JBL Studio 520C Review: Rated 3.4/5

Last updated: October 21, 2026

The JBL Studio 520C is rated 3.4/5 for sound quality, #95 of 134 Center Channel Speakers. See all Passive Home rankings for every top pick.

JBL Studio 520C · Editor's rating 3.4/5, ranked #95 of 134 Center Channel Speakers

Prices on this page were last checked November 18, 2026 at 8:41 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Brand: JBL

#95 JBL Studio 520C: $349.95 each Discontinued eBay

Same family: the JBL Studio 530 (bookshelf, rated 3.3/5) and the JBL Studio 590 (floorstanding, rated 2.8/5). See every JBL Studio generation.

Pros: A compact center channel with a horn loaded compression tweeter between two 4 inch woofers. A two-way center with a 1” compression driver on a horn between two 4” woofers. Erin’s Audio Corner measured low on-axis deviation (0.30) and bass to about 51Hz at -10dB, and the score reaches 5.92 with an ideal subwoofer. Measured bass extension of 98.1Hz (-3dB).

Cons: The listening window spans 4.3dB from 300Hz to 5kHz and directivity is uneven (3.81dB directivity index deviation), for a preference score of 2.92 without a subwoofer. Discontinued.

Is the JBL Studio 520C right for you?

Skip it if

  • you will not add a subwoofer: bass rolls off below about 98 Hz.
  • you want to buy it new: it is discontinued.
ReleasedOct 2011 (15 years ago)
Bass Extension (-10dB)about 51.1Hz (measured, Erin’s Audio Corner)
Bass Extension (-3dB)98.1Hz (measured, Erin’s Audio Corner)
DIY KitNo
Dimensions6.8”H x 21.9”W x 6.6”D (172 x 555 x 168 mm)
Drivers1” compression driver with horn, 2x 4” woofers
Frequency Response60Hz-40kHz -6dB (manufacturer specified)
Impedance6 ohms nominal (manufacturer specified)
Sensitivity88dB (2.83V/1m, manufacturer specified)
Spinorama Preference Score2.92
Spinorama Preference Score with Perfect Sub5.92
Weight16.5 lbs (7.5 kg)
