K-array Dragon KX12 Review: Rated 1.7/5

Last updated: October 21, 2026

The K-array Dragon KX12 is rated 1.7/5 for sound quality, #82 of 83 12-Inch PA Speakers. See all PA & Live Sound rankings for every top pick.

K-array Dragon KX12 · Editor's rating 1.7/5, ranked #82 of 83 12-Inch PA Speakers

Prices on this page were last checked November 18, 2026 at 8:41 AM UTC. Product prices and availability are accurate as of that date/time and are subject to change; the price and availability shown on Amazon at the time of purchase will apply to the purchase of this product.

As an eBay Partner, we may be compensated if you make a purchase.

Brand: K-array

#82 K-array Dragon KX12: $1,900 Passive Discontinued eBay

Newer model: the K-array Dragon-KX12 I, ranked lower, estimated 1.7/5, released 2025. See every K-array Dragon KX12 generation.

Pros: A slim stainless steel passive PA speaker with loud peaks and consistent tone off to the sides, made for use with subwoofers. A slim 201mm deep stainless steel cabinet with a 133dB peak, and the most consistent off-axis tone in this group (2.26dB directivity-index deviation). Measured bass extension of 109Hz (-3dB).

Cons: Vendor measurements give the lowest preference scores here, -4.28 standalone and -0.41 with an ideal subwoofer, because bass stops near 109Hz (-3dB) and the response tilts strongly. It is passive and discontinued, so it is mainly found used.

Is the K-array Dragon KX12 right for you?

Skip it if

  • you want neutral sound: its measured preference score is -0.4 even with a subwoofer.
  • you will not add a subwoofer: bass rolls off below about 109 Hz.
  • you want to buy it new: it is discontinued.
Released2015 (11 years ago)
AES InputNo
Amplifier PowerPassive speaker; requires external amplification
Aux InputNo
Bass Extension (-10dB)about 80.8Hz (measured, vendor Spinorama data)
Bass Extension (-3dB)109Hz (measured, vendor Spinorama data)
BluetoothNo
Coaxial InputNo
ConfigurationPassive 2-way coaxial PA speaker, IP54 stainless steel enclosure
DSPNo (passive)
Dimensions13.4”H x 12.6”W x 7.9”D (340 x 320 x 201 mm)
Drivers12” coaxial woofer with compression driver
Frequency Response120Hz - 18kHz (manufacturer specified)
Guitar InputNo
HDMI InputNo
Impedance8 ohms
Maximum SPL133dB peak (manufacturer specified)
Microphone InputNo
Optical InputNo
PassiveYes
RCA InputNo
Spinorama Preference Score-4.28
Spinorama Preference Score with Perfect Sub-0.41
TRS InputNo
USB InputNo
Weight26.9 lbs (12.2 kg)
XLR InputNo
