Revel F328Be vs JBL Studio 698

Last updated: October 21, 2026

Short answer: the Revel F328Be, comfortably. The JBL Studio 698’s HDI horn and 1” compression driver give excellent high-frequency directivity control and a clean handoff to the 6” PolyPlas midrange, but its prominent mid-bass bump around 80Hz can sound thick or chesty without DSP EQ. The F328Be is quite flat on-axis with superb directivity and efficiency above 90dB, limited mainly by asymmetric vertical directivity.

Revel F328Be vs JBL Studio 698

Buy the Revel F328Be if sound quality is the priority over the price, or the JBL Studio 698 if the price is the priority over sound quality.

Looking for alternatives? See the complete Passive Home rankings.

Measured Differences

Prices on this page were last checked November 14, 2026 at 6:17 PM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Specifications Side By Side

Revel F328Be JBL Studio 698
Price$19,359.90 per pair$1,499.90 per pair
Ranked#9 of 228 in Large Size Floorstanding Speakers#62 of 228 in Large Size Floorstanding Speakers
Bass Extension (-10dB)39Hz (measured, Audio Science Review)34Hz (measured, Erin’s Audio Corner)
Bass Extension (-3dB)74Hz (measured, Audio Science Review)53Hz (measured, Erin’s Audio Corner)
Dimensions50.9”H x 13.5”W x 17.6”D (1292.9 x 342.9 x 447 mm)41.7”H x 11.8”W x 15.7”D (1058 x 300 x 400 mm)
Impedance8 ohms nominal (3 ohms minimum, measured by Audio Science Review)6 ohms nominal (4.1 ohms minimum above 80Hz, measured by Erin’s Audio Corner)
DriversThree 8” (200mm) Deep Ceramic Composite aluminum cones, with cast frames woofer, 5-1/4” (130mm) Deep Ceramic Composite aluminum cone, with cast frame midrange, 1” (25mm) Beryllium dome, with acoustic lens waveguide tweeter1 in. High-Definition Imaging compression driver, 6 in. PolyPlas midrange, dual 8 in. PolyPlas woofers
Sensitivity91dB (measured, Audio Science Review)90dB (measured average, Erin’s Audio Corner)
Weight112.4 lbs (51 kg) each78.9 lbs (35.8 kg) each
Woofer Cabinetported, rearported, rear
Spinorama Preference Score6.404.20
Spinorama Preference Score with Perfect Sub7.816.14
DIY KitNoNo

Where the Ratings Come From

This comparison is generated from the ratings, specifications and measurements on each product’s own page, and it updates when that data changes. How we rank explains how each rating is decided.
