Short answer: choose between the HK Audio LINEAR 9 112 XA and Axiom ED120A for the deployment, not from the automatic ranking alone. Their driver format, power requirements, coverage, bass reach, output capability, and control features determine which is the more practical PA for a particular room or system.
The case for the HK Audio LINEAR 9 112 XA. The high-quality vendor data returns a 5.66 ideal-subwoofer preference score. MILAN networking, comprehensive remote DSP and a durable plywood cabinet make it a strong systems-oriented choice for professional deployment.
The case for the Axiom ED120A. High-quality vendor Spinorama data gives it a 5.73 ideal-subwoofer preference score and 52Hz bass extension, a solid tonal showing for a professional cabinet. CORE DSP, PRONET remote control and an asymmetric rotatable horn add useful installation flexibility.
Important trade-offs. Its 82Hz measured bass extension and 131dB peak claim mean it depends more on a subwoofer than the strongest stand-alone boxes. Buyers who do not need networked audio may find better value in simpler mainstream models. The 132dB claimed peak is competitive rather than class-leading, and the asymmetric 60°-to-100° pattern needs more deliberate aiming than a conventional symmetric horn. Availability and service coverage are less broad than the mainstream QSC, JBL, Yamaha and RCF choices.
Buy the HK Audio LINEAR 9 112 XA when its stated format, coverage, and system features fit the job better.
Buy the Axiom ED120A when its stated output, control, and deployment strengths better match the system.
Looking for alternatives? See the complete PA & Live Sound rankings.
A networked 12 inch powered PA speaker in a durable plywood cabinet with good sound and full remote DSP for professional systems.
A good sounding professional 12 inch powered PA speaker with deep bass, remote control and an asymmetric horn for installs.
Prices on this page were last checked October 23, 2026 at 8:27 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.
As an eBay Partner, we may be compensated if you make a purchase.
Specifications Side By Side
| HK Audio LINEAR 9 112 XA | Axiom ED120A | |
|---|---|---|
| Price | $1,965.54 | $1,790 |
| Ranked | #15 of 83 in 12-Inch PA Speakers | #18 of 83 in 12-Inch PA Speakers |
| Passive | No | No |
| Configuration | Active 2-way bass-reflex PA speaker/monitor | Active 2-way bass-reflex PA speaker |
| Drivers | 12” woofer, 1” compression driver | 12” woofer, 1.4” compression driver |
| Frequency Response | 62Hz - 20kHz (-10dB, manufacturer specified) | 65Hz - 17kHz (-6dB, manufacturer specified) |
| Dimensions | 26.4”H x 14.6”W x 12.2”D (670 x 370 x 310 mm) | 24”H x 14.2”W x 12.2”D (610 x 360 x 310 mm) |
| Bass Extension (-3dB) | 90Hz (measured, vendor Spinorama data) | 60Hz (measured, vendor Spinorama data) |
| Coverage | 70° x 50°, rotatable | 60°-100° asymmetric x 60° |
| Maximum SPL | 131dB peak (manufacturer specified) | 132dB peak (manufacturer specified) |
| Inputs | XLR/TRS combo, XLR thru/DSP out, dual EtherCON | XLR input and link; EtherCON control network |
| Amplifier Power | 700W RMS | 1,200W continuous (900W LF + 300W HF Class D, manufacturer specified) |
| Crossover Frequency | 1600Hz | - |
| Cabinet Material | Birch plywood with PU coating | 15mm reinforced phenolic birch plywood |
| Rigging | 5 x M8 points; DuoTilt 3°/7° pole mount | M10 and M6 fly points; pole-mount socket |
| Network Control | Milan and HK Audio DSP Control | PRONET control over EtherCON/CANBUS |
| DSP | Yes, networked PEQ, filters, delay and limiter | Yes, CORE processing with PRONET control |
| Bluetooth | No | No |
| Weight | 45.2 lbs (20.5 kg) | 41.9 lbs (19 kg) |
| Spinorama Preference Score | 2.40 | 3.30 |
| Spinorama Preference Score with Perfect Sub | 5.66 | 5.73 |
| XLR Input | Yes | Yes |
| RCA Input | No | No |
| TRS Input | Yes | No |
| Optical Input | No | No |
| Coaxial Input | No | No |
| USB Input | No | No |
| HDMI Input | No | No |
| AES Input | No | No |
| Aux Input | No | No |
| Microphone Input | No | No |
| Guitar Input | No | No |
Frequency Response Compared
Both speakers’ spinorama measurements, overlaid. A flatter line is more neutral: peaks sound forward or harsh, dips sound recessed. Each curve is shifted so its average from 300 Hz to 3 kHz sits at 0 dB, so loudness differences between the two are removed and only the shape is compared.
Measurement data: HK Audio LINEAR 9 112 XA (measured by the manufacturer) and Axiom ED120A (measured by the manufacturer), via spinorama.org.
