs in the woofer’s range (below 200Hz) at both 86dB and 96dB SPL/1m. Minimum impedance dips to about 5 ohms with a couple of resonance peaks. This is a DIY project, not a finished retail product: Murphy sold ~$168 pre-built pairs for a while but no longer does, so it now requires sourcing a used/discontinued Pioneer SP-BS22-LR pair plus building the crossover and swapping the tweeter yourself. The mod itself is public domain, but there is no current turnkey way to buy this speaker.
Full Pioneer SP-BS22-LR (Philharmonic AAM Mod) review and specifications →
| Bass Extension (-10dB) | 60Hz (measured, Audio Science Review) |
|---|---|
| Bass Extension (-3dB) | 78Hz (measured, Audio Science Review) |
| Crossover Frequency | 3000Hz |
| DIY Kit | Yes |
| Dimensions | 12.6”H x 7.1”W x 8.5”D (320.0 x 180.0 x 215.0 mm) |
| Drivers | 1x 4” curvilinear-cone woofer (stock Pioneer), 1x Peerless BC25TG15 1” silk dome tweeter (replacement) |
| Impedance | 8 ohms nominal (approx. 5 ohms minimum, measured by Audio Science Review) |
| Sensitivity | 83dB (2.83V/1m, measured by Audio Science Review) |
| Spinorama Preference Score | 5.07 |
| Spinorama Preference Score with Perfect Sub | 7.82 |
| Weight | 9 lbs (4.1 kg) |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Dynaudio X14
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs MartinLogan Motion 4i
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs ELAC BS U5
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL L52 Classic
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Dynaudio Emit M10
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs Parts Express Copperhead Desktop Kit
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs JBL Stage A120
- Pioneer SP-BS22-LR (Philharmonic AAM Mod) vs ELAC Uni-Fi 2.0 UB52
- See all 36 comparisons
JBL Stage A130: $399 per pair Discontinued eBay
Newer model: the JBL Stage 250B, ranked higher, rated 3.2/5.
Pros: More constant, better-behaved directivity than the smaller A120 once past the tweeter crossover point, giving a more consistent radiation pattern that likely explains some of its positive reception among other reviewers. Distortion at 96dB measures slightly better than a direct competitor (Emotiva Airmotiv B1+) in the low end, though slightly worse at high frequencies. The tweeter itself sounded decent to the reviewer, who considers it a reasonable value at its price point despite other reservations. Wide, well-filled horizontal radiation through the midrange. Measured bass extension of 66Hz (-3dB), with a measured sensitivity of 85.2dB.
Cons: Still shows the same underlying “Batman”-shaped response pattern as the A120: a bass bump, a midrange dip, a cabinet-resonance peak around 800Hz-1.7kHz (confirmed via accelerometer testing on the cabinet panels), and roughly a 5dB treble bump around 10kHz. Does not include a port bung, so sealed-cabinet listening requires DIY stuffing rather than a proper factory solution. The reviewer’s own measurements notably diverge from another well-known publication’s results on this same model, possibly reflecting a running production change, though this couldn’t be confirmed. Overall sound quality struck the reviewer as not a good-sounding speaker despite the more favorable measurements relative to the A120. Output-limited at extreme volumes (102dB), similar to its smaller sibling. Loses to the similarly-priced Emotiva Airmotiv B1+ in overall linearity and neutrality, according to the reviewer’s direct comparison. Discontinued.
Full JBL Stage A130 review and specifications →
| Bass Extension (-10dB) | 50Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 66Hz (measured, Erin’s Audio Corner) |
| Crossover Frequency | 3.2kHz |
| DIY Kit | No |
| Dimensions | 12.6”H x 7.5”W x 9.1”D (321 x 190 x 230 mm) |
| Drivers | 5.25” (133mm) polycellulose woofer, 1” (25mm) aluminum dome tweeter |
| Impedance | 6 ohms nominal, about 4.3 ohms minimum (measured, Erin’s Audio Corner) |
| Sensitivity | 85.2dB (measured, Erin’s Audio Corner) |
| Spinorama Preference Score | 4.04 |
| Spinorama Preference Score with Perfect Sub | 6.51 |
| Weight | 12 lbs (5.45 kg) each |
| Woofer Cabinet | ported |
