Short answer: the JBL HDI-3800 for better sound quality, the SVS Ultra Evolution Pinnacle for the lower price. The JBL HDI-3800 ranks #7 of 71 floorstanding speakers at $5000. The SVS Ultra Evolution Pinnacle ranks #49 at $2499.99, $2500.01 cheaper.
What the JBL HDI-3800 offers: 2410H-2 1” Teonex compression driver matched to a custom High-Definition Imaging (HDI) horn geometry achieves exceptional horizontal directivity control, high output capability, and effortless transient response. Triple 8” Advanced Aluminum Matrix woofers deliver deep, authoritative bass extension down to an F3 of 37Hz and F10 of 28Hz with minimal low-frequency compression. Outstanding sensitivity (92dB SPL at 2.83V/1m) and ultra-low THD/multitone distortion allow extremely high undistorted SPL output in large home theater spaces. Watch for: On-axis frequency response features a narrow upper-frequency elevation around 8-10kHz, performing noticeably smoother when toed out 10-20° off-axis. Vertical directivity handoff across the triple woofer layout creates vertical soundstage height tilt depending on listening distance and ear height. Minimum impedance dips to 3.8 ohms, requiring high-current amplifier stability. Substantial cabinet dimensions and 38kg weight require significant room real estate.
What the SVS Ultra Evolution Pinnacle offers: Flagship three-way tower with a diamond-coated tweeter, dual midranges and four force-balanced 8-inch woofers. Erin measured exceptional 27Hz extension, broad roughly +/-75-degree horizontal coverage, an 88.1dB sensitivity and a 4.03 preference score even without a subwoofer. Watch for: The 5.25-to-8-inch transitions and complex array do not produce class-leading smoothness: 0.184 on-axis, 0.226 predicted in-room and 3.64 directivity-index consistency. At 96.7 pounds each, these are difficult to position, and their Q of 1.25 indicates some bass emphasis.
Buy the JBL HDI-3800 if sound quality matters more than the price. Buy the SVS Ultra Evolution Pinnacle if the price matters more than sound quality.
Specifications Side By Side
| JBL HDI-3800 | SVS Ultra Evolution Pinnacle | |
|---|---|---|
| Price | $5,000.00 Discontinued | $2,499.99 each |
| Ranked | #7 of 71 in Large Size Floorstanding Speakers | #49 of 71 in Large Size Floorstanding Speakers |
| Bass Extension (-10dB) | 28Hz (measured, Erin’s Audio Corner) | - |
| Bass Extension (-3dB) | 37Hz (measured, Erin’s Audio Corner) | - |
| Dimensions | 43.3"H x 11.8"W x 16.4"D (1100.5 x 300.0 x 417.8 mm) | 50.2H x 11.8W x 18.1D in |
| Discontinued | Yes | - |
| Impedance | 4 ohms nominal (3.8 ohms minimum, measured by Erin’s Audio Corner) | 6 ohms nominal |
| Sensitivity | 92dB (measured average, Erin’s Audio Corner) | 88dB |
| Drivers | 1 in. 2410H-2 Teonex compression driver with HDI horn, triple 8 in. Advanced Aluminum Matrix cone woofers | 1" diamond-coated tweeter, dual 5.25" midranges, quad 8" woofers |
| Weight | 83.8 lbs / 38.0 kg each | 96.7 lbs each |
| Woofer Cabinet | ported, rear | - |
| Enclosure | - | 3-way passive, dual rear ports |
Related Speaker Comparisons
More useful head-to-heads from the same speaker class:
- Klipsch RP-5000F II vs Revel F228Be
- Klipsch RP-5000F II vs MoFi SourcePoint 888
- Klipsch Forte IV vs Klipsch RP-5000F II
- JBL HDI-3800 vs Revel F208
- JBL HDI-3800 vs Focal Aria Evo X N°2
Prices on this page were last checked August 25, 2026 at 6:19 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
The Two Speakers In Full
JBL HDI-3800: $5,000.00 Discontinued eBay
Pros: 2410H-2 1” Teonex compression driver matched to a custom High-Definition Imaging (HDI) horn geometry achieves exceptional horizontal directivity control, high output capability, and effortless transient response. Triple 8” Advanced Aluminum Matrix woofers deliver deep, authoritative bass extension down to an F3 of 37Hz and F10 of 28Hz with minimal low-frequency compression. Outstanding sensitivity (92dB SPL at 2.83V/1m) and ultra-low THD/multitone distortion allow extremely high undistorted SPL output in large home theater spaces.
Cons: On-axis frequency response features a narrow upper-frequency elevation around 8-10kHz, performing noticeably smoother when toed out 10-20° off-axis. Vertical directivity handoff across the triple woofer layout creates vertical soundstage height tilt depending on listening distance and ear height. Minimum impedance dips to 3.8 ohms, requiring high-current amplifier stability. Substantial cabinet dimensions and 38kg weight require significant room real estate. Discontinued.
Full JBL HDI-3800 review and specifications →
| Bass Extension (-10dB) | 28Hz (measured, Erin's Audio Corner) |
|---|---|
| Bass Extension (-3dB) | 37Hz (measured, Erin's Audio Corner) |
| Dimensions | 43.3"H x 11.8"W x 16.4"D (1100.5 x 300.0 x 417.8 mm) |
| Discontinued | Yes |
| Drivers | 1 in. 2410H-2 Teonex compression driver with HDI horn, triple 8 in. Advanced Aluminum Matrix cone woofers |
| Impedance | 4 ohms nominal (3.8 ohms minimum, measured by Erin's Audio Corner) |
| Sensitivity | 92dB (measured average, Erin's Audio Corner) |
| Weight | 83.8 lbs / 38.0 kg each |
| Woofer Cabinet | ported, rear |
- Links
- Reviews, Comparisons and Sound Samples
- Erin’s Audio Corner: JBL HDI-3800 Floorstanding Speaker Review More from Erin’s Audio Corner →
- Erin’s Audio Corner: Choosing the Ultimate Speaker: JBL Studio 698 or HDI-3800?
- Erin’s Audio Corner Website JBL HDI-3800
- Erin’s Audio Corner Measurements (spinorama.org)
- Reddit Search for JBL HDI-3800 Review
- Head-to-Head Comparisons
SVS Ultra Evolution Pinnacle: $2,499.99 each SVS eBay
Pros: Flagship three-way tower with a diamond-coated tweeter, dual midranges and four force-balanced 8-inch woofers. Erin measured exceptional 27Hz extension, broad roughly +/-75-degree horizontal coverage, an 88.1dB sensitivity and a 4.03 preference score even without a subwoofer.
Cons: The 5.25-to-8-inch transitions and complex array do not produce class-leading smoothness: 0.184 on-axis, 0.226 predicted in-room and 3.64 directivity-index consistency. At 96.7 pounds each, these are difficult to position, and their Q of 1.25 indicates some bass emphasis.
Full SVS Ultra Evolution Pinnacle review and specifications →
| Dimensions | 50.2H x 11.8W x 18.1D in |
|---|---|
| Drivers | 1" diamond-coated tweeter, dual 5.25" midranges, quad 8" woofers |
| Enclosure | 3-way passive, dual rear ports |
| Impedance | 6 ohms nominal |
| Sensitivity | 88dB |
| Weight | 96.7 lbs each |
