Short answer: the JBL Studio 698, whose mid-bass issue is smaller in scope. The Q Acoustics 5040 uses a C3 continuous curved cone profile for smooth midrange integration and controlled breakup, but its free-field response has a noticeable mid-bass scoop around 200Hz, roughly 6dB below the mean SPL. The Studio 698’s HDI horn and 1” compression driver give excellent high-frequency directivity control, though a mid-bass bump around 80Hz is its caveat.
Buy the JBL Studio 698. It is rated higher for sound quality than the Q Acoustics 5040 and costs less, which makes it the one to get unless you need something the other one does better.
Looking for alternatives? See the complete Passive Home rankings.
Specifications Side By Side
| JBL Studio 698 | Q Acoustics 5040 | |
|---|---|---|
| Price | $1,499.90 per pair | $2,472.98 per pair |
| Ranked | #30 of 74 in Large Size Floorstanding Speakers | #41 of 74 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 34Hz (measured, Erin’s Audio Corner) | 39Hz (measured, Erin’s Audio Corner) |
| Bass Extension (-3dB) | 53Hz (measured, Erin’s Audio Corner) | 70Hz (measured, Erin’s Audio Corner) |
| Dimensions | 41.7”H x 11.8”W x 15.7”D (1058 x 300 x 400 mm) | 38.1”H x 11.5”W x 14.2”D (967 x 293 x 361 mm) |
| Impedance | 6 ohms nominal (4.1 ohms minimum above 80Hz, measured by Erin’s Audio Corner) | 6 ohms nominal (3.0 ohms minimum, measured by Erin’s Audio Corner) |
| Sensitivity | 90dB (measured average, Erin’s Audio Corner) | 91.5dB (measured average, Erin’s Audio Corner) |
| Drivers | 1 in. High-Definition Imaging compression driver, 6 in. PolyPlas midrange, dual 8 in. PolyPlas woofers | 0.88 in. decoupled dome tweeter, twin 5.0 in. C3 Continuous Curved Cone woofers |
| Weight | 78.9 lbs (35.8 kg) each | 39.7 lbs (18.0 kg) each |
| Woofer Cabinet | ported, rear | ported, rear |
| Spinorama Preference Score | 4.20 | 3.80 |
| Spinorama Preference Score with Perfect Sub | 6.14 | 6.41 |
| DIY Kit | No | No |
Related Speaker Comparisons
How JBL Studio 698 compares with other leading options:
- JBL Studio 698 vs GR-Research NX-Treme
- JBL Studio 698 vs KEF Blade Two Meta
- JBL Studio 698 vs MoFi SourcePoint V10 Master Edition
- JBL Studio 698 vs MoFi SourcePoint 888
- Revel F328Be vs JBL Studio 698
Prices on this page were last checked October 2, 2026 at 10:18 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
JBL Studio 698: $1,499.90 per pair Crutchfield eBay
Older model: the JBL Studio 590 (ranked lower, rated 2.8/5).
Pros: High-Definition Imaging (HDI) horn waveguide paired with a 1” compression driver provides excellent high-frequency directivity control and seamless acoustic handoff to the 6” PolyPlas midrange. Dual 8” PolyPlas woofers deliver robust low-end authority with solid bass extension down to an F3 of 53Hz and F10 of 34Hz. High voltage sensitivity (90dB SPL at 2.83V/1m) and clean power handling provide effortless dynamic headroom and low distortion for home theater and music listening. Measured bass extension of 53Hz (-3dB), with a measured sensitivity of 90dB.
Cons: Measured response exhibits a prominent mid-bass emphasis bump around 80Hz that can sound overly thick or chesty in smaller rooms without DSP EQ. Treble response lacks top-octave ‘air’ above 12kHz compared to high-end dome or ribbon tweeters. Physically large, heavy cabinet (35.8 kg per speaker) requires careful room placement and a wide acoustic footprint.
Full JBL Studio 698 review and specifications →
| Bass Extension (-10dB) | 34Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 53Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 41.7”H x 11.8”W x 15.7”D (1058 x 300 x 400 mm) |
| Drivers | 1 in. High-Definition Imaging compression driver, 6 in. PolyPlas midrange, dual 8 in. PolyPlas woofers |
| Impedance | 6 ohms nominal (4.1 ohms minimum above 80Hz, measured by Erin’s Audio Corner) |
| Sensitivity | 90dB (measured average, Erin’s Audio Corner) |
| Spinorama Preference Score | 4.20 |
| Spinorama Preference Score with Perfect Sub | 6.14 |
| Weight | 78.9 lbs (35.8 kg) each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Head-to-Head Comparisons
- JBL Studio 698 vs JBL HDI-3600
- JBL Studio 698 vs Morel Avyra 633
- JBL Studio 698 vs Polk Audio Reserve R700
- JBL Studio 698 vs Arendal 1961 Tower
- JBL Studio 698 vs KEF R11 Meta
- JBL Studio 698 vs PSB Imagine T65
- JBL Studio 698 vs Emotiva Airmotiv T2+
- JBL Studio 698 vs Ascend Acoustics Sierra Titan Tower
- See all 51 comparisons
Q Acoustics 5040: $2,472.98 per pair Amazon eBay
Pros: C3 (Continuous Curved Cone) driver profile technology provides smooth midrange integration, controlled cone breakup, and improved bass damping. High voltage sensitivity (91.5dB SPL at 2.83V/1m) allows loud listening with low-to-moderate amplifier wattage. Cabinet features Point-to-Point (P2P) internal bracing and Helmholtz Pressure Equalizer (HPE) tubes to suppress internal standing waves and panel vibrations. Measured bass extension of 70Hz (-3dB), with a measured sensitivity of 91.5dB.
Cons: Free-field frequency response exhibits a noticeable mid-bass scoop around 200Hz (~6dB lower than mean SPL), causing an F3 of 70Hz (F10 of 39Hz) in open space and requiring boundary placement (11-22 inches from front wall) to reinforce upper bass output. Measurements indicate an enclosure resonance near 300Hz visible in sound power data. Minimum impedance drops to 3.0 ohms, demanding a stable 4-ohm rated amplifier despite high sensitivity.
Full Q Acoustics 5040 review and specifications →
| Bass Extension (-10dB) | 39Hz (measured, Erin’s Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 70Hz (measured, Erin’s Audio Corner) |
| DIY Kit | No |
| Dimensions | 38.1”H x 11.5”W x 14.2”D (967 x 293 x 361 mm) |
| Drivers | 0.88 in. decoupled dome tweeter, twin 5.0 in. C3 Continuous Curved Cone woofers |
| Impedance | 6 ohms nominal (3.0 ohms minimum, measured by Erin’s Audio Corner) |
| Sensitivity | 91.5dB (measured average, Erin’s Audio Corner) |
| Spinorama Preference Score | 3.80 |
| Spinorama Preference Score with Perfect Sub | 6.41 |
| Weight | 39.7 lbs (18.0 kg) each |
| Woofer Cabinet | ported, rear |
